Sida 1/2
2153 Dryden Rd., Dayton, OH 45439 937-299-5493 800-347-5423 Fax: 937-299-4147 www.globefoodequip.com | | | |
GLOBE FOOD EQUIPMENT COMPANY
Project Name: AIA#:
Model #: Location:
Item #: Quantity:
12/19/2023 Printed in the U.S. © Globe Food Equipment Company Specifications are subject to change without notice.
Approved by: Date:
Globe® 80 Quart Planetary Floor Mixer SPC80PL
Model
o SPC80PL
Standard Features
• Powerful 3 HP custom built motor
• Gear-driven, high-torque transmission
• Heat-treated hardened steel alloy gears & shafts
• Four fixed speeds
• Oil bath transmission
• Thermal overload protection
• Front-mounted touch pad controls with 60-minute
digital timer and last-batch recall
• Stainless steel, interlocking bowl guard with built-in
fully welded ingredient chute
• Heavy duty bowl truck (pictured)
• Power bowl lift
• Rigid cast iron body
• Industry standard #12 attachment hub
• NSF approved enamel gray paint
• 6-foot cord and ground plug
• Automatic safety shut off, provides superior motor and
transmission protection
Standard Accessories/Attachments
• 80 qt. stainless steel bowl (#304 series)
• Aluminum flat beater
• Stainless steel wire whip
• Aluminum spiral dough hook
• Non-slip rubber feet
• Bowl truck
Warranty
• Two years parts and labor
Optional Attachments/Accessories
• Seismic flange kit
• Vegetable slicer for #12 hub
• Shredder/grater for #12 hub
• Meat grinder for #12 hub
• Meat tenderizer for #12 hub
• Strip cutter for #12 hub
• Aileron (wing) whip
• 40-qt. adapter kit
• 60-qt. adapter kit
• Bowl scraper
• Correctional package
To select options, see complete list on back
The Perfect Mix of Value,
Performance & Durability
Features front mounted touch pad control
panel with 60-minute digital timer!
80 Quart Planetary Floor
Mixer
2153 Dryden Rd., Dayton, OH 45439 937-299-5493 800-347-5423 Fax: 937-299-4147 www.globefoodequip.com | | | |
12/19/2023 Printed in the U.S. © Globe Food Equipment Company Specifications are subject to change without notice.
80 Quart Planetary Floor Mixer SPC80PL
DIMENSIONS | SHIPPING INFORMATION
Cartons are reinforced for shipping. The weight and dimensions of this reinforced carton are included below and may vary from shipment to shipment.
This product ships on a pallet. Freight class 85.
Model Base Foot Print Overall Dimensions Net Weight Shipping Dimensions Shipping Weight
SPC80PL
30.25'' W x 36.5 D
(77 cm x 93 cm)
30.25'' W x 38.6" D x 62'' H
(77 cm x 98 cm x 156 cm)
1,003 lbs
(455 kg)
48'' W x 48'' D x 76'' H
(122 cm x 122 cm x 193 cm)
1,270 lbs
(575 kg)
SPECIFICATIONS
Model Motor Volts Amps
Transmission
Type
Capacity Controls
Power
Bowl
Lift First Second
First Second
SPC80PL
(3 Phase)
3 HP 208/60/3 12 Gear
80 qt
75.7 liter
Digital, front
mounted
timer &
controls
1/8 HP
Motor
60 105 67 118
Third Fourth Third Fourth
176 310 198 349
Agitator Speeds (RPMs) Attachment Speeds (RPMs)
Mixer is constructed of a rigid cast iron body with front-mounted touch and 60-minute digital timer with last-batch recall. Mixer has 3 HP custom
built motor with overload protection and gear-driven, high torque permanently lubricated transmission consisting of heat-treated hardened steel
alloy gears and shafts. Mixer comes with 80 qt. stainless steel bowl, aluminum flat beater, stainless steel wire whip, bowl truck, aluminum spiral
dough hook and non-slip rubber feet. Interlocked with stainless steel bowl guard with fully welded ingredient chute. Mixer has #12 attachment
hub and interlocked bowl lift. Mixer is NSF and ETL listed. Two-year parts and labor warranty.
OPTIONAL MIXER ACCESSORIES AND HUB ATTACHMENTS
MIXER:
XXSEISMIC KIT-LG Seismic kit
80 qt stainless XXBOWL-80
steel (S/S) bowl
XXBEAT-80 Alum. flat beater
XXBEAT-80SS S/S flat beater
XXHOOK-80 Alum. dough hook
S/S wire whipXXWHIP-80
Heavy-duty 4 mm XXHDWHIP80-4
S/S wire whip
XXAWHIP-80 80 qt aileron whip
scraper with mounting kitXXSCRP-80
Adapter kit - 40 qt XXACC40-80
bowl, hook, beater and whip
Adapter kit - 60 qt XXACC60-80
bowl, hook, beater and whip
HUB:
9" Slicer/Shredder/Grater XVSGH
housing only (no plates included-must
select from plates listed on this sheet)
Adjustable slicing plate XASP
(for vegetables only)
Plate holder -*only 1 requiredXPH
Meat Tenderizer attachmentL00670
L00783 Strip Cutter attachment
Shredding Plates:
3/32" (2.3 mm) XSP332*
XSP316* 3/16" (4.7 mm)
1/4" (6.3 mm)XSP14*
XSP516* 5/16" (7.9 mm)
1/2" (12.7 mm)XSP12*
Grating plateXGP*
XMCA-SS Meat grinder assembly
(Polished stainless steel cylinder, worm
gear, ring, and s/s pan. Includes knife,
3/16" plate, and pusher)
XXCK Chopper knife for XMCA-SS
Chopper Plate Sizes Available:
CP02-12 1/16" (2 mm)
5/32" (4 mm)CP04-12
CP05-12 3/16" (5 mm)
1/4" (6 mm)CP06-12
5/16" (8 mm)CP08-12
CP10-12 3/8" (10 mm)
CP12-12 1/2" (12 mm)
CP14-12 9/16" (14 mm)
CP16-12 5/8" (16 mm)
CP18-12 11/16" (18 mm)
CP00-12 Stuffing plate
1/2" Stuffing tube (mutton)XST12
3/4" Stuffing tube (pork)XST34
FACTORY INSTALLED OPTION:
XXCORR-80 Correctional package,
includes tamper resistant external
fasteners.
Drawings available through KCL at www.kclcad.com.
