NETWORK CAMERA

User Manual

XNF-8010R/XNF-8010RV/XNF-8010RVM

Hanwha Techwin

Trademark

Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their

respective company.

Restriction

Copyright of this document is reserved. Under no circumstances, this document shall be reproduced, distributed or changed, partially or wholly, without

formal authorization.

Disclaimer

Hanwha Techwin

makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be

provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility.

Hanwha Techwin

reserves the

right to change the contents of this document without prior notice.



Design and specications are subject to change without prior notice.



The initial administrator ID is “admin” and the password should be set when logging in for the rst time.

Please change your password every three months to safely protect personal information and to prevent the damage of the information

theft.

Please, take note that it’s a user’s responsibility for the security and any other problems caused by mismanaging a password.

Network Camera

User Manual

English _3

●● OVERVIEW

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean the contaminated area on the product surface with a soft, dry cloth or a damp cloth.

(Do not use a detergent or cosmetic products that contain alcohol, solvents or surfactants or oil constituents

as they may deform or cause damage to the product.)

7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and

the point where they exit from the apparatus.

11. Only use attachments/ accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,

or sold with the apparatus. When a cart is used, use caution when moving the cart/

apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lighting storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus

has been damaged in any way, such as power-supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

15. This product is intended to be supplied by a Listed Power Supply Unit marked “Class 2” or “LPS” and rated

from 12 Vdc, 1.1 A for XNF-8010RVM*, XNF-8010RV*, 12 Vdc, 1.0 A for XNF-8010R*.

16. If you use excessive force when installing the product, the camera may be damaged and malfunction.

If you forcibly install the product using non-compliant tools, the product may be damaged.

17. Do not install the product in a place where chemical substances or oil mist exists or may be generated. As

edible oils such as soybean oil may damage or warp the product, do not install the product in the kitchen or

near the kitchen table.

This may cause damage to the product.

18. When installing the product, be careful not to allow the surface of the product to be stained with chemical

substance.

Some chemical solvents such as cleaner or adhesives may cause serious damage to the product’s surface.

19. If you install/disassemble the product in a manner that has not been recommended, the production functions/

performance may not be guaranteed.

Install the product by referring to “Installation & connection” in the user manual.

20. Installing or using the product in water can cause serious damage to the product.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT

TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE

VENTILATION GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT.

Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,

such as vases, shall be placed on the apparatus.

To prevent injury, this apparatus must be securely attached to the Wall/ceiling in accordance

with the installation instructions.

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION

: TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

EXPLANATION OF GRAPHICAL SYMBOLS

The lightning flash with arrowhead symbol, within an equilateral triangle, is

intended to alert the user to the presence of “dangerous voltage” within the

product’s enclosure that may be of sufficient magnitude to constitute a risk of

electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to

the presence of important operating and maintenance (servicing) instructions in

the literature accompanying the product.

WARNING

To prevent damage which may caused by IR LED, don’t stare at operating lamp.

For below models only

XNF-8010RVM* XNF-8010RV* XNF-8010R*

Risk Group 1

WARNING IR emitted from this product.

Do not stare at operating lamp

Product tested against IEC 62471

overview

Produktspecifikationer

Varumärke:	Hanwha
Kategori:	övervakningskamera
Modell:	XNF-8010RVM
Vikt:	790 g
Bredd:	146 mm
Djup:	146 mm
Höjd:	65.8 mm
Ljudformat som stöds:	AAC-LC, ADPCM, G.711, G.726
Videoformat som stöds:	H.264, H.265, M-JPEG
Maximal upplösning:	2048 x 2048 pixlar
Antal kameror:	1
Fast brännvidd:	1.6 mm
Ljudsystem:	2-vägs
Zoomkapacitet:	Ja
Fokus:	Manuell
Optisk sensorstorlek:	1/8 "
Bildsensortyp:	CMOS
Digital zoom:	8 x
Inbyggd mikrofon:	Ja
vitbalans:	ATW, AWC, Indoor, Manual, Mercury lamp, Outdoor, Sodium lamp
Grafikupplösningar som stöds:	640 x 640,640 x 160,640 x 480 (VGA),704 x 576,720 x 720,800 x 600 (SVGA),960 x 960,1024 x 768 (XGA),1280 x 960,1280 x 1280,1600 x 1200 (UXGA),1920 x 480,2048 x 1536 (QXGA),2048 x 2048
Modell:	IP-säkerhetskamera
webbläsare:	Ja
Antal användare:	20 användare (er)
Ljuddetektering:	Ja
Progressiv skanning:	Ja
Samplingshastighet:	48 kHz
Antal linser:	1
Strömningsmetod:	Multicast, Unicast
Antal sensorer:	1
Antal effektiva pixlar (H x V):	2048 x 2048 pixlar
Highlight Compensation (HLC):	Ja
Brusreduceringsteknik:	Reducering av 3D-ljud
Typ av minneskort:	SD, SDHC, SDXC
Produktens färg:	Black, Ivory
Inbyggd kortläsare:	Ja
Slutartid:	2 - 1/12000 s
Skyddsfunktioner:	Vandalsäker
Formfaktor:	Kupol-formad
Kompositvideo ut:	1
mörkerseende avstånd:	15 m
Strömförbrukning (Power over Ethernet (PoE)):	12.95 W
Windows-operativsystem som stöds:	Windows 10, Windows 7, Windows 8.1
Mac-operativsystem som stöds:	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
brett dynamiskt omfång (WDR):	Ja
Typ av ethernet-gränssnitt:	Snabb Ethernet
Antal LAN (RJ-45) anslutningar:	1
Strömförbrukning (vanlig):	12 W
Temperatur vid drift:	-40 - 55 ° C
Temperaturintervall (förvaring):	-50 - 60 ° C
Intervall för relativ operativ luftfuktighet:	0 - 90 %
Fuktighet (förvaring):	0 - 90 %
Internationellt skydd (IP) kod:	IP66
Video rörelsedetektor:	Ja
Kryptering/säkerhet:	802.1x RADIUS, EAP-TLS
Material, hölje:	Gjuten aluminium
Placeringar som kan användas:	Inomhus & utomhus
Anslutningsteknologi:	Kabel
Dag / nattläge:	Ja
Monteringssätt:	Tak
Minimibelysning:	0.1 lx
Kameraslutningstyp:	Elektronisk
Största bländarnummer:	1.6
Mörkerseende:	Ja
Totalt megapixel:	6 MP
Bildfrekvens:	30 fps
Strömmande video:	Ja
Ljuddämpning:	Ja
Vänd och spegla:	Ja
Integritetsskydd:	Ja
Styrning av bit-hastighet:	Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Bakgrundsbelysningskompensation (BLC):	Ja
Nätverksansluten (Ethernet):	Ja
Stöd för nätverksprotokoll:	TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3 (MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, SIP
Filtrering för IP-adress:	Ja
Systemfunktioner för intelligent videoövervakning (IVS):	Crossing line, Missing object, People counting
Strömkälla av typen:	PoE
Kommunikationsstandarder:	IEEE 802.3af
Stöd för garanterad tjänstekvalitet (QoS):	Ja
PTZ-styrning:	Ja
Högsta minneskortskapacitet:	512 GB
Uttag för mikrofon/linje in:	Ja
Bildstabiliserare:	Ja
Larm ingång / utgång:	Ja
Fjärruppspelning:	Ja
Infrarött (IR) gränsfilter:	Ja
Objektivets betraktningsvinkel, horisontell:	192 °
Signal/brusförhållande (SNR):	50 dB
Aktivt manipulering larm:	Ja
Närmsta fokusavstånd:	0.3 m
Objektivets betraktningsvinkel, vertikal:	192 °
Typ av larmmeddelande:	E-post
IK klass:	IK10
PTZ-lägen:	Digital PTZ
Infoga text i bilden:	Ja
Fog bevis:	Ja
Objektivets betraktningsvinkel, diagonal:	192 °
Antiflimmer:	Ja
