When you installing AGP card, please make sure the following

notice is fully understood and practiced. If your AGP card has

"AGP 4X/8X(1.5V) notch"(show below), please make sure your AGP

card is AGP 4X/8X (1.5V).

Caution: AGP 2X(3.3V) card is not supported by VIA PT800. You might

experiencesystem unable to boot up normally. Please insert an AGP

4X/8X (1.5V) card

Example 1: Diamond Vipper V770 golden finger is compatible with

2X/4X mode AGP slot. It can be switched between AGP 2X(3.3V) or 4X

(1.5V) mode by adjusting the jumper. The factory default for this card is

2X(3.3V).

The GA-8VT800 motherboards might not function properly, if you install

this card without switching the jumper to 4X(1.5V) mode in it.

Example 2: Some ATi Rage 128 Pro graphics cards made by

"Power Color", the graphics card manufacturer & some SiS 305 cards,

their golden finger is compatible with 2X/4X mode AGP slot, but they

support 2X(3.3V) only. The GA-8VT800 motherboards might not function

properly, If you install this card in it.

Note : Although Gigabyte's AG32S(G) graphics card is based on

ATi Rage 128 Pro chip, the design of AG32S(G) is compliance

with AGP 4X(1.5V) specification. Therefore, AG32S (G)will work

fine with VIA PT800 based motherboards.

AGP 4X/8X notch

M The author assumes no responsibility for any errors or omissions

that may appear in this document nor does the author make a

commitment to update the information contained herein.

M Third-party brands and names are the property of theirrespective

owners.

M Please do not remove any labels on motherboard, thismay void the

warranty of this motherboard.

M Due to rapid change in technology, some of the specifications might

be out of date before publication of this booklet.

Produktspecifikationer

Varumärke:	Gigabyte
Kategori:	moderkort
Modell:	GA-8VT800-L
Bredd:	305 mm
Djup:	215 mm
Hörlursutgångar:	1
Maximalt internminne:	3 GB
Ljudutgångskanaler:	6.1 kanaler
Kompatibla processorer:	Intel® Pentium® 4
Antal minnesplatser:	3
Nätverksegenskaper:	Snabb Ethernet
Antal LAN (RJ-45) anslutningar:	1
processorsockel:	Socket 478
Antal PS/2-portar:	2
Strömkälla av typen:	ATX
Antal USB 2.0 anslutningar:	2
Minnets hastigheter:	266,333,400 MHz
Max antal processorer:	1
USB 2.0 anslutning:	2
Moderkort formfaktor:	ATX
Medföljande programvara:	Norton Internet Security\n- Norton Anti-Virus\n- Norton Personal Firewall\n- Norton Privacy Control\n- Norton Parental Control\n- Norton Spam Alert\nGIGABYTE Windows Utility Manager\nAdobe Acrobat Reader
Ombord grafikkort:	Nej
Uttag för mikrofon/linje in:	Ja
Parallellport:	1
Ljudchipp:	REALTEK ALC655
Stöd för parallellprocessteknik:	Stöds inte
S/PDIF ut anslutning:	Ja
Antal COM portar:	2
Stöd för processorsystembussar:	533,800 MHz
PCI-kortplatser:	5
Antalet parallella ATA-anslutningar:	2
CD/AUX ljudingång:	Ja
Anslutning för diskettenhet:	Ja
GAME/MIDI anslutning:	Ja
S/PDIF in-kontakt:	Ja
AGP x8 kortplatser:	1
