Sida 1/3
Warning
Model No.: FCJJ-35
Super Capacitor Science Education Kit
ASSEMBLY GUIDE
To avoid the risk of property damage, serious injury or
death:
1. Read carefully and fully understand the instructions
before assembling this kit.
2. This kit is intended only for use by persons 14 years
old and up, and only under the supervision of adults
who have read and understood the instructions in this
user manual.
3. When assembling this kit, tools may be used. Extra
care should be taken to avoid personal injury.
4. Some parts are small and fragile: please be careful
when handling and connecting parts to avoid breakage.
Handle all parts and components with care.
5. Do not attempt to use any part, item, or component
provided in this kit for any other purpose than what is
instructed in this manual. Do not attempt to disassemble
any part, item or component in this kit.
6. Keep small children and animals away, because this kit
contains small parts that could be swallowed.
7. The hand crank is highly suggested to be cranked at
approximately 2 revolutions per second otherwise the
crank generator could be damaged by cranking too fast.
Super Capacitor Science Education kit
Preparing the super capacitor module
a. Insert the super capacitor support (g) into the base (f).
Make sure they fit well.
List of Component
a. Hand crank generator
b. Potentiometer
c. Super capacitor
d. Fan module
e. Fan blade
f. Capacitor base
g. Capacitor support
h. Wires
i. Fan blade adapter
a
b
c
d
e
f
g
h
b. Place the super capacitor (c) onto its support (g).
Make sure the capacitor fits well in its support.
c. Plug the red cable (h) and black cable (h) in the capacitor red and black socket.
Ensure to respect the color code.
Otherwise energy from the hand crank can not be stored into the capacitor.
Preparing the energy storing kit
a. Connect the other end of the cable to the potentiometer (b).
Ensure to respect the color code.
b. Connect the red and black cable to the hand crank (a).
Ensure to respect the color code.
i
