GOS-6051/6050/6031/6030 OSCILLOSCOPE
USER MANUAL
⎯⎯
i
CONTENTS PAGE
1.PRODUCT INTRODUCTION.................................................
1-1.Description……………………………………………….
1-2.Feature…………………………………………………....
1
1
2
2.TECHNICAL SPECIFICATIONS………………………… 4
3.PRECAUTIONS BEFORE OPERATION…….…………...
3-1.Unpacking the Oscilloscope……………….………….…
3-2.Checking the Line Voltage…………………..…………..
3-3.Environment……………………………………..………
3-4.Equipment Installation and Operation………………....
3-5.CRT Intensity……………………………………………
3-6.Withstanding Voltage of Input Terminals……………...
7
7
7
8
8
8
8
4.PANEL INTRODUCTION……………………..…………...
4-1.Front Panel……………………………………………….
4-2.Rear Panel……………………………………….……….
8
11
26
5.OPERATION METHOD………………………………...….
5-1.Readout Display……………………………………..…...
5-2.Connecting Input Signals..………………………………
5-3.Adjustment and Checks…………………………………
5-4.Function Check…..………………………………………
5-5.Basic Operation………….….…………………………....
5-6.Measurement Application……………………………….
28
28
30
31
33
35
44
6.MAINTENANCE……………………………………………
6-1.Fuse Replacement………………………………………..
6-2.Line Voltage Conversion……………………………..….
6-3.Cleaning………………………………………………….
46
46
46
47
7.BLOCK DIAGRAM………………………………………...48
GOS-6051/6050/6031/6030 OSCILLOSCOPE
USER MANUAL
⎯⎯
ii
SAFETY TERMS AND SYMBOLS
These terms may appear in this manual or on the product:
WARNING. Warning statements identify condition or
practices that could result in injury or loss of life.
CAUTION. Caution statements identify conditions or
practices that could result in damage to this product or
other property.
The following symbols may appear in this manual or on the product:
DANGERATTENTION ProtectiveEarth(ground)
High Voltagerefer to ManualConductorTerminal
Terminal
