Sida 1/15

说明手册

Instruction Manual

705-XPRZS0-00

Made In China

地址/Add: 深圳市宝安区福永镇福洲大道西新和村华发工业园A4栋

Building A4, Xinhe Huafa Industrial Zone, Fuzhou RD West, Fuyong

Town, Baoan District, Shenzhen 518103, China

电话/Tel: +86-755-29609320(8062) Fax: +86-755-25723423传真/

邮箱/E-mail: godox@godox.com

深圳市神牛摄影器材有限公司

GODOX Photo Equipment Co., Ltd.

TTL

无线引闪器

TTL Wireless Flash Trigger

Foreword

Warning

Names of Parts

Body

LCD Panel

Battery

Installing Batteries

Battery Level Indication

Using the Flash Trigger

As a Wireless Camera Flash Trigger

As a Wireless Outdoor Flash Trigger

As a Wireless Original Flash Trigger

As a Wireless Studio Flash Trigger

As a Wireless Shutter Release Trigger

As a Flash Trigger

with 2.5mm Sync Cord Jack

Setting the Flash Trigger

Power Switch

Automatically Enter Power Saving Mode

Power Switch of AF Assist Beam

Channel Settings

Wireless ID Settings

Mode Settings

Magnification Function

Output Value Settings

Flash Exposure Compensation

Settings

Multi Flash Settings

(Output Value, Times

and Frequency)

Modeling Lamp Settings

ZOOM Value Settings

Shutter Sync Settings

Buzz Settings

Sync Socket Settings

TCM Function

SHOOT Function Settings

C.Fn: Setting Custom Functions

Compatible Flash Models

Compatible Camera Models

Technical Data

Restore Factory Settings

Firmware Upgrade

Attentions

Caring for Flash Trigger

Contents

Foreword

Thanks for your purchase of this XProS wireless flash trigger.

This wireless flash trigger is suitable for using Sony cameras to control Godox flashes

with X system e.g. camera flash, outdoor flash, and studio flash. It can also control

Sony original speedlights with the coordination of X1R-S receiver. Featuring multi-

channel triggering, stable signal transmission, and sensitive reaction, it gives

photographers unparalleled flexibility and control over their strobist setups. The flash

trigger applies to hotshoe-mounted Sony series cameras, as well as the cameras

which have PC sync sockets.

With XProS wireless flash trigger, high speed synchronization is available for most of

camera flashes in the market which support TTL. The max flash synchronization speed

is up to 1/8000s *.

*: 1/8000s is achievable when the camera has a max camera shutter speed of 1/8000s.

- 23 - - 24 -

Warning

Do not disassemble. Should repairs become necessary, this product must be sent to

an authorized maintenance center.

Always keep this product dry. Do not use in rain or in damp conditions.

Keep out of reach of children.

Do not use the flash unit in the presence of flammable gas. In certain circumstance,

please pay attention to the relevant warnings.

Do not leave or store the product if the ambient temperature reads over 50℃.

Turn off the flash trigger immediately in the event of malfunction.

Observe precautions when handling batteries

- Use only batteries listed in this manual. Do not use old and new batteries or

batteries of different types at the same time.

- Read and follow all warnings and instructions provided by the manufacturer.

- Batteries cannot be short-circuited or disassembled.

- Do not put batteries into a fire or apply direct heat to them.

- Do not attempt to insert batteries upside down or backwards.

- Batteries are prone to leakage when fully discharged. To avoid damage to the

product, be sure to remove batteries when the product is not used for a long time or

when batteries run out of charge.

- Should liquid from the batteries come into contact with skin or clothing, rinse

immediately with fresh water.

Names of Parts

Body

Power Switch

--ON (Power On)

--OFF (Power Off)

AF Assist Beam Switch

--ON (AF Assist Beam outputs)

--OFF (AF Assist Beam

do not output)

Battery Compartment

Hot Shoe Camera Connection

LCD Panel

Status Indicator Lamp

--Green:

Trigger (Flash) +

Focus (Camera)

--Red:

Trigger (Flash) +

Shutter (Camera)

Group Button 1

Group Button 2

Group Button 3

Group Button 4

Group Button 5

Function Button 2

Function Button1

Function Button 3

Function Button 4

MODE/LOCK Mode Selection/

Locking Button

TEST/Shutter Button

MENU Button

Magnification/TCM Button

Select Dial

2.5mm Sync

Cord Jack

Type-C USB

Port

AF-assist Lamp

- 25 - - 26 -

Produktspecifikationer

Varumärke:	Godox
Kategori:	Fjärrutlösare
Modell:	XPro
Vikt:	90 g
Bredd:	50 mm
Djup:	58 mm
Höjd:	90 mm
Frekvensband:	2.4 GHz
Batteriteknik:	Alkalisk
Batterityp:	AA
Antal batterier:	2
Produktens färg:	Svart
Brand kompatibilitet:	Nikon
