Sida 1/8
1
INSTRUCTIONS FOR OPERATION AND CARE
XVSGH GRATER/SHREDDER HOUSING
AND ATTACHMENTS
Our slicer attachments can be used for slicing potatoes (from 1/16''
to 5/8'' thickness); cutting vegetables for salads and coleslaw; or for
slicing fruits and nuts. An adjustable slicer plate with shaft are included
with the XVSGH attachment.
Our versatile grater/shredder attachments can be used to grate and shred cheeses, raw
vegetables, nuts, breadcrumbs, etc. depending on the plate or disc selected. Our S/S discs
are available with 3/32'', 3/16'', 1/4'', 5/16'', or 1/2'' size holes and a special grating disc for
breadcrumbs & hard cheeses is available. A plate holder with shaft and one 3/16'' plate are
included with the XVSGH attachment.
WARNING
There are sharp rotating knives behind the door; keep hands out of
hopper and use a pusher plate or stomper to push product into the
hopper — do not use your fingers. Always stop power unit before
opening front for changing, cleaning, or servicing anything on this
unit. Only trained and qualified persons 18 years and older should
use these attachments.
XVSGH
The XVSGH is made up of the following three basic components:
1. XVSH Housing
2. XVSD Door or Hopper
3. XVSP Pusher Plate
Plate Holder or Adjustable Slicer Plate units
• XASP Adjustable Slicer Shaft with S/S “S” knife
• XPH Plate Holder with Shaft
PLATE HOLDER WITH SHAFT
Shredder discs are available with 3/32'', 3/16'', 1/4'', 5/16'', or 1/2'' hole sizes. These
plates have keyhole slots for attaching to shouldered studs on the plate hubs.
DOOR OR HOPPER
The door is a hopper and lever feed design. It hinges onto the back case and is held
closed with an adjustable latch. To remove door, lift latch and swing door open while
lifting it from the hinge holes.
PUSHER PLATE
The pusher plate has an integrated handle to push the food into the rotating disc or
slicer knife. It has pins at both sides of the top and hinges into door. The pusher plate
has a rubber-tipped stop screw under the handle that can be adjusted to prevent the
pusher plate from coming in contact with the disc or blade.
HOUSING OR BACK CASE
The housing or back case mounts into the attachment socket of a mixer, food cutter or
power drive unit. The housing is held on with the pointed thumbscrew that goes through
the attachment hole into the indentation on neck of the machine.
ADJUSTABLE SLICER PLATE WITH STAINLESS STEEL “S” KNIFE AND SHAFT
Stainless steel “S” knife is ideal for slicing vegetables.
1. XVSH
2. XVSD
3. XVSP
XASP
XPH
