USER MANUAL

WWW.NANLUX.COM

Evoke 1200

LED SPOT LIGHT

Product Details

1. Quick Release Device 11. Fixture Body Handle

9. USB Port

10. DMX IN

7. Function Keys

8. Left Knob

14. Wire Control

Socket

13. Right Knob

15. DC IN

16. DMX OUT

12. Kipp Handle

4. Eye Bolt

5. Yoke

2. NL Mount

3. Lock Catch

6. Display

Detailed Description

1. Quick release device: For quick installation and detachment of yoke.

2. NL mount: For installation of reflector or other NL mount accessories.

3. Lock catch: To lock or release the reflector or other accessories.

4. Eye Bolt: For hanging safety rope.

5. Yoke: Mount the fixture on a stand, pan and tilt.

6. Display: To display data.

7. Functions keys: Including DAYLIGHT, EFFECT, MENU and LOCK.

8. Left knob: For adjusting brightness and other parameters.

9. USB port: For updating firmwares or connecting USB cable to external devices with maximum current of 5V/1A.

10. DMX IN: DMX signal input interface.

11. Fixture body handle: Adjust the direction of the fixture.

12. Kipp handle: Tighten or release the tilt movement of the fixture on the yoke.

13. Right knob: For selecting options.

14. Wire control socket: Wire control Interface.

15. DC IN: DC power input interface.

16. DMX OUT: DMX signal output interface.

17. Power supply hanging point: For safely hanging the power supply.

18. DC power output socket: For connecting the fixture to the power supply with DC cable.

19. LED indicator: For determining the status of power input. Being on, power supply normal; Flashing or being off, power supply abnormal or no power input.

20. Power switch: To turn on/off the fixture.

21. AC power input socket: For connecting AC power supply.

18. DC Power Output Socket

17. Power Supply

Hanging Point

22. Power Supply Handle

20. Power Switch

21. AC Power Input Socket

23. COB Protective Cap

24. Reflector

19. LED Indicator
