Refrigerators
Top-Freezer
162D6736P007 39-60256-1 10-03 JR
Safety Information
Adapter Plugs . . . . . . . . . . . . . . . . . 3
Connecting Electricity . . . . . . . . . . 3
Extension Cords . . . . . . . . . . . . . . . 2
Safety Precautions . . . . . . . . . . . . . . 2
Operating Instructions
Automatic Icemaker . . . . . . . . . . . .8
Care and Cleaning . . . . . . . . . . 9, 10
Shelves . . . . . . . . . . . . . . . . . . . . .5, 6
Storage Drawers . . . . . . . . . . . . . .6, 7
Temperature Controls . . . . . . . . . . .4
Installation Instructions
Preparing to Install
the Refrigerator . . . . . . . . . . . . . . 11
Reversing the Door Swing . . . 16–22
Water Line Installation . . . . . . 12–16
Troubleshooting Tips
Before You Call
For Service . . . . . . . . . . . . . . . .24, 25
Normal Operating Sounds . . . . . .23
Consumer Support
Consumer Support . . . . Back Cover
Product Registration . . . . . . . . 29, 30
Warranty . . . . . . . . . . . . . . . . . . . . 31
www.Hotpoint.com
Write the model and serial numbers here:
Model #__________________________
Serial # __________________________
You can find them on a label on the upper
left side of the fresh food compartment.
Models
15, 16, 17, 18
Owner’s Manual and
Installation Instructions
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
Use this appliance only for its intended purpose as described in this Owner’s Manual.
SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
■ ■This refrigerator must be properly installed
and located in accordance with the Installation
Instructions before it is used.
■ ■Do not allow children to climb, stand or hang
on the shelves in the refrigerator. They could
damage the refrigerator and seriously injure
themselves.
■ ■Do not touch the cold surfaces in the freezer
compartment when hands are damp or wet.
Skin may stick to these extremely cold
surfaces.
■ ■Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
■ ■Keep fingers out of the “pinch point” areas;
clearances between the doors and between
the doors and cabinet are necessarily small.
Be careful closing doors when children are
in the area.
■ ■In refrigerators with automatic icemakers,
avoid contact with the moving parts of the
ejector mechanism, or with the heating
element that releases the cubes. Do not place
fingers or hands on the automatic icemaking
mechanism while the refrigerator is plugged in.
■ ■Unplug the refrigerator before cleaning and
making repairs.
NOTE: We strongly recommend that any servicing be
performed by a qualified individual.
■ ■Turning the control to the position does 0
not remove power to the light circuit.
■ ■Do not refreeze frozen foods which have
thawed completely.
2
PROPER DISPOSAL OF THE REFRIGERATOR
Child entrapment and suffocation are not
problems of the past. Junked or abandoned
refrigerators are still dangerous…even if they
will sit for “just a few days.” If you are getting
rid of your old refrigerator, please follow the
instructions below to help prevent accidents.
Before You Throw Away Your Old
Refrigerator or Freezer:
■Take off the doors.
■Leave the shelves in place so that children
may not easily climb inside.
Refrigerants
All refrigeration products contain refrigerants,
which under federal law must be removed prior
to product disposal. If you are getting rid of an
old refrigeration product, check with the
company handling the disposal about what
to do.
USE OF EXTENSION CORDS
Because of potential safety hazards under certain conditions, we strongly recommend against
the use of an extension cord.
However, if you must use an extension cord, it is absolutely necessary that it be a UL-listed,
3-wire grounding type appliance extension cord having a grounding type plug and outlet and
that the electrical rating of the cord be 15 amperes (minimum) and 120 volts.
DANGER! RISK OF CHILD ENTRAPMENT
Consumer Support Troubleshooting Tips Operating InstructionsInstallation InstructionsTroubleshooting Tips Installation Instructions Safety InstructionsSafety InstructionsOperating Instructions
3
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
www.Hotpoint.com
WARNING!
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
For personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall outlet
to minimize the possibility of electric shock
hazard from this appliance.
Have the wall outlet and circuit checked by a
qualified electrician to make sure the outlet is
properly grounded.
Where a standard 2-prong wall outlet is
encountered, it is your personal responsibility
and obligation to have it replaced with a
properly grounded 3-prong wall outlet.
The refrigerator should always be plugged into
its own individual electrical outlet which has a
voltage rating that matches the rating plate.
This provides the best performance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
Never unplug your refrigerator by pulling on the
power cord. Always grip plug firmly and pull
straight out from the outlet.
Repair or replace immediately all power cords
that have become frayed or otherwise damaged.
Do not use a cord that shows cracks or abrasion
damage along its length or at either end.
When moving the refrigerator away from the
wall, be careful not to roll over or damage the
power cord.
USE OF ADAPTER PLUGS
Because of potential safety hazards under certain conditions, we strongly recommend against
the use of an adapter plug.
However, if you must use an adapter, where local
codes permit, a temporary connection may be made
to a properly grounded 2-prong wall outlet by use
of a UL-listed adapter available at most local
hardware stores.
The larger slot in the adapter must be aligned
with the larger slot in the wall outlet to provide
proper polarity in the connection of the power
cord.
When disconnecting the power cord from the
adapter, always hold the adapter in place with
one hand while pulling the power cord plug with
the other hand. If this is not done, the adapter
ground terminal is very likely to break with
repeated use.
If the adapter ground terminal breaks, DO NOT
USE the refrigerator until a proper ground has
been established.
Attaching the adapter ground terminal to a wall outlet
cover screw does not ground the appliance unless the
cover screw is metal, and not insulated, and the wall
outlet is grounded through the house wiring. You should
have the circuit checked by a qualified electrician to
make sure the outlet is properly grounded.
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
