Sida 1/24
GB
1
English, 1
! This symbol reminds you to read this bo-
oklet.
Contents
Installation, 2-3-4-5-6-7
Unpacking and levelling
Connecting the electricity and water supplies
The first wash cycle
Technical data
Instructions for the fitter
Care and maintenance, 8
Cutting off the water or electricity supply
Cleaning the Washer-dryer
Cleaning the detergent dispenser drawer
Caring for the door and drum of your appliance
Cleaning the pump
Checking the water inlet hose
Precautions and tips, 9
General safety
Disposal
Opening the porthole door manually
Description of the Washer-dryer and star-
ting a wash cycle, 10-11
Control panel
Indicator lights
Starting a wash cycle
Wash cycles, 12
Table of wash cycles
Personalisation, 13
Setting the temperature
Setting the drying cycle
Functions
Detergents and laundry, 14
Detergent dispenser drawer
Preparing the laundry
Garments requiring special care
Load balancing system
Troubleshooting, 15-16
Product Guarantee and Repair Information,
17
GB
BHWD 129
Instructions for use
WASHER-DRYER
2
GB
unevenness by tightening or loosening the
adjustable front feet (see figure); the angle
of inclination, measured according to the
worktop, must not exceed 2°.
Levelling your appliance correctly will provide
it with stability and avoid any vibrations, noi-
se and shifting during operation. If it is pla-
ced on a fitted or loose carpet, adjust the
feet in such a way as to allow enough room
for ventilation beneath the Washer-dryer.
Electric and water connections
Connecting the water inlet hose
1. Connect the supply
pipe by screwing it
to a cold water tab
using a 3/4 gas thre-
aded connection (see
figure). Before per-
forming the connec-
tion, allow the water
to run freely until it
is perfectly clear.
2. Connect the other
end of the water inlet
hose to the Washer-
dryer,
screwing it onto the
appliance’s cold water
inlet, situated on the
top right-hand side
on the rear of the
appliance (see figure).
3. Make sure there are no kinks or bends in
the hose.
! The water pressure at the tap must be
within the values indicated in the Technical
details table (see page 5).
! If the water inlet hose is not long enough,
contact a specialist store or an authorised
serviceman.
! Ensure that the supply taps are allowing
water through. Old taps may seize in the
closed position and thus prevent water
reaching the machine.
! Keep this instruction manual in a safe place
for future reference. Should the appliance
be sold, transferred or moved, make sure the
instruction manual accompanies the Washer-
dryer to inform the new owner as to its ope-
ration and features.
! Read these instructions carefully: they
contain vital information on installation, use
and safety.
Unpacking and levelling
Unpacking
1. Unpack the Washer-dryer.
2. Check whether the Washer-dryer has
been damaged during transport. If this is
the case, do not install it and contact your
retailer.
3. Remove the 4
protective screws
and the rubber
bush with the re-
spective spacer, si-
tuated on the rear
of the appliance
(see also the instal-
lation leaflet).
NB:The plastic spa-
cers may fall down
inside the machine once the bolt has been
removed, and will not interfere with the
operation of the machine.
4. Seal the gaps using the plastic plugs
provided.
5. Keep all the parts: you will need them
again if the Washer-dryer needs to be mo-
ved to another location.
! Packaging materials are not children’s
toys.
Levelling
Your machine may make a considerable amount
of noise if the two front feet have not been
adjusted correctly.
1. Install the Wa-
sher-dryer on a
flat sturdy floor,
without resting it
up against walls,
furniture cabinets
or other.
2. If the floor is
not perfectly level,
compensate for any
Installation
GB
3
Connecting the drain hose
Connect the drain
hose, without ben-
ding it, to a draining
duct or a wall drain
situated between
65 and 100 cm from
the floor;
The drain hose may
be connected to
an under-sink trap.
Before connecting
the drain hose from
the machine ensu-
re that any blanks
or removable ends
have been taken off
the spigot.
If it is place over
the edge of a basin
or sink be sure the
free end of the
hose should not be
underwater.
! We advise against the use of hose exten-
sions; in case of absolute need, the exten-
sion must have the same diameter as the
original hose and must not exceed 150 cm
in length.
Ensure that if the drain hose is pushed into
a standpipe, that the end does not go down
more than 15cms (6 inches). If the hose is
pushed down too far, this may cause the
machine to self -syphon ie. continuously
empty as it is filling.
Electric connection
Before plugging the appliance into the
mains socket, make sure that:
• the socket is earthed and in compliance
with the applicable law;
• the socket is able to sustain the applian-
ce’s maximum power load indicated in the
Technical details table (see page 5);
65 - 100 cm
Where it connects to
the waste water pipe
cut end off spigot or
remove the blanking cap
• the supply voltage is included within the
values indicated on the Technical details ta-
ble (see page 5);
• the socket is compatible with the washing
machine’s plug. If this is not the case, re-
place the socket or the plug.
Your appliance is now supplied with a 13 amp
fused plug it can be plugged into a 13 amp
socket for immediate use. Before using the
appliance please read the instructions below.
WARNING - THIS APPLIANCE MUST BE EAR-
THED.
THE FOLLOWING OPERATIONS SHOULD BE
CARRIED OUT BY A QUALIFIED ELECTRICIAN.
Replacing the fuse:
When replacing a faulty fuse, a 13 amp ASTA
approved fuse to BS 1362 should always be
used, and the fuse cover re-fitted. If the
fuse cover is lost, the plug must not be used
until a replacement is obtained.
Replacement fuse covers:
If a replacement fuse cover is fitted, it must
be of the correct colour as indicated by
the coloured marking or the colour that is
embossed in words on the base of the plug.
Replacements can be obtained directly from
your nearest Service Depot.
Removing the plug:
If your appliance has a non-rewireable moul-
ded plug and you should wish to re-route the
mains cable through partitions, units etc.,
please ensure that either:
the plug is replaced by a fused 13 ampere
re-wearable plug bearing the BSI mark of
approval.
or:
the mains cable is wired directly into a 13
amp cable outlet, controlled by a switch, (in
compliance with BS 5733) which is accessible
without moving the appliance.
Disposing of the plug:
Ensure that before disposing of the plug
itself, you make the pins unusable so that it
cannot be accidentally inserted into a socket.
Instructions for connecting cable to an alter-
native plug:
Important: the wires in the mains lead are co-
loured in accordance with the following code:
Green & Yellow Earth
Blue Neutral
Brown Live
