Sida 1/112

When you installing AGP card, please make sure the following notice

is fully understood and practiced. If your AGP card has "AGP 4X/8X

(1.5V) notch"(show below), please make sure your AGP card is AGP

4X/8X (1.5V).

Caution: AGP 2X card is not supported by Intel

845(GE/PE) / 845(E/G) /

850(E) / E7205 / 865(G/PE/P/GV) / 875P. You might experience system

unable to boot up normally. Please insert an AGP 4X/8X card.

Example 1: Diamond Vipper V770 golden finger is compatible with 2X/4X

mode AGP slot. It can be switched between AGP 2X(3.3V) or 4X(1.5V) mode

by adjusting the jumper. The factory default for this card is 2X(3.3V).

The GA-8I865GVMK (or any AGP 4X/8X only) motherboards might not

function properly, if you install this card without switching the jumper to

4X(1.5V) mode in it.

Example 2: Some ATi Rage 128 Pro graphics cards made by "Power Color",

the graphics card manufacturer & some SiS 305 cards, their golden finger is

compatible with 2X(3.3V)/4X(1.5V) mode AGP slot, but they support 2X(3.3V)

only. The GA-8I865GVMK (or any AGP 4X/8X only) motherboards might not

function properly, If you install this card in it.

Note : Although Gigabyte's AG32S(G) graphics card is based on ATi Rage

128 Pro chip, the design of AG32S(G) is compliance with AGP 4X(1.5V)

specification. Therefore, AG32S(G) will work fine with Intel

845(GE/PE) /

845(E/G) / 850(E) / E7205 / 865(G/PE/P/GV) / 875P based motherboards.

AGP 4X/8X notch

Produktspecifikationer

Varumärke:	Gigabyte
Kategori:	moderkort
Modell:	GA-8I865GVMK
Bredd:	244 mm
Djup:	244 mm
Maximalt internminne:	4 GB
Expansionsplatser:	3 x PCI
Antal minnesplatser:	4
processortillverkare:	Intel
Nätverksegenskaper:	Intel PRO/100 VE Ethernet
Antal LAN (RJ-45) anslutningar:	1
Produktstorlek (BxDxH):	244 x 244 mm
processorsockel:	Socket 478
Seriella portar:	1
Antal PS/2-portar:	2
Strömkälla av typen:	ATX
Antal USB 2.0 anslutningar:	4
USB 2.0 anslutning:	2
Antalet Seriella ATA anslutningar:	2
Moderkort formfaktor:	micro ATX
Medföljande programvara:	Norton Internet Security 2003 \n- Norton Anti Virus \n- Norton Personal Firewall \n- Norton Privacy Control \n- Norton Parental Control \n- Norton Spam Alert \nGIGABYTE Windows Utility Manager \nAdobe Acrobat Reader\n
Kvalitet på VGA (D-Sub) porten:	1
Parallellport:	1
Ljudchipp:	Realtek ALC655
CD/AUX ljudingång:	Ja
Anslutning för diskettenhet:	Ja
GAME/MIDI anslutning:	Ja
