Sida 1/96

When you installing AGP card, please make sure the following

notice is fully understood and practiced. If your AGP card has

"AGP 4X/8X(1.5V) notch"(show below), please make sure your AGP

card is AGP 4X/8X(1.5V).

Caution: AGP 2X card is not supported by SiS

648. You might

experience system unable to boot up normally. Please insert an

AGP 4X/8X card.

Example 1: Diamond Vipper V770 golden finger is compatible with 2X/4X

mode AGP slot. It can be switched between AGP 2X(3.3V) or 4X(1.5V)

mode by adjusting the jumper. The factory default for this card is

2X(3.3V). The GA-8S648(-L) (or any AGP 4X only) motherboards might

not function properly, if you install this card without switching the jumper

to 4X(1.5) mode in it.

Example 2: Some ATi Rage 128 Pro graphics cards made by "Power

Color", the graphics card manufacturer & some SiS 305 cards, their

golden finger is compatible with 2X(3.3V)/4X(1.5V) mode AGP slot, but

they support 2X(3.3V) only. The GA-8S648(-L) (or any AGP 4X only)

motherboards might not function properly, If you install this card in it.

Note : Although Gigabyte's AG32S(G) graphics card is based on

ATi Rage 128 Pro chip, the design of AG32S(G) is compliance

with AGP 4X(1.5V) specification. Therefore, AG32S (G)will work

fine with SiS

648 based motherboards.

AGP 4X/8X notch

M The author assumes no responsibility for any errors

or omissions that may appear in this document nor

does the author make a commitment to update the

information contained herein.

M Third-party brands and names are the property of

their respective owners.

M Please do not remove any labels on motherboard, this

may void the warranty of this motherboard.

M Due to rapid change in technology, some of the

specifications might be out of date before publication

of this booklet.

Produktspecifikationer

Varumärke:	Gigabyte
Kategori:	moderkort
Modell:	GA-8S648
Bredd:	295 mm
Djup:	209 mm
Hörlursutgångar:	1
Maximalt internminne:	3 GB
Ljudutgångskanaler:	5.1 kanaler
Komponent för:	PC
Kompatibla processorer:	Intel® Pentium® 4
Minnestyper som stöds:	DDR-SDRAM
Antal minnesplatser:	3
processortillverkare:	Intel
processorsockel:	Socket 478
Antal PS/2-portar:	2
Strömkälla av typen:	ATX
Antal USB 2.0 anslutningar:	2
Minnets hastigheter:	266,333 MHz
USB 2.0 anslutning:	2
BIOS minnesstorlek:	2 mbit
Moderkort, chipsetfamilj:	SiS
Moderkort formfaktor:	ATX
Medföljande programvara:	Norton Internet Security\nNorton Anti-Virus\nNorton Personal Firewall\nNorton Privacy Control\nNorton Parental Control\nNorton Spam Alert\nGIGABYTE Windows Utility Manager\nAdobe Acrobat Reader
Uttag för mikrofon/linje in:	Ja
Stöd för parallellprocessteknik:	Stöds inte
S/PDIF ut anslutning:	Ja
Antal COM portar:	2
Stöd för processorsystembussar:	533 MHz
PCI-kortplatser:	5
Antalet parallella ATA-anslutningar:	2
Anslutning för diskettenhet:	Ja
AGP x8 kortplatser:	1
