GEAppliances.com

DBL333

DCL333

DVL223

Dryers

134202100B 175D1807P436 49-90172-1 08-03 JR

Safety Instructions . . . . . . . . . 2–5

Operating Instructions

Control Panels . . . . . . . . . . . . . . . .6

Control Settings . . . . . . . . . . . . . . .7

Loading and Using the Dryer . . .8, 9

Installation Instructions

Electrical Requirements . . . . . . . 11

Exhausting the Dryer . . . . . . . . . 12

Installing the Dryer . . . . . . . . 13–19

Preparing to Install the Dryer . . 10

Troubleshooting Tips . . . . . 20, 21

Consumer Support

Consumer Support . . . . Back Cover

Warranty . . . . . . . . . . . . . . . . . . . 23

Write the model and serial

numbers here:

Model # __________________

Serial # __________________

You can find them on the label

on the front of the left side of

the door opening.

Owner’s Manual and

Installation Instructions

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions

WARNING!

For your safety, the information in this manual must be followed to minimize the risk of fire

or explosion, electric shock, or to prevent property damage, personal injury, or death.

WHAT TO DO IF YOU SMELL GAS:

Do not try to light a match, or cigarette, or

turn on any gas or electrical appliance.

Do not touch any electrical switch;

do not use any phone in your building.

Clear the room, building or area of all

occupants.

Immediately call your gas supplier from

a neighbor’s phone. Follow the gas

supplier’s instructions carefully.

If you cannot reach your gas supplier,

call the fire department.

California Safe Drinking Water and Toxic Enforcement Act

This act requires the governor of California to publish a list of substances known to the state to cause cancer,

birth defects or other reproductive harm and requires businesses to warn customers of potential exposure

to such substances.

Gas appliances can cause minor exposure to four of these substances, namely benzene, carbon monoxide,

formaldehyde and soot, caused primarily by the incomplete combustion of natural gas or LP fuels.

Properly adjusted dryers will minimize incomplete combustion. Exposure to these substances can be

minimized further by properly venting the dryer to the outdoors.

■Do not store or use gasoline or other

flammable vapors and liquids in the

vicinity of this or any other appliance.

■Installation and service must be performed

by a qualified installer, service agency or

the gas supplier.

■Properly ground dryer to conform with all

governing codes and ordinances. Follow

details in the Installation Instructions section.

■Install or store where it will not be exposed

to temperatures below freezing or exposed

to the weather.

■Connect to a properly rated, protected and

sized power supply circuit to avoid electrical

overload.

■Remove all sharp packing items and dispose

of all shipping materials properly.

Exhaust/Ducting:

This dryer MUST be exhausted to the outside.

Use only rigid metal 4″diameter ductwork

inside the dryer cabinet. Use only rigid metal

or flexible metal 4″diameter ductwork for

exhausting to the outside. USE OF PLASTIC OR

OTHER COMBUSTIBLE DUCTWORK CAN CAUSE

A FIRE. PUNCTURED DUCTWORK CAN CAUSE A

FIRE IF IT COLLAPSES OR BECOMES OTHERWISE

RESTRICTED IN USE OR DURING INSTALLATION.

Follow details in the Installation Instructions section.

PROPER INSTALLATION

This dryer must be properly installed and located in accordance with the Installation Instructions

before it is used.

Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions

GEAppliances.com

YOUR LAUNDRY AREA

■Keep the area underneath and around your

appliances free of combustible materials, such

as lint, paper, rags, chemicals, gasoline and

other flammable vapors and liquids.

■Keep the floor around your appliances clean

and dry to reduce the possibility of slipping.

■Keep area around the exhaust opening and

surrounding areas free from the accumulation

of lint, dust and dirt.

■Do not obstruct the flow of ventilating air.

Do not stack or place laundry or throw rugs

against the front or back of the dryer.

■Close supervision is necessary if this appliance

is used by or near children. Do not allow

children to

play on, with or inside this or

any other appliance.

■Keep all laundry aids (such as detergents,

bleaches, etc.) out of the reach of children,

preferably in a locked cabinet. Observe all

warnings on container labels to avoid injury.

■Never climb on or stand on the dryer top.

■Do not install or store this appliance where

it will be exposed to the weather.

WARNING!
