Sida 1/6
www.fusionelectronics.com
FUSION Electronics New Zealand Ph: +64 9 369 2900
FUSION Electronics Australia Ph: +61 1300 736 012
FUSION Electronics Europe Ph: +44 845 299 7586
FUSION Electronics USA Ph: +1 623 580 9000
User / Installation Manual
Marine Speakers
MS-FR402, MS-FR602, MS-FR702
www.busse-yachtshop.de | info@busse-yachtshop.de
45
4
PUBLISHED BY FUSION ELECTRONICS LIMITED:
© Copyright 2010 by FUSION Electronics Limited.
All rights reserved. Specifications and design are
subject to change without notice. v7.0
YOU CAN HELP PROTECT THE ENVIRONMENT!
Please remember to respect the local regulations:
Hand in the non-working electrical equipment to
an appropriate waste disposal center.
RECORD YOUR PRODUCT DETAILS HERE:
MODEL NUMBER DATE OF PURCHASE
AFFIX RECEIPT HERE
Contents
List Of Contents 4
Product Specifications 4
Line Drawings And Dimensions 5
Installation Guide 8
Optimum Enclosure Recommendations 10
Trouble Shooting 10
Speaker Grille Options 11
www.busse-yachtshop.de | info@busse-yachtshop.de
67
6
FUSION’s Full Range 2-Way Marine Speakers are carefully designed and manufactured
specifically for marine use. All feature a unique high tech bass/mid cone, a fluid cooled
titanium dome tweeter, engineered to minimise magnetic interference, and are constructed
to be water resistant.
These speakers have been thoroughly tested to ensure consistent and reliable performance
is achieved in the challenging marine environment. If you have any questions about the
installation and/or operation of this product, contact your nearest Authorised FUSION
Dealer for further assistance.
List Of Contents
1 Pair Speakers
1 Pair Standard Grilles
1 Pair Sport Grilles (MS-FR602, MS-FR702 only)
1 Pair Cloth Grilles (MS-FR602, MS-FR702 only)
Wiring Kit
Mounting Hardware
1 Pair Spacer Gaskets
Manual
Warranty Card
Mounting Template
1 Pair FUSION Gel Badges, Green/Black
1 Pair FUSION Gel Badges, White/Black
1 Pair FUSION Gel Badges, Silver/Black
Product Specifications
MS – FR402 MS – FR602 MS - FR702
Tweeter Type Titanium Dome Titanium Dome Titanium Dome
Max Power (watts) 120 200 260
Efficiency (1W/1M) 87db 90db 91db
Frequency Response 90 – 22kHz 70 – 22kHz 60 – 22kHz
Min. Mounting Depth Allowing
Clearance (mm/in) 60mm (2 7/16") 75mm (3") 80mm (3 3/16")
Impedance 4 ohms 4 ohms 4 ohms
Line Drawings And Dimensions
MS – FR402
004
Product Specs
005
MS-FR402
137mm (5 7/16")
137mm (5 7/16")
137mm (5 7/16")
52mm
(2 1/16")
17mm
( 11/16")
95mm (3 3/4")
CAUTION: For speaker mounting restrictions, please refer to manufacturers
recommendations for any related navigational equipment.
www.busse-yachtshop.de | info@busse-yachtshop.de
