Sida 1/2
2153 Dryden Rd., Dayton, OH 45439 937-299-5493 800-347-5423 Fax: 937-299-4147 www.globefoodequip.com | | | |
GLOBE FOOD EQUIPMENT COMPANY
Project Name: AIA#:
Model #: Location:
Item #: Quantity:
12/19/2023 Printed in the U.S. © Globe Food Equipment Company Specifications are subject to change without notice.
Approved by: Date:
Globe® 60 Quart Planetary Floor Mixer SP62P-4
Model
o SP62P-4
Standard Features
• Powerful 3 HP fixed speed custom built motor
• Direct gear-driven, high-torque transmission
• Heat-treated hardened steel alloy gears and shafts
• Four fixed speeds
• Handles up to 50 lbs. of flour (80 lb. batch size)
• Safety interlocked power bowl lift
• Permanently lubricated oil bath transmission
• Thermal overload protection
• Front-mounted touch pad controls with 60-minute
digital timer and last-batch recall
• Stainless steel, interlocking bowl guard with built-in,
fully welded ingredient chute
• Heavy duty bowl truck (pictured)
• Rigid cast iron body
• Industry standard #12 attachment hub
• NSF approved enamel gray paint
• 6-foot cord and ground plug
• Auto shut off, for improved protection of motor and
transmission protection
Standard Accessories/Attachments
• 60 qt. stainless steel bowl (#304 series)
• Aluminum spiral dough hook, flat beater and stainless
steel whip
• Non-slip rubber feet
• Bowl truck
Warranty
• Two years parts and labor
Optional Attachments/Accessories
• Seismic flange kit
• Slicer/shredder/grater for #12 hub
• Meat grinder for #12 hub
• Meat tenderizer for #12 hub
• Strip cutter for #12 hub
• Bowl Scraper
• Additional bowl truck
• Correctional package
• Extended warranty
To select options see back
Enhanced to handle a
variety of mixes!
Utilizing 4 speeds, operator-friendly power bowl
lift and front-mounted touch pad control panel
with digital timer and heavy duty transmission.
60 Quart Planetary Floor
Mixer with Power Bowl Lift
2153 Dryden Rd., Dayton, OH 45439 937-299-5493 800-347-5423 Fax: 937-299-4147 www.globefoodequip.com | | | |
12/19/2023 Printed in the U.S. © Globe Food Equipment Company Specifications are subject to change without notice.
60 Quart Planetary Floor Mixer SP62P-4
DIMENSIONS | SHIPPING INFORMATION
Reinforced carton for shipping. The weight and dimensions of this reinforced carton are included below and may vary from shipment to shipment.
This product ships on a pallet. Freight class 85.
Model Overall Dimensions Net Weight Shipping Dimensions Shipping Weight
SP62P-4
30.25" W x 41.6" D x 60" H
(76.83 cm x 105.66 cm x 152.4 cm)
980 lbs
(444 kg)
48'' W x 48'' D x 76'' H
(122 cm x 122 cm x 193 cm)
1,228 lbs
(556 kg)
Mixer is constructed of a rigid cast iron body with front-mounted controls, and 60-minute digital timer. Mixer has 3 HP custom built motor with
overload protection and direct gear-driven, high torque permanently lubricated 4 speed transmission consisting of heat-treated hardened steel
alloy gears and shafts. Mixer comes with 60 qt. stainless steel bowl, aluminum bowl truck and stainless steel wire whip, aluminum dough hook
and non-slip rubber feet. Interlocked with stainless steel bowl guard with fully welded ingredient chute. Mixer has #12 attachment hub and
interlocked power bowl lift. Mixer is NSF and ETL listed. Two-year parts and labor warranty.
OPTIONAL MIXER ACCESSORIES AND HUB ATTACHMENTS
MIXER:
XXSEISMIC KIT-LG Seismic kit
60 qt. stainless steel XXBOWL-62
(S/S) bowl
XXBEAT-62 Alum. flat beater
XXHOOK-62 Alum. dough hook
S/S wire whipXXWHIP-62
XBTRUCK-62 Heavy-duty bowl truck
HUB:
o
XVSGH 9" Slicer/Shredder/Grater
housing only (no plates included-must
select from plates listed on this sheet)
Adjustable slicing plate XASP
(for vegetables only)
Plate holder XPH
Meat Tenderizer attachmentL00670
L00783 Strip Cutter attachment
Shredding Plates:
3/32" (2.3 mm) XSP332*
XSP316* 3/16" (4.7 mm)
1/4" (6.3 mm)XSP14*
XSP516* 5/16" (7.9 mm)
1/2" (12.7 mm)XSP12*
Grating plate XGP*
*Only 1 plate holder required
XMCA-SS Meat grinder assembly
(Polished stainless steel cylinder, worm
gear, ring, and s/s pan. Includes knife,
3/16" plate, and pusher.)
XXCK Chopper knife for XMCA-SS
Chopper Plate Sizes Available:
CP02-12 1/16" (2 mm)
5/32" (4 mm)CP04-12
CP05-12 3/16" (5 mm)
1/4" (6 mm)CP06-12
5/16" (8 mm)CP08-12
CP10-12 3/8" (10 mm)
CP12-12 1/2" (12 mm)
CP14-12 9/16" (14 mm)
CP16-12 5/8" (16 mm)
CP18-12 11/16" (18 mm)
CP00-12 Stuffing plate
1/2" Stuffing tube (mutton)XST12
3/4" Stuffing tube (pork)XST34
o
FACTORY INSTALLED OPTION:
XXCORR-62 Correctional package,
includes tamper resistant external
fasteners.
o
EXTENDED WARRANTY
SP-XDSPL Extended warranty for
SP62P mixer, extends factory warranty
to 3-years. Available only at time
of purchase.
38.6 (98)
60 (152.4)
30.25 (76.8)
3.0 (8)
SPECIFICATIONS
Model Motor Volts Amps Transmission Type Capacity Controls
Power
Bowl Lift
Agitator Speeds (RPMs) Attachment Speeds (RPMs)
First Second First Second
SP62P-4
(1 Phase)
3 HP 220/60/1 18 Gear 60 qt / 57 liter
Digital,
front
mounted
timer and
controls
1/8 HP
Motor
60 105 67 118
SP62P-4
(3 Phase)
3 HP 208/60/3 12 Gear 60 qt / 57 liter
Third Fourth Third Fourth
176 310 198 349
Cord & Plug: Attached 6-foot exible 3-wire cord with molded plug ts a grounded receptacle. Single phase NEMA L6-30P Three phase NEMA L15-20P
*Specify voltage when ordering.
