Sida 1/5
1. INTRODUCTION
Heatit Z-Dim2 is a Z-Wave™ rotary dimmer for many dierent types
of light xtures. The Heatit Z-Dim2 works on most low loads without
causing ickering.
The dimmer is equipped with an external switch option. This allows
you to dim and turn on/o the load from an external switch.
Heatit Z-Dim2 is very well suited for LED, and ts into System 55 frames.
When connecting low loads it is recommended to use a bypass.
NB! DIMMING
Dimming may be challenging, and we recommend checking the
compatibility of dierent light sources before installation. We are
happy to answer any questions.
2. STATEMENT REGARDING PRODUCTS FROM MULTIPLE
MANUFACTURERS
Please read this before installation
This device may be used with all devices certied with the Z-Wave
Plus™ certicate and should be compatible with such devices
produced by any manufacturer. Every primary controller is dierent
depending on the manufacturer, their target audience and intended
use/application. Please review the functionalities implemented
by the primary controller you intend to use with our Z-Wave Plus
certied device to ensure that it provides the necessary controls to
take full advantage of our product’s capabilities.
3. BEHAVIOUR WITHIN THE Z-WAVE™ NETWORK
This device may be operated within any Z-Wave network with
Z-Wave-certied devices from other manufacturers. All non-battery-
operated nodes within the network will act as repeaters regardless of
manufacturer to increase the reliability of the network. On delivery,
the device does not belong to any Z-Wave network. The device needs
to be added to an existing network to communicate with the other
devices within it. Devices may also be removed from a network. The
add/remove processes are initiated by the primary controller of the
Z-Wave network.
4. QUICK START
1. Switch o the mains voltage (turn o the fuse).
2. Open the junction box.
3. Connect according to the wiring diagram as shown in chapter 7
“Installation & wiring”.
4. After verifying the connections, switch on the mains voltage.
5. Set the primary controller in add mode (security/non-security).
6. Press the reset button on dimmer 3 times in a rapid sequence.
Heatit Z-Dim2 is now included in your Z-Wave network.
HEATIT
Z-DIM2 250W
Ver 2022-A
Firmware 1.20
01.05.2022
Installers manual
TABLE OF CONTENTS
1. Introduction
2. Statement regarding products from multiple manufacturers
3. Behaviour within the Z-Wave™ network
4. Quick Start
5. Control
6. Illustrations
7. Installation and wiring
8. External Switch
9. Add/Remove
9.1 Method 1: Standard (Manual)
9.2 Method 2: SmartStart (Automatic)
10. Factory Reset
11. Startup
12. LED blinking patterns description
13. QR-Code Placement (DSK)
14. Security
15. Node Information Frame
16. Associations
16.1 Setting and Removing Associations
17. Association Groups
18. Conguration Parameters
19. Autocalibration of maximum dim level
20. Command Classes
20.1 Basic Command Class
20.2 Multilevel Switch Command Class
20.3 Meter Command Class
20.4 Indicator Command Class
20.5 Central Scene Command Class
21. Supported Command Classes
Product info
White RAL 9003
plastic kit
White RAL 9010
plastic kit
Dimmer unit
Art.no. 14 444 40
