Sida 1/112

When you installing AGP card, please make sure the following

notice is fully understood and practiced. If your AGP card has

"AGP 4X/8X (1.5V) notch"(show below), please make sure your

AGP card is AGP 4X/8X (1.5V).

Caution: AGP 2X card is not supported by Intel

845(GE/PE) / 845(E/

G) / 850(E) / E7205 / 865(G/PE/P) / 875P. You might experience system

unable to boot up normally. Please insert an AGP 4X/8X card.

Example 1: Diamond Vipper V770 golden finger is compatible with 2X/4X

mode AGP slot. It can be switched between AGP 2X(3.3V) or 4X(1.5V)

mode by adjusting the jumper. The factory default for this card is

2X(3.3V). The GA-8IPE1000 Series (or any AGP 4X/8X only)

motherboards might not function properly, if you install this card without

switching the jumper to 4X(1.5V) mode in it.

Example 2: Some ATi Rage 128 Pro graphics cards made by "Power Color",

the graphics card manufacturer & some SiS 305 cards, their golden finger

is compatible with 2X(3.3V)/4X(1.5V) mode AGP slot, but they support 2X

(3.3V) only. The GA-8IPE1000 Series (or any AGP 4X/8X only)

motherboards might not function properly, If you install this card in it.

Note : Although Gigabyte's AG32S(G) graphics card is based on ATi Rage

128 Pro chip, the design of AG32S(G) is compliance with AGP 4X(1.5V)

specification. Therefore, AG32S(G) will work fine with Intel

845(GE/PE) /

845(E/G) / 850(E) / E7205 / 865(G/PE/P) / 875P based motherboards.

Before you install PCI cards, please remove the Dual BIOS label from

PCI slots if there is one.

AGP 4X/8X notch

M The author assumes no responsibility for any errors

or omissions that may appear in this document nor

does the author make a commitment to update the

information contained herein.

M Third-party brands and names are the property of

their respective owners.

M Please do not remove any labels on motherboard, this

may void the warranty of this motherboard.

M Due to rapid change in technology, some of the

specifications might be out of date before publication

of this booklet.

Produktspecifikationer

Varumärke:	Gigabyte
Kategori:	moderkort
Modell:	GA-8IPE1000-L
Bredd:	305 mm
Djup:	244 mm
Hörlursutgångar:	1
Maximalt internminne:	4 GB
Ljudutgångskanaler:	6.1 kanaler
Snabbinstallationsguide:	Ja
Kompatibla processorer:	Intel® Pentium® 4
Antal minnesplatser:	4
Nätverksegenskaper:	Snabb Ethernet
Antal LAN (RJ-45) anslutningar:	1
processorsockel:	Socket 478
Antal PS/2-portar:	2
Strömkälla av typen:	ATX
Antal USB 2.0 anslutningar:	4
Minnets hastigheter:	266,333,400 MHz
Max antal processorer:	1
USB 2.0 anslutning:	2
Antalet Seriella ATA anslutningar:	2
BIOS minnesstorlek:	16 mbit
Moderkort formfaktor:	ATX
Medföljande programvara:	Norton Internet Security 2003\n- Norton Anti Virus\n- Norton Personal Firewall\n- Norton Privacy Control\n- Norton Parental Control\n- Norton Spam Alert\nGIGABYTE Windows Utility Manager\nAdobe Acrobat Reader
Ombord grafikkort:	Nej
Uttag för mikrofon/linje in:	Ja
Drivrutiner medföljer:	Ja
Parallellport:	1
Ljudchipp:	Realtek ALC655
Stöd för parallellprocessteknik:	Stöds inte
Antal COM portar:	2
Stöd för processorsystembussar:	533,800 MHz
PCI-kortplatser:	5
Antalet parallella ATA-anslutningar:	2
CD/AUX ljudingång:	Ja
Anslutning för diskettenhet:	Ja
GAME/MIDI anslutning:	Ja
AGP x8 kortplatser:	1
