Sida 1/46

SAFETY INSTRUCTIONS

IMPORTANT TO BE READ AND OBSERVED

Download the complete instruction manual on

http://docs.hotpoint.eu or call the phone number

shown on the warranty booklet.

Before using the appliance, read these safety

instructions. Keep them nearby for future reference.

These instructions and the appliance itself provide

important safety warnings, to be observed at all times.

The manufacturer declines any liability for failure to

observe these safety instructions, for inappropriate use

of the appliance or incorrect setting of controls.

WARNING: If the hob surface is cracked, do not

use the appliance - risk of electric shock.

WARNING: Danger of re: Do not store items on

the cooking surfaces.

CAUTION: The cooking process has to be

supervised. A short cooking process has to be

supervised continuously.

WARNING: Unattended cooking on a hob with

fat or oil can be dangerous - risk of re. NEVER try to

extinguish a re with water: instead, switch o the

appliance and then cover ame e.g. with a lid or a

re blanket.

Do not use the hob as a work surface or support.

Keep clothes or other ammable materials away

from the appliance, until all the components have

cooled down completely - risk of re.

Very young children (0-3 years) should be kept

away from the appliance. Young children (3-8years)

should be kept away from the appliance unless

continuously supervised. Children from 8years old

and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge can use this appliance only if they

are supervised or have been given instructions on

safe use and understand the hazards involved.

Children must not play with the appliance. Cleaning

and user maintenance must not be carried out by

children without supervision.

WARNING: The appliance and its accessible parts

become hot during use. Care should be taken to

avoid touching heating elements. Children less than

8 years of age shall be kept away unless continuously

supervised.

PERMITTED USE

CAUTION: the appliance is not intended to be

operated by means of an external switching device,

such as a timer, or separate remote controlled system.

This appliance is intended to be used in household

and similar applications such as: sta kitchen areas

in shops, oces and other working environments;

farm houses; by clients in hotels, motels, bed &

breakfast and other residential environments.

No other use is permitted (e.g. heating rooms).

This appliance is not for professional use. Do not

use the appliance outdoors.

INSTALLATION

The appliance must be handled and installed by

two or more persons - risk of injury. Use protective

gloves to unpack and install - risk of cuts.

Installation, including water supply (if any),

electrical connections and repairs must be carried

out by a qualied technician. Do not repair or replace

any part of the appliance unless specically stated in

the user manual. Keep children away from the

installation site. After unpacking the appliance,

make sure that it has not been damaged during

transport. In the event of problems, contact the

dealer or your nearest After-sales Service. Once

installed, packaging waste (plastic, styrofoam parts

etc.) must be stored out of reach of children - risk of

suocation. The appliance must be disconnected

from the power supply before any installation

operation - risk of electric shock. During installation,

make sure the appliance does not damage the

power cable - risk of re or electric shock. Only

activate the appliance when the installation has

been completed.

Carry out all cabinet cutting operations before

tting the appliance and remove all wood chips and

sawdust.

If the appliance is not installed above an oven, a

separator panel (not included) must be installed in

the compartment under the appliance.

ELECTRICAL WARNINGS

It must be possible to disconnect the appliance

from the power supply by unplugging it if plug is

accessible, or by a multi-pole switch installed

upstream of the socket in accordance with the

wiring rules and the appliance must be earthed in

conformity with national electrical safety standards.

Do not use extension leads, multiple sockets or

adapters. The electrical components must not be

accessible to the user after installation. Do not use

the appliance when you are wet or barefoot. Do not

operate this appliance if it has a damaged power

cable or plug, if it is not working properly, or if it has

been damaged or dropped.

Installation using a power cable plug is not

allowed unless the product is already equipped with

the one provided by the Manufacturer.

If the supply cord is damaged, it must be replaced

with an identical one by the manufacturer, its service

agent or similarly qualied persons in order to avoid

a hazard - risk of electric shock.

CLEANING AND MAINTENANCE

WARNING: Ensure that the appliance is switched

o and disconnected from the power supply before

performing any maintenance operation; never use

steam cleaning equipment - risk of electric shock.

Do not use abrasive or corrosive products,

chlorine-based cleaners or pan scourers.

Produktspecifikationer

Varumärke:	Hotpoint
Kategori:	Ugn
Modell:	HR 632 B
Inbyggd display:	Ja
Timer:	Ja
Vikt:	8000 g
Bredd:	580 mm
Djup:	510 mm
Höjd:	46 mm
Typ av klocka:	Elektronisk
LED-indikatorer:	Ja
Automatisk avstängning:	Ja
Ramtyp:	Framkant
Ramfärg:	Svart
Produktens färg:	Svart
Skärmtyp:	Analog
Kontrolltyp:	Röra
AC-inspänning:	230 V
Apparatens placering:	Inbyggd
Växelström Frekvens:	50 - 60 hz
På / av-knapp:	Ja
Ström:	27.8 A
Installationsfack, bredd:	560 mm
Installationsfack, djup:	490 mm
Installationsfack, höjd:	42 mm
Barnsäkert:	Ja
Typ av spishäll:	Keramisk
Antal brännare / zoner matlagning:	4
Antalet elektriska kokzoner:	4
Kokzon 3, form:	Rund
Diameter på platta/tillagningsyta 1:	180 mm
Placering av platta/tillagningsyta 4:	Höger fram
Typ av platta/tillagningsyta 4:	Vanlig
Typ av platta/tillagningsyta 3:	Vanlig
Kokzon 1, form:	Rund
Placering av platta/tillagningsyta 3:	Höger bak
Kokzon 2, form:	Rund
Strömförsörjning till platta/tillagningsyta 3:	Elektrisk
Diameter på platta/tillagningsyta 4:	145 mm
Typ av platta/tillagningsyta 1:	Stor
Placering av platta/tillagningsyta 2:	Vänster bak
Diameter på platta/tillagningsyta 2:	120 / 210 mm
Diameter på platta/tillagningsyta 3:	145 mm
Strömförsörjning till platta/tillagningsyta 4:	Elektrisk
Strömförsörjning till platta/tillagningsyta 2:	Elektrisk
Typ av platta/tillagningsyta 2:	Extra stor
Kokzon 4, form:	Rund
Strömförsörjning till platta/tillagningsyta 1:	Elektrisk
Placering av platta/tillagningsyta 1:	Främre till vänster
Manöverplats:	Framsida
Maximal kabelförlust med anslutning:	Ja
Klocka:	Ja
Typ av timer:	Digital
Alarm:	Ja
Typ av ytskikt:	Glass-keramisk
Anslutningseffekt (elektrisk):	- W
Anslutningseffekt (gas):	- W
Hålla sig varm funktion:	Ja
Boost-funktionen:	Nej
Ram formulär:	Direkt
Spisens bredd, storlek:	58 cm
Antal kokzoner som kan användas samtidigt:	4
Integrerad huva:	Nej
Kombizon:	Ja
Funktion för kokningskontroll:	Ja
Rengöring lås:	Ja
