HUF40/68A

5/11/16

Item # 13157

HoshizakiAmerica,Inc. reserves the right to change

specifications without notice.

*AutoCad available on KCL

Item #

Project:

Qty:

• Stainless steel interior and exterior top, front and sides

• EverCheck solid state digital control system with visual alarms

• Entire cabinet and doors are insulated with 2 3/8" CFC free foamed in place polyurethane

• Exclusive "Stepped" door design to protect recessed door gasket

• Self-closing all stainless steel doors with locks

• Doors are reversible at the factory (no charge)

• Dual door frame heaters to eliminate condensation

• Epoxy coated evaporator coil

• Front breathing with Zero clearance requirements

• Cartridge-style refrigeration system is easily removed from main unit

• Defrost is time initiated temperature terminated

• Hinged, louvered front panel for easy access to controller

• Removable stainless steel end panel for access to refrigeration system

• Removable, cleanable refrigeration system Air Filter

• Energy efficient automatic hot gas condensate evaporator

• (1) Epoxy coated wire shelf per section

• Stainless steel shelf supports adjustable on 1” centers

• 4" heavy duty platform casters (two with brakes)

• Three years parts and labor warranty

• Five year compressor warranty

• 8 ft. cord and plug

HUF-A Dimensions

W x D x H

1 Section - 40.25” x 32.3” x 33.9”*

2 Section - 68” x 32.3” x 33.9”*

*with 4” casters

Electrical/Refrigeration

Voltage- 115/60/1

H

ACR Breaker- 15.0

E

lectrical Connection- 5-15P

(NEMA)

Voltage Range- 104-126

Ambient Temp. Range - 45˚-100˚F

Control Setpoint Range - -13˚ to +19˚F

*RefrigerantR-404A

Warranty

Valid in United States, Canada, Puerto Rico,

and U.S. Territories. Contact factory for

warranty in other countries.

• Three Year - Parts & Labor on entire

machine.

• Five Year - Parts on: Compressor.

Options

• 6” Legs

• 6” Casters

• Tray pan rack slides (18” x 26” pans)

• Bullnose top (front & rear)

• Stainless steel back

• Drawers

• Additional epoxy shelves

Dimensions / Capacity

Electrical & Refrigeration Data

Model #One Section

HUF40A

Two Section

HUF68A

InteriorStorageCapacity(CF)8.5 ft

3

18.8 ft

3

Overall Width x Depth40.25” x 32.3” 68” x 32.3”

Height (including 4” casters)33.9”33.9”

Door Opening Width x Height22.5” x 24.3” 22.5” x 24.3”

Depth with Door open at 90° 56.8”56.8”

Adjustable Shelves12

Shelf Dimensions (W x D)22.4” x 24.6”25.0” x 24.6”

Crated Shipping Weight317 lbs442 lbs

Crated Height x Width x Depth39.5” x 44.25” x 36.25”39.5” x 72” x 36.25”

Model #One Section

HUF40A

Two Section

HUF68A

Amperage

4.810.0

Energy Consumption (kwh/day)

4.979.45

Heat Rejection (BTU/Hr.)

11331565

Approx. Nominal Compres. BTU/HR(HP)

1378 (3/8HP)2466 (1/2HP)

HUF40/68A

Professional Series Undercounter Freezers

© HOSHIZAKI AMERICA, INC.

618 Hwy. 74 S., Peachtree City, GA 30269

TEL 800-438-6087

FAX 800-345-1325

www.hoshizaki.com
