Sida 1/2
TAB
ON/OFF
DC IN
1 5
1
2
3
4
6 7 8 9 10
160.00 mm
120.00 mm
封底 封面
书本形式
42
GVM-TL15RS
3 11 12
封面内页封底内页
1/4 Screw Hole
LED lamp beads
1/4 Screw
1/4 Screw
2
Rotate clockwise to assemble the light onto the stand and rotate
counter-clockwise to disassemble it.
Adapter interface
（Adapter is to be purchased）
Battery mounting slot
4
Fix your camera or your mobile phone via 1/4 camera screw and
the stand.
Mobile Phone Installation
Camera Installation
5
The two cold shoe mounts are compatible with various cameras.
DC IN
13
TAB
ON/OFF
DC IN
1
2
3
4
5
5
OLED display
Welcome to ”GVM-TL15RS”. This product is specially designed for senior photography
enthusiasts. The product is suitable for live / outdoor / studio photography, and also for
YouTube video shooting. The main features of the product are:
PRODUCT INTRODUCTION
①
②
③
We firmly believe that the correct use of this product will definitely help your shooting
work. Before using the product, we strongly recommend that you carefully read the
following user guide.
Infinitely adjustable RGB color and dual color temperature characteristics, brightness/
color temperature/RGB hue/color purity are all.It can be controlled at will, the color
temperature range is 3200K~5600K. Having 152 LED bulbs helps,To restore and
enrich the colors of objects, to provide you with natural and vivid shooting effects.
Adopts battery power and DC input Dual power supply design: equipped with battery
for outdoor use, optional adapter can use DC input for long-term continuous power
supply.
With electronic display and stable system. Small size and light weight, it can be
hand-held to customize control to fill light, and it is easy to carry. Let you shoot the
results you want easily.
④8 kinds of scene lights can be simulated: Lightning, Cop Car, Candle, TV, Bad Bulb,
Party, Disco, Paparazzi.
1.
PRECAUTIONS
①Please use the matching power adapter or lithium battery with the same
specifification to power the product. Do not use power adapter with
different output voltage parameters.
The product is not waterproof, please use it in rainproof environment.②
The product is not anti-corrosion, therefore do not let the product touch
any corrosive liquid.
③
When using the product, make sure the product is put fifirmly and prevent
from falling and damage.
④
If the product will not be used for a long time, please switch off the power
to reduce energy loss.
⑤
DISCLAIMERS
Before using this product, please read the instructions carefully and make sure use
the product correctly. If you don’t obey the instructions and warnings, you maybe
cause harm to yourself and the people around, or even damage the product and
other things around.
2. Once you use this product, you are deemed to have read the disclaimer and warning
carefully, understand and acknowledge all the terms and contents of this statement,
and promise to take full responsibility for the use of this product and possible
consequences.
PRODUCT
DETAIL
Brand: GVM
Product Name: Photography Light
Product model: GVM-TL15RS
Product Type: Photography fill light
Number of lamp beads: 152
Function/Features: High CRI, RGB Light, Scene Light, OLED Screen
Color rendering index: ≥97
Color temperature: 3200~5600K
HUE: 0°~360°
SAT: 0%~100%
Brightness: 1600lux/0.5m; 700lux/1m
Product size (mm): 295*213*40mm
Product net weight: 0.45KG
Power: 15W
Voltage: AC100V~240V
Heat dissipation: Self-heating
Product material: Plastic
Light adjustment method: Stepless dimming
Power supply mode : DC input & Battery
Battery Capacity : 7.4V-2200mAh*1
Power supply: DC 9V/3A (Power adapters are not provided
and need to be purchased separately)
Place of Origin: China. Huizhou
PRODUCT
STRUCTURE ANALYSIS
DC Power input
Cold Shoe Mount
Cold Shoe Mount
Brightness
Adjustment Knob
Battery Slot
Power Switch
Bluetooth
Photographing
Button
Battery Slot
1
Install the diffuser as below picture.
INSTALLATION
METHOD
3
There are two power supply modes to choose.
①
（ ） Single or dual battery both work.
②
Purchase a power cord and adapter separately, connect the power cord
and adapter for power supply.
Insert a lithium battery into the battery slot and use the battery for power.
DESCRIPTION OF
PRODUCT CONTROL KEYS
Long press this knob to switch the light mode;
short press this knob to select the light parameter;
turn this knob to adjust the currently selected light parameter.
Compound knob:
Power switch: Long press to turn on.
DC power input interface: Connect the power cord and adapter
for power supply. ( Adapter is to be purchased )
OLED display: display the current information of the photography
light.
Mobile phone Bluetooth camera button: Open the Bluetooth
on the mobile phone and connect it to GVM-HL. You can take
photos with the mobile phone via the Bluetooth Photographing
Button.
② Adjust brightness (BRG): Range 0%~100%
Long press the compound knob to switch modes. Modes include:
CCT, HSI, SCENE
CCT : (Dual color temperature mode) Adjustable brightness, color temperature
① Mode selection:
SCENE : (Scene light mode) Adjustable scene light, there are 8 kinds of scene light:
Lightning, Cop Car, Candle, TV, Bad Bulb, Party, Disco, Paparazzi.
There is brightness adjustment in any mode. Long press the compound knob
button to switch to the desired mode → short press the compound knob button
to select BRG → turn the compound knob button to adjust the brightness.
③ Adjust color temperature (CCT): Range 3200K~5600K
Long press the composite knob button to switch to CCT mode short press the →
composite knob button to select CCT turn the composite knob button to adjust →
the color temperature.
HSI : (RGB color light mode) Adjustable brightness, hue, color purity
FUNCTION INSTRUCTION &
INSTRUCTION FOR USE
④ Adjust hue (HUE): Range 0°~360°
Long press the compound knob button to switch to HSI mode short press the →
compound knob button to select HUE turn the compound knob button to adjust →
the hue.
⑤ Adjustable color purity (SAT): Range 0%~100%
Long press the composite knob to switch to HSI mode short press the composite →
knob to select SAT turn the composite knob to adjust the color purity. →
⑥ Adjust the scene mode (SCENE):
Long press the compound knob button to switch to SCENE mode → short press
the compound knob button to select MOD → turn the compound knob button to
switch scenes → short press the compound knob button to select the parameter
to be adjusted → rotate the compound knob button to adjust the currently
selected parameter.
Phenomenon
①
②
Make sure the adapter
is well contacted with
the power plug
Charge the battery
before using it
SIMPIE FAULTS
AND TROUBLESHOOTING
Check the product
Troubleshooting
The switch
indicator does
not light up
When using lithium battery, make sure
there's no "low power" protection.
Check whether the color purity SAT
value is too low or 0; the color purity
value is 100, the color difference is
the most obvious.
Increase the color purity
SAT value in HSI mode.
Color cannot
be adjusted
Check the matching power adapter
indicator light up or not.
(Buy separately)
Do not put the product in a highly humid, strong electromagnetic field, direct sunlight,
high-temperature environment. If not use the product for a long time, disconnect the
power and take out the battery.
Clean：Before clean, disconnect the power plug. And use wet cloth rather than any
detergent or soluble liquid, avoiding damaging the surface layer.
USE AND
PRESERVATION
Power：Make sure the power is in the demanded range, not too high or too low. Correctly
load the battery, in order not the damage to machine.
Repairing：If there is fault or performance degradation, do not unpack the shell by
yourself, avoiding damage the machine and lose the right of maintenance. When there
is a fault, do not hesitate to contact us, and we will do our best to deal with the problem.
Accessories：Please use the accessories provided by manufacturer and approved
ones, in order to maximize the performance.
Guarantee：Do does not modify the product, or you will lose the right of maintenance.
1
Phone Clip
N am e
Q ua n t it y
N ot e s
1
1
1
1
GVM-
TL15RS
Photography
Light
PACKING
LIST
Lithium-Ion
Battery
Battery
Charger
User Manual
FacebookGVM Official
website
Web: www.gvmled.com
B&H Email: bh@gvmled.com
GVM Email: support@gvmled.com
Amazon Email: amazonsupport@gvmled.com
Warehouse Add: 4301 N Delaware ave, unit D. PHILADELPHIA, PA19137, USA
C O N T E N T S
Product introduction Page 1- ---------------------------------------- --
Disclaimers Page 1--------------------------------------------------------
Product Detail Page 2------------------------ --- -------------- ------- ----
Product structure analysis Page 3--------------------- ------------- --
Installation method Page 4 8~------------------------ --- ------------ -
Description of product control keys Page 9----------- -- ---- ---- --
Function introduction and instruction for use Page 10~11----
Simple faults and troubleshooting Page 11------------------------
Use and preservation Page 12-----------------------------------------
Precautions Page 12---------- ------------------------ --------------------
Packing list Page 13------------------------------------------------ -------
