Thank you for purchasing a GIGABYTE Chassis. GIGABYTE is

dedicated to the integration of water/air-cooling chassis solutions to

provide users with the most optimal solution for thermal dissipation.

For further information and specifications of the “SUMO” series,

please visit GIGABYTE website. (http://www.gigabyte.com.tw)

The following is not covered by warranty:

1. Using the product incorrectly or in a manner other than its designed purpose.

2. Nonobservance of its proper operation as provided in documentation.

3. Malfunction due to interference from other devices.

4. Unapproved modification of the product.

5. Consequential damage to other object due to the product’s fault.

6. Malfunction arising from natural hazards, e.g. earthquake, lightning, fire, and floods.

7. Warranty void if label has been removed or tampered with.

8. The devices inside, including power supply, hard disk, CD-ROM drive, motherboard, ventilator, etc, are not

detached from the casing prior to transportation of the computer system, resulting in damage to the casing

or other computer-related devices.

9. Any loss/damage caused by failure to follow the installation process with in the user manual.

Failure to wear gloves during installation of computer products may cause bodily harm or damage to your devices. Incorrect connector

installation may possibly burn out the motherboard and other components. Be sure to observe the instructions in the installation

manual.

English

Content

1. Components Introduction 04

1-1 Casing’s Internal Structure 04

1-2 Casing’s Panel Structure 05

1-3 Removal of Side and Front Panels 05

2. Features 06

3. Specifications 07

4. Installation Instruction 08

4-1 Installation of Power Supply 08

4-2 Installation of Motherboard 08

4-3 Installation of Add-On card 08

4-4 Installation of Front Multi-Media I/O Ports 09

4-5 Connection of Fan Power Cable 10

4-6 Installation of 5.25” Front Device Bay 10

4-7 Installation of 3.5” Front Device Bay 10

4-8 Installation of 3.5” Internal Device Bay 10

4-9 Application of Removable/Dual Directional HDD Rack 11

4-10 Installation of 2.5” Enclosure 11

4-11 Application of DIY inter changeable LED lighting 11

4-12 Application of Security locks 11

4-13 Application of Foot Support 12

4-14 Application of Liquid Cooling System 12

4-15 Recommended GIGABYTE Thermal Solution products 12

English

Produktspecifikationer

Varumärke:	Gigabyte
Kategori:	dator box
Modell:	Sumo 5112
Vikt:	12100 g
Bredd:	205 mm
Djup:	560 mm
Höjd:	522 mm
Ljudutgång:	Ja
Material:	Aluminium, SECC
Modell:	PC
Expansionsplatser:	7
Fjärrkontroll ingår:	Nej
Produktens färg:	Svart
Formfaktor:	Full Tower
På / av-knapp:	Ja
Antal USB 2.0 anslutningar:	2
Ljudanslutning:	Ja
Antal eSATA portar:	1
Som stöds moderkorts formfaktorer:	ATX, CEB, EATX, Micro ATX
Anta IEEE 1394/Firewire anslutningar:	1
Externa expansionsfack:	1x 3.5", 4x 5.25"
Interna expansionsfack:	5x 3.5"
Ventilationsfläkt:	3x 120mm, 2x 80mm
