Sida 1/12
Product & Assembly
Manual
HEATSTRIP
®
I n t e n s e Porta ble Electric
Heater
Model THY2200P
For HEATSTRIP Installation video go to: www.youtube.com, search HEATSTRIP www.heatstrip.com.au
2
For repairs or replacement parts, please contact:
Thermofilm Australia Pty Ltd
17 Johnston Court, Dandenong South, Victoria 3175, Australia
Telephone: (03) 9562 3455
8:30am-5:00pm Mon-Fri (EST)
Email: sales@thermofilm.com.au
To obtain the correct replacement parts for your electric radiant heater, please refer to
the part numbers in this parts list. The following information is required to ensure you
receive the correct parts:
1. Model and Serial Number (see label on the heater)
2. Part Number
3. Part Description
4. Quantity of parts needed
Important: Use only Thermofilm replacement parts. The use of any part that is not a
Thermofilm replacement part can be dangerous and void your product warranty. Keep
this Instruction Manual for convenient referral and for parts replacement.
Contents
Product Overview 3
Specifications 3
Product Features & Benefits 3
Installation Requirements 4
Parts List 4
Product Parts Diagram 5
Hardware Pack & Tools Required 6
Assembly Instructions 7
Electric Heater Assembly Instructions 7-9
Maintenance and Safety 10
Replacement Parts 10
Warranty 11
Manual # Rev B - Date:20/12/2017
3
Specifications - Australia
MODEL POWER
(WATTS)
CURRENT
(AMPS)
DIMENSIONS (mm) WEIGHT
(Kg)
LEAD
LENGTH
(mm)
PLUG
THY2200P 2200 9.2 1068(W) x 2050(H) x 500(D) 20 3000 Yes
HEATER TYPE High intensity electric radiant heater with carbon filament element.
POWER 230-240 Volts Nominal at 50—60 Hertz, Single Phase
CONNECTION 3 Core Cable 2.5mm
2
APPROVALS AUSTRALIA/NZ
PROTECTION RATING IPX5 Protection from water ingress from all directions
MATERIAL OF CONTRUCTION Heater: Black anodized alloy casing & endcaps, powder coated grille
Stand: Powder coated mild steel
Features & Benefits
Stylish, high quality portable, free-standing outdoor heat-
er stand
Ideal for alfresco areas, balconies, apartments & hospi-
tality (internal & external use)
High Temperature Output
All black construction with attractive hexagonal shaped
grille
Instantaneous Heat
Infrared Carbon Filament Element
Concealed power cable ensures a sleek appearance
Components are sub-assembled for easy DIY installation
In-built wheels for easy portability, perfect for residential
and commercial applications
Corrosion protected for even the toughest environments
2 year residential and 1 year commercial warranty
Tips
If an extension lead is required, use one as short as pos-
sible, as a long lead may result in performance loss
Locate the heater as close to the power point as possible
This portable heater is for spot heating only. Locate as
close to the area you want to heat as possible (e.g Ta-
ble)
Store under cover at all times
MODEL INDOOR PROTECTED (m
2
) OUTDOOR ENCLOSED (m
2
)
OUTDOOR EXPOSED (m
2
)
THY2200P 14 9 5
Heating Area
