Installation and

Operating Instructions

Built-In Loudspeaker

1258 00

Device description

With the built-in loudspeaker, the Gira Door

Communication System is integrated in let-

terbox systems, speech compartments, door

side installations or front panels. The built-in

loudspeaker assumes the function of a door

station. It has two mounting openings which

are matched to the mounting systems of

common installation solutions.

Up to 8 mechanical bell buttons can be con-

nected to the built-in loudspeaker. Addi-

tional bell buttons can be connected via add-

on modules. It is possible to connect up to

11 add-on modules with 12 bell buttons

each. With these door communication sys-

tems with up to 70 audio devices can be

realised, e.g.

1 Audio control device

1 Built-in speaker with

5 Add-on modules

68 Surface-mounted, hands-free feature

home stations

Number of devices

The Gira door communication system is

designed for the following numbers of

devices:

Audio: 70 devices, Video: 20 devices.

Device presentation

Front

1 Loudspeaker

2 Mounting opening

3 Microphone

Back

4 Interfaces

System: Connection for add-on module

or other system components

Video: Connection of the UP colour

camera

5 Terminal strip

BUS: Connection to the 2-wire bus

ZV: Supply of UP colour camera etc.

0: Common earth for bell buttons

1 - 8: Connection for bell buttons

Produktspecifikationer

Varumärke:	Gira
Kategori:	Intercomsystem
Modell:	125800
Produkttyp:	Högtalarmodul
Bredd:	101 mm
Djup:	27 mm
Höjd:	67 mm
Produktens färg:	Brun
Temperatur vid drift:	-25 - 70 ° C
Monteringssätt:	Yta
Brand kompatibilitet:	GIRA
