Sida 1/51

GXV3651_FHD User Manual www.grandstream.com
Firmware Version 1.0.1.68 http://esupport.grandstream.com
Grandstream Networks, Inc.
GXV3651_FHD

GXV3651_FHD User Manual www.grandstream.com
Firmware Version 1.0.1.68 http://esupport.grandstream.com
T C ABLE OF ONTENTS
GXV3651_FHD User Manual
WELCOME ................................................................................................................................................ 4
S CAFETY OMPLIANCES .............................................................................................................................. 5
WARRANTY ............................................................................................................................................... 7
PACKAGE CONTENTS ............................................................................................................................ 8
E P CQUIPMENT ACKAGE ONTENTS .............................................................................................................. 8
PRODUCT OVERVIEW ............................................................................................................................. 9
GXV3651_FHD SIDE VIEW .................. .................................... ..................................... ............................ 9
GXV3651_FHD BACK PANEL .................................................................................................................. 10
GXV3651_FHD SAMPLE CONNECTION DIAGRAM ..................................................................................... 11
GXV3651_FHD KEY FEATURES .............................................................................................................. 12
GXV3651_FHD LENS SPECIFICATION ..................................................................................................... 13
INSTALLATION GUIDE ...........................................................................................................................14
CONNECT YOUR GXV3651_FHD ............................................................................................................. 14
C W BONFIGURING THE GXV3651_FHD VIA EB ROWSER ............................................................................ 15
GXV3651_FHD HOME WEB PAGE .......................................................................................................... 18
GXV3651_FHD CONFIGURATION & LANGUAGE PAGE ....... ......................................... ............................... 19
BASIC SETTINGS EXPLANATION .........................................................................................................20
S S PYSTEM ETTINGS AGE ......................................................................................................................... 20
V & A S PIDEO UDIO ETTING AGE ................................................................................................................ 21
CMOS SETTINGS PAGE .......................................................................................................................... 23
W SI-FI ETTINGS PAGE ............................................................................................................................. 24
N S PETWORKING ETTING AGE ................................................................................................................... 25
DDNS SETTINGS PAGE ........................................................................................................................... 26
SIP SETTING PAGE ................................................................................................................................. 27
S PTATUS AGE ......................................................................................................................................... 29
ADVANCED SETTINGS EXPLANATION ................................................................................................30
U M PSER ANAGEMENT AGE ...................................................................................................................... 30
M PAINTENANCE AGE ............................................................................................................................... 31
SMTP SETTING PAGE (EMAIL ALARM) ...................................................................................................... 32
FTP SETTINGS PAGE (UPLOAD ALARM) .................................................................................................... 33
PTZ S PETTINGS AGE .............................................................................................................................. 34
CONNECT A PTZ DEVICE TO THE GXV3651_FHD ..................................................................................... 35
A S S P ALARM ERVER ETTINGS AGE (UPLOAD LARM TO SUPPORTED VMS OR HTTP SERVER) ....................... 36
A E P LARM VENT AGE................................................................................................................................ 37
C A I EONNECT LARM NPUT QUIPMENT TO THE GXV3651_FHD .................................................................... 38
S A AETUP LARM CTIONS ........................................................................................................................... 38
S A E T SETUP LARM VENT IME CHEDULE ..................................................................................................... 39
H A O EOW TO CONNECT AN LARM UTPUT QUIPMENT TO GXV3651_FHD ....................... ............................... 40
M D C P AOTION ETECTION ONFIGURATION AGE (SET LARM) ................ ........................... ............................ ... 41
S S PYSLOG ETTINGS AGE (TROUBLESHOOTING) ......................................................................................... 43
L S S P C F MIVE TORAGE ETTING AGE (SD ARD ILE ANAGEMENT) ................................................................... 44
SOFTWARE UPGRADE ...........................................................................................................................45
S UOFTWARE PGRADE VIA TTFP, HTTP OR HTTPS .................................................................................. 45
INSTRUCTIONS FOR LOCAL FIRMWARE UPGRADE USING TFTP SERVER: ....................................................... 46
C F DONFIGURATION ILE OWNLOAD ............................................................................................................ 46
RESTORE FACTORY DEFAULT SETTING ............................................................................................47
FACTORY RESET ................................................................................................................................ 47
R B RESET UTTON (HARD ESET) ................................................................................................................ 47
R W I RESET FROM EB NTERFACE (SOFT ESET) ............... ............................ ........................... ...................... 47
IP VIDEO SURVEILLANCE FAQ .............................................................................................................48

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 3 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
T FABLE OF IGURES
GXV3651_FHD USER MANUAL
FIGURE 1 S IDE VIEW ........................................................................................................................................................... 9
FIGURE 2 B ACK PANEL VIEW ............................................................................................................................................ 10
FIGURE 3 C ONNECTION DIAGRAM .................................................................................................................................... 11
FIGURE 4 H P OME AGE OF GXV3651_FHD ...................................................................................................................... 18
FIGURE 5 S S P YSTEM ETTINGS AGE ................................................................................................................................... 20
FIGURE 6 V & IDEO A S PUDIO ETTINGS AGE...................................................................................................................... 21
FIGURE 7 V & IDEO A S PUDIO ETTINGS AGE...................................................................................................................... 22
FIGURE 8 S P CMOS ETTINGS AGE ..................................................................................................................................... 23
FIGURE 9 W N S P I-FI ETWORKING ETTING AGE ................................................................................................................. 24
FIGURE 10 NETWORK S PETTING AGE ............................................................................................................................... 25
FIGURE 11 DDNS SETTING PAGE ..................................................................................................................................... 26
FIGURE 12 SIP SETTING PAGE .......................................................................................................................................... 27
FIGURE 13 STATUS PAGE .................................................................................................................................................. 29
FIGURE 14 USER MANAGEMENT PAGE ............................................................................................................................. 30
FIGURE 15 MAINTENANCE PAGE ...................................................................................................................................... 31
FIGURE 16 SMTP SETTING PAGE ..................................................................................................................................... 32
FIGURE 17 FTP SETTING PAGE ......................................................................................................................................... 33
FIGURE 18 PTZ SETTING PAGE ......................................................................................................................................... 34
FIGURE 19 PTZ CONNECTION ........................................................................................................................................... 35
FIGURE 20 ALARM HTTP SERVER SETTING PAGE ........................................................................................................... 36
FIGURE 21 ALARM EVENT AGESETTING P ........................................................................................................................ 37
FIGURE 22 ALARM OUTPUT CONNECTION ........................................................................................................................ 40
FIGURE 23 MOTION DETECTION CONFIGURATION PAGE ................................................................................................. 41
FIGURE 24 MOTION DETECTION SCHEDULE CONFIGURATION PAGE ............................................................................... 42
FIGURE 25 SYSLOG CONFIGURATION PAGE ..................................................................................................................... 43
FIGURE 26 LIVE STORAGE M PANAGEMENT AGE ............................................................................................................. 44
FIGURE 27 FIRMWARE UPGRADE AND PROVISIONING ..................................................................................................... 45
FIGURE 28 FACTORY RESET FROM WEB INTERFACE ........................................................................................................ 47

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 4 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
W ELCOME
The GXV3651_FHD is a next generation IP camera for remote monitoring and surveillance over your
LAN or Internet.
The GXV3651_FHD combines best in class IP video technology and SIP protocols for a robust IP
surveillance solution. The product features H.264 video streams with up to 30 frames per second at 1080p
resolution, delivering rich image clarity at rapid transmission rates. Integrated SIP can pass alarms to the
PSTN, mobile phones, SIP IP phones, SIP videophones and enables 2-way VoIP communication.
The GXV3651_FHD ensures ease of use, integration and deployment with a multilingual graphical user
interface. The GXV3651_FHD can be quickly installed and connected to your network and accessed from
anywhere over the internet. Grandstream’s flexible video management software enables users to monitor
multiple environments in one easy to use application. The intuitive web interface lets users easily access,
manage, view and record live video streams from the device.
The GXV3651_FHD is a powerful solution for small to medium sized offices, homes and storage facilities
looking to safeguard their valuables.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 5 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Safety Compliances
These instructions are intended to assist users with the operation of the GXV3651_FHD and also to
instruct on how to avoid dangerous situations or damage to the device.
Warnings: Serious injury or death may be caused if any of the warnings below are neglected.
Cautions: Injury or damage to the equipment may occur if any of the following caution messages
are neglected.
Warnings Follow these safeguards to prevent
serious injury or death.
Cautions Follow these precautions to
prevent potential injury or material
damage.
Warnings:
Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source
with DC 12V according to the IEC60950-1 standard. Please refer to the technical specifications for
more details.
Do not use a third-party power adapter or power cord
When the device is installed on the wall or ceiling, make sure that it is firmly attached.
Notice:
Make sure that the power supply voltage is correct before using the camera. Do not drop the device or
expose it to physical shock.
Do not expose the device to temperatures outside the range of -30 ºC to +50 ºC. PSU and PoE mode
when the device is in operation.
Do not expose the device to high electromagnetism radiation.
To avoid heat accumulation, make sure that your operating environment has proper ventilation.
Do not attempt to open, disassemble, or modify the device
A few parts (e.g. electrolytic capacitor) of the equipment shall be replaced regularly according to their
average life time. The average life time varies from the differences between operating environments and
usage history. Regular maintenance checks are recommended for all users. Please contact your dealer
for more details.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 6 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Note:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 7 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Warranty
If you purchased your GXV3651_FHD from a reseller, please contact the company where you purchased
your device for replacement, repair or refund.
If you purchased the product directly from Grandstream, please contact your Grandstream Sales and
Service Representative for a RMA (Return Materials Authorization) number before you return the
product. Grandstream reserves the right to remedy warranty policy without prior notification.
Caution:
Changes or modifications to this product not expressly approved by Grandstream, or operation of this
product in any way other than as detailed by this User Manual, could void your manufacturer warranty.
Please do not use a different power adaptor with the GXV3651_FHD as it may cause damage to the
products and void the manufacturer warranty.
This document is subject to change without notice. The latest electronic version of this user manual
is available for download at:
http://www.grandstream.com/products/surveillance/gxv3651/documents/gxv3651_fhd_user
manual.pdf
Reproduction or transmittal of the entire or any part, in any form or by any means, electronic or print, for
any purpose is not permitted without the express written permission of Grandstream Networks, Inc.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 8 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
P C ACKAGE ONTENTS
Equipment Package Contents
The GXV3651_FHD package contains:
GXV3651_FHD IP Camera
12V DC power Adapter
6-pin terminal block connector – 6-pin connector block for connecting external devices, such as
infrared detector, smoke detector and etc., to Alarm IN, Alarm OUT and RS485 pins.
Quick installation guide

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 9 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
P O RODUCT VERVIEW
GXV3651_FHD Side View
Figure 1 Side view
Note: The above shown is an 3rd party optional Auto Iris Lens (Not Supplied)

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 10 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
GXV3651_FHD Back Panel
Indicators and Connectors on Back Panel
Figure 2 Back panel view
NETWORK: 10/100 Switch LAN port for connecting to Ethernet. The indicator will
be steady for connection and flashing for network activity.
AUDIO IN: 3.5mm port for audio input devices (Microphone, pickup and etc.).
AUDIO OUT: 3.5mm port for audio output devices (speakers, and etc.).
VOUT: 1 BNC (Voltage: 1.0V p-p, Resistance75Ω) port for video output.
DC 12V: 12V DC power jack; UL Certified.
SD/MMC: SD card slot.
RESET: Press the Reset button for 10 seconds to perform a factory reset.
PINs: 1 PTZ connector, Alarm In connector, and Alarm out connector.
USB: USB connector for USB flash/hard drives.
POWER: The indicator will be solid green if the power is on.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 11 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
GXV3651_FHD Sample Connection Diagram
Figure 3 Connection diagram

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 12 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
GXV3651_FHD Key Features
Thetablebelowliststhekeyfeaturesthe GXV3651_FHD Supports.
Table 1: GXV3651_FHD Technical Specifications
Image Sensor
1/2.5”, 5-Megapixel CMOS, 2592x1944 (pixels),
exceptionally low noise levels and low-light sensitivity for
superior video quality at very high resolution (1080p)
Lens Type ½”, 4.5-10mm, Manual-Iris, CS
Day & Night Electronic, with integrated IR_CUT and light sensor
Responsitivity 1.4V/lux-sec (550nm)
V
ideo Resolution 15fps at 2048x1536; 30fps for 1920x1080,
1600x1200, 1280x960, 1280x720, 1024x768, 800x592,
800x480, 640x480, 640x368, 480x368, 480x272, 320x240,
320x176, 256x192 and 256x144
Pixel Dynamic Range 70.1dB, with SNRMAX 38.1dB (full resolution)
Max Frame Rate in Max Resolution 1920x1080 @ 30fps
V
ideo Bit Rate 32 Kbps – 8 Mbps, multi rate for preview and recording
Audio Input LINE-IN, built in microphone
Audio Output LINE-OUT
Audio Compression G.711 U/A, AAC
IRIS Control Manual IRIS (default lens), optional auto-iris lens
Alarm Input Vin≤45V, Iin≤35mA, Normal open
Alarm Output 125VAC/0.5A,30VDC/2A, Normal open
Embedded Analytics Motion detection (up to 16 regions),video loss (pending)
V
ideo Management System ONVIF compliant, HTTP API for advanced integration
Pre-
/
post-alarm Buffe
r
24MB
Pre-/post-alarm triggered record Pre-30s and post-60s recording@2Mbps;
Pre-50s and post-100s recording@1Mbps
Snapshots Triggered upon events, send via email/FTP,
or stored in local SD card
Multi-streaming Preview & Recording Yes
ePTZ Yes (at 320x240 resolution)
Security Login password, access privilege management
Peripheral Ports Internal SDHC 2.0 socket, USB 2.0
Network Port 10M/100M auto-sensing, RJ45
Network Protocol TCP/UDP/IP, RTP, RTSP, DHCP, DDNS, HTTP/HTTPS,
SMTP, FTP, NTP, PPPoE
Power over Ethernet (PoE) IEEE 802.3af default class
SIP/VoIP Support Yes, Voice & Video-over-IP
Dimensions (W x H x L) 152mm x 68mm x 64mm (Lens not included)
Weight 0.51kg (lens not included)
Temperature / Humidity 0°C – 45°C (32°F–113°F)
Humidit
y
10
–
90% RH
(
non
–
condensin
g)
Power Adapter
Output: 12VDC/1A; Input: 100–240VAC, 50–60Hz
Regulatory Compliance FCC Part 15, Subpart B Class B; CE EN 55022 Class B, EN
61000-3-2, EN 61000-3-3, EN 55024, EN 60950-1;
C-tick AS/NZS CISPR 22, CISPR 24

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 13 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
GXV3651_FHD Lens Specification
Parameters GXV3651_FHD
Lens Format 1/2”
Image Sensor 1/2.5” CMOS
Focal Length 4.5mm – 10mm
Aperture Ratio F1.6
View Angle D:102°- 46.5°
H: 80.5°-37°
V: 60°-28°
IRIS Manual
Minimum Object
Distance
10 cm
IR CUT Filter Yes

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 14 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
I G NSTALLATION UIDE
Minimum Recommended System Requirement
To install GXV3651_FHD, you have to have a computer, PC recommend. The minimum recommended
PC system requirement listed below:
Windows 2000, XP, Windows Vista, Windows 7 (32bit or 64bit)
CPU: Intel Pentium 4 or higher, 2 GHz
RAM: 1 GB (4 GB recommended for larger systems)
Support for DirectX 8.0 and above.
.
Connect your GXV3651_FHD
Using the Power adapter as power supply
Connect an RJ-45 cable to the NETWORK port of the GXV3651_FHD.
Connect the other end of the RJ-45 cable to your network or PC.
Connect the power supply to the DC 12V connector block inside the GXV3651_FHD.
Connect the other end of the power supply to a wall outlet. The POWER LED will turn solid
green.
Using PoE as power supply:
Connect an RJ-45 to the NETWORK port of the GXV3651_FHD.
Connect the other end of the RJ-45 cable to a PoE switch. The POWER indicator will turn solid
green.
NOTE:
If you are going to connect the device to a hub/switch/router, please use a straight-through cable.
A crossover cable will be used if you are going to connect the device directly to a PC.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 15 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Configuring the GXV3651_FHD via Web Browser
The GXV3651_FHD‘s embedded Web server responds to HTTP/HTTPS GET/POST requests. Embedded
HTML pages allow you to configure your IP camera through Microsoft Internet Explorer.
Access the GXV3651_FHD Web Configuration Menu
Connect the Camera to a DHCP server.
The GXV3651_FHD by default enabled as DHCP client, it will automatically get IP address from the
network with DHCP server running. User can know the IP address assigned to the camera from DHCP
server log or using Grandstream free GS_Search tool.
1. Download the GS_Search tool from Grandstream website:
http://www.grandstream.com/products/tools/surveillance/gs_search.zip
2. Run the Grandstream GS_Search tool by double click the unzipped “GS_Search.exe”.
3. Click on button to begin device detection
4. The detected devices will appear in the Output field like below
5. Double click the column of the detected camera, the browser will automatically open and link to the
device IP and the web configuration page.
6. The browser will ask for plug-in or ActiveX if not installed, otherwise it will get to Home page and
start to show the video captured by the camera (by default the camera enabled anonymous access)
7. Click “Configuration”, the browser will ask credentials to authorize configuration.
8. Enter the administrator user name and password to access the Web Configuration Interface, the default
user name and password are both set to admin.
9. In step 6, IE will indicate that “This website wants to install the following add-on: GSViewerX.cab
from Grandstream Networks Inc.”, allow the installation.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 16 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
10. Firefox user need to download and install the plug-in to see the video, the plug-in for Firefox is here:
http://www.grandstream.com/products/tools/surveillance/firefox_plugin.exe
NOTE:
Please temporarily disable Antivirus or Internet Security Software when download and install the
Grandstream Firefox plug-in for video or “GSViewerX.cab” for Microsoft Internet Explorer.
Connect to the Camera using Static IP
If no DHCP server in the network or the camera does not get IP from DHCP server, user can connect the
camera to a computer via cross-over cable, using static IP to configure the camera.
The default IP, if no DHCP server; or DHCP offer time out (3 minutes), is 192.168.1.168
1. Connect the computer via cross-over Ethernet cable directly to the IP camera GXV3651_FHD
2. Configure the computer using Static IP: 192.168.1.XXX (1<XXX<255, but NOT 168) and configure
the “Subnet mask” to “255.255.255.0”. Leave the “Default Gateway” to “Blank” like below:
3. Power on the GXV3651_FHD.
4. Start the IE or Firefox browser when the network connection is up.
5. Enter 192.168.1.168 in the address bar of the browser.
6. The browser will ask for plug-in or ActiveX if not installed, otherwise it will get to Home page and
start to show the video captured by the camera (by default the camera enabled anonymous access)
7. Click “Configuration”, the browser will ask credentials to authorize configuration.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 17 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
8. Enter the administrator user name and password to access the Web Configuration Interface, the default
user name and password are both set to admin.
9. In step 6, IE will indicate that “This website wants to install the following add-on: GSViewerX.cab
from Grandstream Networks Inc.”, allow the installation.
10. Firefox user need to download and install the plug-in to see the video, the plug-in for Firefox is here:
http://www.grandstream.com/products/tools/surveillance/firefox_plugin.exe
NOTE:
Please temporarily disable Antivirus or Internet Security Software when download and install the
Grandstream Firefox plug-in for video or “GSViewerX.cab” for Microsoft Internet Explorer.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 18 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
GXV3651_FHD Home Web Page
The Home Page of GXV3651_FHD shown as Figure 4:
Figure 4 Home Page of GXV3651_FHD
1. Control Console: PTZ Console controller for ePTZ function.
2. ZOOM: Zoom in or Zoom out during ePTZ operation.
3. FOCUS: Adjust the focus of image (if equipped with the proper lens).
4. PTZ SPEED/Default Button: Adjust the rotate speed of the control console;
Default button to reset the video brightness, contrast and saturation to
factory default value.
5. BRIGHTNESS: Adjust the image brightness.
6. CONTRAST: Adjust the image contrast.
7. SATURATION: Adjust the image saturation
8. View Size: Adjust the image display size.
9. Configuration: Click to enter “Configuration Page” to configure the parameters of
GXV3651_FHD (Administration privilege required).
10. Language: Click to switch webpage language.
(Current supported: Chinese, English and Russian)
11. Play/Stop: Start/Stop Play the video stream in webpage.
12. Snapshot: Click to capture and save a snapshot of current video displayed.
Default directory: C:\GS_Capture
13. Record: Click to Start/Stop record of current video into a file.
Default directory: C:\GS_Record

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 20 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
B S EASIC ETTINGS XPLANATION
System Settings Page
This page allow user to configure the system settings of GXV3651_FHD.
Figure 5 System Settings Page
Current System Time: Display time current system is running at
Set the System Time: Configure the time system is running.
o Time Zone: Select from pull down menu the time zone unit located
o Self-Defined Time Zone: Use the self-defined time zone for automatic daylight saving time
adjustment. Format please refer to the “help over mouse”
o Update via NTP Server: Synchronize time using NTP protocol with a Time Server
over the Internet cloud (*)
o Synchronize with
Local Computer: Synchronize time with local computer
o Set the Time Manually: Manually input the time
o Keep Current D/T: Select to use camera current displayed time
OSD Date Format: Pull down to select date format displayed on video screen.
Device Setting: Setting of Device Operation
o Device Name: The name of device which will be shown in the result of
GS_Search program.
DI and DO Setting: Setting the state of the Alarm IN / Alarm out Settings
NOTE:
(*) If select this option, a valid DNS server must be configured under Basic Settings
Networking
button has to be clicked to save all the changes made to the device.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 21 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Video & Audio Setting Page
This page allows user to configure the video and audio related settings.
Figure 6 Video & Audio Settings Page
On Screen Display (OSD): Display time stamp and text on the video screen.
o OSD Text: Inputted text (to identify the camera) shown on the screen.
o OSD Position: Show the OSD in either top or bottom position on screen.
o Display Time: When checked, time stamp will display on video screen
o Display Text: When checked, inputted text will display on video screen.
Audio Settings: Pull down to disable or select different audio codec used in microphone.
Three codec supported: G.711u, G.711a and AAC.
o Microphone Volume: Slide to adjust microphone gain.
o Speaker Volume: Slide to adjust the speaker volume.
Power Frequency: Select correct local power frequency to avoid video flicking effect under
fluorescence light condition.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 22 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Figure 7 Video & Audio Settings Page
Primary Stream Settings:
o Preferred Video Codec: H.264 supported.
o Resolution: The video resolution in pixel used in camera video
o Bit Rate: video bit rate used in video
o I-frame Interval: I-frame interval
Secondary Stream Settings: Pull down to select, same as Primary steam.
NOTE:
H.264 suggested if camera needs to be viewed via Internet.
If MJPEG selected, reduce fps to minimum to save bandwidth and get better image
Grandstream IP Camera provides two video streams; user can use them with flexibility. For example,
the high-resolution stream for local recording; another low or high resolution for remote monitoring; or
vice versa depending application scenarios.
Use below link to calculate bandwidth and storage before installation
http://www.grandstream.com/support/tools/bandwidth-storage-calc

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 23 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
CMOS Settings Page
This page allows user to adjust the CMOS parameters:
Figure 8 CMOS Settings Page
Flip: Check this will allow video flip 180° vertically in horizontal axis.
Iris Setting: Select from either automatic, where the iris would open or close depending on the
environment conditions, or set it to manual where the user can select from having it
open100/80/60/40/20 percent.
Shutter Speed: Select from either automatic shutter speed depending on the environment
conditions, or select one of the available shutter speeds from 1/30 to 1/1000 of a second.
IR CUT Setting: Select from either manual or automatic. If the user selects manual then select from
either daytime mode or night mode. If the user selects automatic, then select a sensitivity value from 1
to 5 that adjusts the best to the environment conditions.
Color Mode: Camera Color Mode. There are three options: Color; Black/White; Auto.
NOTE:
Flip option recommended if camera requires ceilling installation
Auto option recommended for both Shutter Speed and Color Mode.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 24 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Wi-Fi Settings Page
This page allows user to configure Wi-Fi network related parameters. Grandstream Wi-Fi dongle is
required for this to work. Wi-Fi dongle and USB flash drive storage is mutual exclusive and only one
choice will work at a time.
Figure 7-1: Wi-Fi Networking Setting Page
Enable Wi-Fi: If checked and click “Save”, a reboot is required before Wi-Fi start to
work. A pop up window will show as Figure 7-1.
Figure 9 Wi-Fi Networking Setting Page
SSID: Wi-Fi network SSID. When Wi-Fi enabled,
click “Scan” the camera will scan the Wi-Fi access point nearby.
Key: Key for security enhanced Wi-Fi network the camera try joining.
Security Mode: The security mode Wi-Fi access point or router used.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 25 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Networking Setting Page
This page allows user to configure network related parameters:
Figure 10 Network Setting Page
IP Address Configuration: Camera IP address configuration
o Dynamically Associated via DHCP: Default setting, DHCP server assign IP to
camera.
o Statically Configured as: Static IP address configuration
DNS Configuration: DNS server IP must be configured correctly if using static IP.
HTTP: Web access TCP port, default 80.
PPPoE: Set the PPPoE credentials if you intended to use PPPoE.
NOTE:
If camera behind SOHO router with port forwarding configuration for remote access, static IP or
static DHCP has to be used to avoid IP address change after router reboot.
TCP port above 5000 suggested if port forwarding HTTP remote access, due to some ISP would
block port 80 inbound traffic. For example, change the default HTTP port from 80 to 8088, to
make sure the port forwarding not likely be blocked.
In addition to HTTP port, RTSP port also required to be configured for port forwarding, in order
for remote party viewing the H.264 video.
If change the default port from TCP 80 to port “A”, then RTSP port should be “2000+A”. Both
TCP port “A” and “2000+A” should be configured for port forwarding in the router. For
example, the HTTP port changed to 8088, the RTSP port should be 10088, both 8088 and 10088
should be configured for port forwarding in order for remote camera video access.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 26 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
DDNS Settings Page
This page allows user to configure dynamic DNS related parameters:
Figure 11 DDNS Setting Page
DDNS Active: Enable DDNS by check this field.
DDNS ISP Type: Select the DDNS service provider from the pull-down menu list
Self-Define DDNS Address: Input the self-defined DDNS address
Site Name: DDNS site name
DDNS Account: DDNS account name
DDNS Password: DDNS password
STUN Server: STUN server FQDN or IP. If device behind non-symmetric router
STUN server can help to penetrate & resolve NAT issue.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 28 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Authenticate ID: Authenticate ID used by SIP proxy
Authenticate Password: Authenticate password used by SIP proxy
STUN Server: STUN server used to resolve NAT if have
Steam: Which stream used for SIP call.
Preferred Vocoder: Audio codec used for SIP call
Registration Expiration: Registration expiration time, default 3600 seconds
Local SIP Port: Local SIP port, default 5060
Local RTP Port: Local RTP port for media, default 5004
Auto on hook Timer: Auto On Hook timer, default 300 seconds
Disable Audio in SIP Call: Checked to disable audio for SIP call
Enable Keep Alive: Checked to enable, help NAT resolution
Accept Direct IP Call: Check to accept peer to peer IP call.
Enable White List Number Filter: Check to allow only white list number to call in, for security
Enable Dual-way Audio Warning: Check to enable two-way audio warning.
Phone List/Phone Number: Callee or call receiver number when alarm call trigged.
White List/Phone Number: Phone numbers allowed to call into the camera.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 29 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Status Page
This page shows the GXV3651_FHD operation status:
Figure 13 Status Page
NOTE:
When SIP account registered, the status will display “Online” in Green.
When SIP account unregistered, the status will display “Offline” in Red, as below.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 30 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
A S E DVANCED ETTINGS XPLANATION
The supports all the traditional and advanced telephony features.
User Management Page
This page allows user to do user management:
Figure 14 User Management Page
Existing User Name: Allow revise existing user or add new user
User Name: The name of user need to be revised
User Password: New password if revise password
Confirm User Password: Re-enter the new password for verification
Privilege: Choose user privilege
Allow Anonymous Viewing: When checked, no security enhanced. Any person can view the
camera if knowing the IP or FQDN of the camera, but can NOT
change anything, just view ONLY.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 31 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Maintenance Page
This page allows user to maintain the camera:
Figure 15 Maintenance Page
Restart: When clicked, the camera will reboot or restart
Restore: When clicked, the camera will be reset to factory default, wiping out all
the configurations (except IP address)
Firmware Upgrade and Provisioning:
Upgrade via: Upgrade firmware via TFTP, HTTP or HTTPS
Firmware Server Path: Server path holding the firmware
Config Server Path: Server path holding the configuration file (auto provisioning)
XML ConfigFile Password: Password for encrypt the XML based configuration file
Automatic Upgrade Interval (Minutes): Time interval for automatic upgrade, default 10080
Automatic Upgrade: Checked to enable automatic firmware upgrade and provisioning.
NOTE:
Only XML based automatic provisioning is supported by GXV3651_FHD.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 32 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
SMTP Setting Page (Email Alarm)
This page allows user to configure email client to send out email when alarm trigged:
Figure 16 SMTP Setting Page
Enable SMTP: When checked, email client is enabled.
SMTP Server: SMTP Email Server IP or Domain Name
SMTP Server Port: Port number used by server to send email
From Email address: The email address of alarm email sending from, usually client email ID
To E-Mail address: The email address to receive the alarmed email, total 3 included.
User Name: Email client User ID
Password: Email client password
SSL: Check if the SMTP email server requires SSL
NOTE:
Click “Save” to save the email configuration information.
Click “Test” after configuration, if setting is correct, a test email will send out and “Test
successful!” yellow bar will display like below

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 33 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
FTP Settings Page (Upload Alarm)
This page allows user to configure FTP parameters to upload the alarm or video recording:
Figure 17 FTP Setting Page
Enable FTP: When checked, built-in FTP client is enabled.
FTP Server: IP or Domain name of FTP site or server
FTP Server Port: TCP port for FTP server, default port number 21
User Name: FTP server User ID
Password: FTP server user password
Path: Path in the server where upload files are stored.
NOTE:
Click “Save” to save the FTP configuration information.
Click “Test” after configuration, if setting is correct, a test FTP operation will be performed and
“Test successful!” yellow bar will display if the operation is successful.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 34 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
PTZ Settings Page
This page configures the PTZ settings.
Select the PTZ protocol that your connected compatible 3rd party equipment (e.g.: External PTZ
Enclosure) by clicking on the radio in front of the protocol. Next, select the Baud Rate from the drop down
menu based on technical document of the 3rd party equipment and synchronize the Baud Rate setting.
Figure 18 PTZ Setting Page
PTZ Protocol:
The GXV3651_FHD supports both Pelco-D and Pelco-P. Select the protocol based on the technical
document of your 3rd party PTZ equipment.
PTZ Baud Rate:
The Baud Rate is the number of distinct symbol changes (signaling events) made to the transmission
medium per second in a digitally modulated signal or a line code.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 35 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Connect a PTZ device to the GXV3651_FHD
1. Connect the PTZ device (e.g.: 3rd party external enclosure) to GXV3651_FHD by
following the connection diagram shown below
Figure 19 PTZ Connection
2. Click Advanced Settings > PTZ; in PTZ page, configure the PTZ Protocol and Baud Rate
according to the technical document of your connected 3rd party PTZ device.
3. Click Save and reboot the device to apply all the changes.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 36 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Alarm Server Settings Page (Upload Alarm to Supported VMS or HTTP Server)
This page allows user to configure alarm HTTP server to upload alarms:
Figure 20 Alarm HTTP Server Setting Page
Server Name: The name of HTTP server or VMS system
URL: URL of the Server
User Name: User ID from that Server
Password: Password for that User ID
NOTE:
Grandstream provide HTTP API to help 3rd party company by using HTTP server or VMS to
develop further solutions for its customers.
Grandstream IP Camera and DVS (include GXV3651_FHD) are ONVIF certified.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 37 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Alarm Event Page
The GXV3651_FHD supports alarm inputs, for example, infrared detector, smoke detector and so on.
Follow the steps to make Alarm Input work:
1. Connect the alarm input equipment to the GXV3651_FHD.
2. Set up the alarm event time schedule.
3. Configure the alarm actions which you would like the GXV3651_FHD to take when the alarm is
triggered.
This page allows user to configure alarm event:
Figure 21 Alarm Event Setting Page
How Alarm Input and Alarm Output Work
Alarm-in is the alarm input port; users are able to connect sensors such as infrared sensor (PIR), smoke sensor or
light sensor to it. The detectable signal voltage range for alarm-in is from 1.8V to 15 V
NOTE:
Please do not connect a device that has a signal voltage that is higher than 15V, this will damage
the IP camera.
Internally, the Alarm-out uses relays as a switch (30VAC/2A); users can connect devices such as an alarm siren, alert
lights or electric strike to this port. Under normal circumstances, the circuit is open. When there is an alarm event,
the GXV3651_FHD will close the circuit to trigger the alarm.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 38 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Connect Alarm Input Equipment to the GXV3651_FHD
Here are two sample connection diagrams. Connect the alarm equipment to the GXV3651_FHD by following the
diagram below:
Setup Alarm Actions
An alarm action is what the GXV3651_FHD is going to do when an alarm is triggered during the defined time period
– the time schedule. The GXV3651_FHD allows multiple alarm actions.
Record Video: If this option is selected, the GXV3651_FHD will record the video when an alarm
is triggered. You can enter the length of the video recording (in seconds). You
can also choose the storage method for video files: SD card, USB Flash drive, or
USB hard drive.

Grandstream Networks, Inc. GXV3651_FHD User Manual Page 39 of 51
Firmware Version 1.0.1.68 Last Updated: 1/2013
Voice Alarm to SIP Phone: If this option is selected, the GXV3651_FHD will make calls to the
number listed in the Phone List page using the configured SIP
account when an alarm is triggered. To use this function, the
settings in SIP page must be configured properly.
Alarm Output: If this option is selected, the alarm will output via the configured
method/equipment when it is triggered.
Upload to Alarm Center: This option is an integrated feature with GSurf. If this option is
checked, the GXV3601 will report the alarm event to GSurf.
Upload to Alarm HTTP Server: This option is used when the Alarm Server is configured, the
GXV-3651_FHD will send an HTTP GET request to the pre-
configured HTTP Server.
Email and FTP upload JPEG and Store it to USB card or SD driver :
If this option is selected, the GXV3651_FHD will capture the
image and store it to connected live storage device when an alarm
is triggered.
Setup Alarm Event Time Schedule
This section allows you to configure the time during which the GXV3651_FHD will monitor the
Alarm Input. The GXV3651_FHD not only can monitor your settings but also can take actions when the alarm is
triggered.
Dropdown list for date Available time schedules
