Quick guide
SLIDING RUNNERS AND SHELF GUIDES
Before using the oven remove the protective tape [a] and then
remove the protective foil [b] from the sliding runners.
REMOVING THE SLIDING RUNNERS [c]
Pull the lower part of the sliding runner to uncouple the lower
hooks (1) and pull the the sliding runners upwards, removing
them from the upper hooks (2).
REFITTING THE SLIDING RUNNERS [d]
Hook the upper hooks on the shelf guides (1) then press the
lower part of the sliding runners against the shelf guides, until
the lower hooks are clicking (2).
1
2
1
2
[c][d]
REMOVING AND REFITTING THE SHELF GUIDES
1. To remove the shelf guides, rmly grip the external part of the
guide, and pull it towards you to extract the support and the
two internal pins from the lodging.
2. To reposition the shelf guides, position them near the cavity
and initially insert the two pins into their lodgings. Next,
position the external part near its lodging, insert the support,
and rmly press towards the wall of the cavity to make sure the
shelf guide is properly secured.
FIRST TIME USE
1. SETTING THE TIME
You will need to set the time when you switch on the appliance
for the rst time: Pressuntil the icon and the two digits
for the hour start ashing on the display.
Use or to set the hour and press to conrm. The two
digits for the minutes will start ashing. Use o to set the
minutes and press to conrm.
Please note: When the
icon is flashing, for example following
lengthy power outages, you will need to reset the time.
2. SET THE POWER CONSUMPTION
By default the oven is programmed to work at a power higher
than 3 kW (Hi): To operate the oven at a power that is compatible
with a domestic power supply less than 2,9 kW (Lo), you will
need to change the settings.
To go to the change menu, turn the selection knob to , then
turn it back to .
Press and hold and for ve seconds immediately
afterwards.
THANK YOU FOR BUYING A HOTPOINT-
ARISTON PRODUCT
In order to receive a more complete
assistance, please register your product on
www . hotpoint . eu/register
Before using the appliance carefully read the Safety
Instruction.
CONTROL PANEL DESCRIPTION
132456
1. SELECTION KNOB
For switching the oven on by selecting a
function.
Turn to theposition to switch the oven
o.
2. LIGHT
With the oven switched on, press to turn
the oven compartment lamp on or o.
3. SETTING THE TIME
For accessing the cooking time settings,
delayed start and timer.
For displaying the time when the oven is
o.
4. DISPLAY
5. ADJUSTMENT BUTTONS
For changing the cooking time settings
6. THERMOSTAT KNOB
Turn to select the temperature you
require when activating manual
functions.
For automatic functions keep on
/A.
Produktspecifikationer
| Varumärke: | Hotpoint |
| Kategori: | Ugn |
| Modell: | FA5 841 P IX HA |
| Inbyggd display: | Ja |
| Vikt: | 30000 g |
| Bredd: | 595 mm |
| Djup: | 551 mm |
| Höjd: | 595 mm |
| Grill: | Ja |
| Förpackningens bredd: | 600 mm |
| Konvektionsmatlagning: | Ja |
| Antal ugnar: | 1 |
| Energiförbrukning (konventionell): | 0.89 kWh |
| Ugnsstorlek: | Medium |
| Ugnens termostatområde: | 250 - 420 ° C |
| Produktens färg: | Black, Stainless steel |
| Skärmtyp: | LCD |
| Kontrolltyp: | Rotations- |
| Låddjup: | 555 mm |
| Vikt inkl. förpackning: | 35000 g |
| Ugnstyp: | Elektrisk ugn |
| Ugnens nettokapacitet: | 71 l |
| AC-inspänning: | 220-240 V |
| Apparatens placering: | Inbyggd |
| Växelström Frekvens: | 50 - 60 hz |
| Ström: | 16 A |
| Installationsfack, bredd: | 600 mm |
| Installationsfack, djup: | 555 mm |
| Installationsfack, höjd: | 560 mm |
| Grill styrka: | 2200 W |
| Totalt ugn (er) invändig kapacitet: | 71 l |
| Totalt ugn: | 3300 W |
| Ugnström: | 3300 W |
| Normalkokning: | Ja |
| Energiförbrukning (påtvingad konvektion): | 0.69 kWh |
| Antal glaspaneler dörr: | 3 |
