Wired Bus Cable Adapter

HmIPW-BCC

Installation and Operating Manual

Table of contents

1 Table of contents

1x Wired Bus Cable Adapter

1x User manual

2 Information about this

manual

Read this manual carefully before begin-

ning operation with your HomematicIP

Wired device. Keep the manual for later

consultation. If you hand the device over

to other persons for use, please ask them

to read this manual.

Symbols used

This indicates a hazard.

This section contains important ad-

ditional information.

3 Hazard information

We accept no liability for damage

caused by use for other than the

intended purpose, incorrect han-

dling or failure to observe the haz-

ard warnings. In such cases, all war-

ranty claims are void. We accept no

liability for consequential damage.

Do not use the device if it has visi-

ble damage or a malfunction. If you

have any doubts, have the device

checked by a qualified expert.

For safety and licensing reasons

(CE), unauthorised conversions to

and/or modification of the device

are not permitted.

The device is not a toy – do not al-

low children to play with it.

Plastic film, plastic bags, polystyrene

parts, etc. can be dangerous for

children. Keep the packaging mate-

rial out of the reach of children and

dispose of it immediately.

Clean the device using a soft and

clean lint-free cloth. Do not use any

detergents containing solvents for

cleaning purposes.

Do not expose the device to mois-

ture, vibrations, constant solar or

other heat radiation, excessive cold

or mechanical loads. The device

must only be operated indoors.

Failure to observe the installa-

tion instructions may result in fire or

a danger of electric shock. The de-

vice is part of the building installa-

tion. Observe the relevant nation-

al standards and directives during

planning and installation.

The device is intended for operation

on the HomematicIP Wired Bus on-

ly. The HomematicIP Wired Bus

is a SELV power circuit. The mains

voltage for the building installation

and the HomematicIP Wired Bus

must be routed separately. Com-

mon cable routing for power supply

and the HomematicIP Wired Bus

in installation and junction boxes is

not permitted. The required isola-

tion for a power supply of the build-

ing installation to the HomematicIP

Wired Bus must be observed at all

times.

Hazard information

For safe operation, the device must

be installed in a circuit distribu-

tion board that complies with the

standards VDE 0603, DIN 43871

(low voltage sub-distribution board

(NSUV)), DIN 18015-x. The device

must be installed on a mounting

rail (top-hat rail, DIN rail) in accor-

dance with DIN EN60715. Installa-

tion and wiring must be carried out

in accordance with VDE 0100 (VDE

0100-410, VDE 0100-510). The pro-

visions of the technical connection

regulations (TAB) of the energy sup-

plier must be observed.

Observe the permissible cable types

and conductor cross sections when

connecting to the device terminals.

The device is suitable for use only in

residential environments.
