Sida 1/28

DIGITAL VIDEO RECORDER

Quick Guide

HRX-1635/HRX-1634/HRX-835A

Features

The product records video and audio from cameras to a hard disk, and enables playback from the hard disk.

It also provides remote monitoring environment for video and audio over the network using a remote computer.

●

Provides new UI 2.0

●

Supports instant viewer

●

Bookmark function

●

Thumbnail function (Not supported in web viewer)

●

View camera event list in real time

●

Convenient event rule setup

●

Various sequence (layout, page) functions

●

Extended search period

●

Convenient log search

●

Supports thermal imaging camera/PTZ linked camera

●

Supports a range of 4K camera resolutions

●

Outputs a 4K high definition image using HDMI

●

Supports dual monitor output

●

Record and play video

●

Record and play audio

●

Supports ONVIF Profile S standard and RTP / RTSP protocols

●

Display the HDD operation status by HDD SMART

●

HDD overwrite enabled

●

Function to export using USB memory and external hard disk

●

Simultaneous play of 10 or 18 channels

●

View multi-channel time line when playing videos

●

Various Search Modes (Time, Event, Smart, Text, Export, ARB)

●

ARB support (configuration feature for saving period by channel)

●

Various recording modes (Normal, Event, Scheduled Recording)

●

Alarm Input / Output

●

Remote monitoring function by Windows Network Viewer

●

Live monitoring of the camera

●

Installation Wizard Function (Recorder, Web Viewer)

●

Supports the remote monitoring feature by DDNS/P2P support (Wisenet Viewer/Wisenet mobile)

●

Provides smartphone event alarm (sending real-time event messages)

Package Contents

■

The appearance of the components may differ from the image shown.

■

Accessory category and quantity may differ depending on sales region.

■

For some regions, HDD is not pre-installed. HDD Fixing Screw, SATA Cable quantity vary depending on the model.

HRX-1635/HRX-835A

USB

DIGITAL VIDEO RECORDER

REC HDD ALARM

NETWORK BACKUP

POWER

Recorder Mouse Quick Guide

Power Cable SATA Power Cable

SATA Data Cable

(HRX-1635: 8 ea, HRX-835A: 4 ea)

HDD Fixing Screw

(HRX-1635: 32 ea, HRX-835A: 16 ea)

Bracket Rack (2 ea)/Screw(4 ea) Terminal block (15 pins, 20 pins)

English

HRX-1634

DIGITAL VIDEO RECORDER

REC HDD ALARM

NETWORK BACKUP

POWER

Recorder Mouse Quick Guide

Power Cable Power Adaptor SATA Power Cable

SATA Data Cable (2 ea) HDD Fixing Screw (8 ea) Bracket Rack (2 ea)/Screw(4 ea)

Installing the HDD

■

If you are adding a new or previously used HDD to this product in addition to the HDD(s) originally installed, format the new HDD manually in the

set before use.

■

If you wish to replace or add an HDD, contact your dealer or our customer service first.

HRX-1635/HRX-835A

■

The images below are based on the HRX-1635 model.

Loosen the screws on the left/right sides and

back and slide the cover back to remove it.

Loosen the left/right screws and remove the

bracket.

Bracket

Install 8 HDDs to the bracket and fix them with

screws.

■

For the HRX-835A, install the HDD only to the bottom bracket.

Fix the bracket with the HDD to the recorder with

screws.

■

To prevent damage to the HDD(s) due to vibration, it is

recommended to install it first to the bottom bracket.

Produktspecifikationer

Varumärke:	Hanwha
Kategori:	Videobandspelare
Modell:	HRX-1635
Inbyggd display:	Nej
Bredd:	440 mm
Djup:	384.8 mm
Höjd:	88 mm
Mobila operativsystem som stöds:	iOS, Android
LED-indikatorer:	Ja
Wi-Fi:	Nej
Videoformat som stöds:	H.265, H.264
Maximal upplösning:	3840 x 2160 pixlar
Ljudsystem:	2-vägs
Antal HDMI-portar:	1
Strömförbrukning (max):	200 W
Total installerad lagringskapacitet:	24000 GB
Snabbinstallationsguide:	Ja
DHCP-server:	Ja
DHCP-klient:	Ja
Maximal lagringskapacitet:	48 TB
VGA (D-Sub) utgångsportar:	1
Larmingångskanaler:	16
Syslog:	Ja
Larmutgångskanaler:	4
Produktens färg:	Svart
Datahastighet för Ethernet-LAN:	10,1000,100 Mbit/s
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	0 - 40 ° C
Intervall för relativ operativ luftfuktighet:	20 - 85 %
Hårddiskkapacitet:	- GB
AC-inspänning:	100 - 240 V
Språkstöd:	CZE, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HRV, HUN, ITA, NOR, POL, POR, RUM, RUS, SER, THA, TUR, VIE
Stöd för nätverksprotokoll:	IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S), SUNAPI(Server, Client)
Antalet hårddiskar som stöds:	8
Växelström Frekvens:	50 / 60 hz
Bildkomprimeringsformat:	MJPEG
På / av-knapp:	Ja
Antal USB 2.0 anslutningar:	1
Upplösningar som stöds:	3840 x 2160, 2560x1440, 1920x1080, 1280x1024, 1280x720
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	1
Video-inspelningslägen:	2160p, 720p, 1080p
PTZ-styrning:	Ja
Hårddiskens gränssnitt:	SATA III
Linje in:	Ja
Videoingångskanaler:	16 kanaler
Antal kanaler som kan spelas upp samtidigt:	18 kanaler
Säkerhetskopieringsfunktion:	Ja
Ingående bandbredd:	128 Mbit/s
Inspelningstyp:	Schedule, Event
Utgående bandbredd:	32 Mbit/s
BNC-videoingång:	Ja
