ENQuick Guide

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that THE SALT RESERVOIR NEVER BE EMPTY.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must

be lled when the green oat on the cap of the salt reservoir is no longer

visible.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Only the rst time you do this: ll the salt reservoir

with water.

3. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 1 kg); it is not unu-

sual for a little water to leak out.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water sof-

tener beyond repair).

Whenever you need to add salt, it is mandatory to complete the pro-

cedure before the beginning of the washing cycle to avoid corrosion.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently prevent-

ing scale buildup on heater, contributing also to better cleaning eciency.

This system regenerates itself with salt, therefore it is required to rell

salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 5 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid

dispenser A should be lled when the dark optical

indicator on the dispenser door C becomes trans-

parent.

NEVER pour the rinse aid directly into the

appliance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device D. Introduce the

detergent into the dry dispenser E only. Place the amount of detergent for

pre-washing directly inside the tub.

Usage of detergent not designed for dishwashers may cause malfunc-

tion or damage to the appliance.

Program

Programs description

Drying

phase

Duration

of wash

program

(h:min)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Program is suitable to clean normally soiled tableware, that for this use, it is

the most ecient programme in terms of its combined energy and water consump-

tion, and that it is used to assess compliance with the EU Ecodesign legislation.

4:3011.50.76

Intensive65° - Program recommended for heavily soiled crockery, especially suitable

for pans and saucepans (not to be used for delicate items).

2:3015.51.50

Mixed 55° - Mixed soil. For normally soiled dishes with dried food residues.

2:3015.51.30

Rapid 40’45° - Program to be used for half load of lightly-soiled dishes with no dried

food residues. Without drying.

0:408.50.90

Half Load 50°- Ideal for washing a half load of lightly or normally soiled crockery.

1:2011.50.90

CONTROL PANEL

FIRST TIME USE

More information in the Daily Reference Guide on website.

PROGRAMS TABLE

1. ON-OFF / Reset button with indicator light

2. Program selection button

3. Program indicator lights

4. START/Pause button with indicator light

PLEASE SCAN THE

QR CODE ON YOUR

APPLIANCE IN

ORDER TO HAVE

MORE DETAILED

INFORMATION

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories:

For information on comparative EN testing conditions, please send an email to the following address:

[email protected]

Pre-treatment of the dishes is not needed before any of the programs.

*) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

THANK YOU FOR BUYING A HOTPOINT ARISTON PRODUCT.

In order to receive a more complete assistance, please register

your appliance on: www.hotpoint.eu/register

Before using the appliance carefully read Safety and Installation Instructions.

After installation, please remember to remove all transport protection parts from

the dishwasher.
