Sida 1/5
Models
HP 3005pr USB 3.0 Port Replicator
H1L08AA
HP 2005pr USB 2.0 Port Replicator
H1L07AA
Compatibility
The HP 3005pr USB 3.0 Port Replicator is compatible with Windows®-based PCs and netbooks with a USB 3.0 port. The HP 2005pr USB
2.0 Port Replicator is compatible with Windows®-based PCs and netbooks with a USB 2.0 port.
NOTE:
Please note that neither port replicator works with the HP ElitePad 900 Tablet PC.
Service and Support
HP Universal Docking Solutions have a one-year limited warranty or the warranty remaining for the HP product in which it is installed.
Technical support is available seven days a week, 24 hours a day, as well as in online support forums. Certain restrictions and
exclusions apply.
NOTE:
Certain restrictions and exclusions apply.
HP 3005pr USB 3.0 Port Replicator (H1L08AA) front view
1.
USB 2.0 port
2.
USB 2.0 port
QuickSpecs
HP Universal Docking Solutions for HP Notebook PCs
Overview
DA - 13223 North America — Version 16 — January 10, 2013
Page 1
HP 3005pr USB 3.0 Port Replicator (H1L08AA) back view
1.
Power connector
7.
Audio-out headphone jack
2.
USB 2.0 port
8.
USB 3.0 port for connecting notebook PC
3.
USB 2.0 port
9.
RJ-45 network jack
4.
USB 3.0 port
10.
HDMI port
5.
USB 3.0 port
11.
DisplayPort
6.
Audio-in microphone jack
HP 2005pr USB 2.0 Port Replicator (H1L07AA) back view
1.
Power connector
7.
Audio-out headphone jack
2.
USB 2.0 port
8.
USB 2.0 port for connecting notebook PC
3.
USB 2.0 port
9.
RJ-45 network jack
4.
USB 2.0 port
10.
VGA port
5.
USB 2.0 port
11.
HDMI port
6.
Audio-in microphone jack
QuickSpecs
HP Universal Docking Solutions for HP Notebook PCs
Overview
DA - 13223 North America — Version 16 — January 10, 2013
Page 2
Standard Features for HP 3005pr USB 3.0 Port Replicator
USB ports
2 USB 3.0 ports (back), 4 USB 2.0 ports (2 front, 2 back)
Network connectors
10/100/1000 Ethernet port
Monitor connectors
HDMI, DisplayPort 1.2
Audio connectors
Headphone/Microphone
Security cable slots
Add a locking cable (sold separately) to secure the docking station using the security cable slot
LED indicator
One Green LED indicates power, one Green LED indicates PC
Specifications
Dimensions
(H x W x D)
1 x 8.64 x 2.76 in (25.2 x 219.5 x 70.2 mm)
Weight
0.50 lb (235g)
USB 3.0
Upstream connector
Type B
Peripherals
USB 3.0
Capacity of each port
Total current shared among Min. 2.5A of 2 USB 3.0 ports
Cable length
1.64 ft (0.5m)
USB 2.0
Downstream connector
Type A
Peripherals
USB 2.0
Capacity of each port
1.0A max
Video
Two external displays with 1920 x 1200 resolution each are available when connected through a USB 3.0
connection from the notebook to the port replicator. Up to a 2560 x 1600 resolution is available on a single
external display connected through a USB 3.0 connection from the notebook to the port replicator,
however when a 2560 x 1600 resolution display is connected to the port replicator, the unused port will be
disabled. 1920 x 1200 resolution is available on a single external display when connected through a USB
2.0 connection from the notebook to the port replicator.
Audio
Microphone
3.5mm jack input
Headphone output
>= 0.707 V rms at 320 Ohm load
>= 300 mV rms at 32 Ohm load
Network
IEEE802.3:10Base-T,100Base-TX,1000Base-T, compatible. Wake-on-LAN (WOL) not supported
Power requirements
DC input
19.5 V
Rated current
3.5A
Temperature
Operating
41° to 95° F (5° to 35° C)
Non-operating
41° to 104° F (5° to 40° C)
Relative humidity
Operating
8% to 80%, non-condensing
Non-operating
8% to 80%, non-condensing
Agency approvals
CB, CE, FCC, UL/cUL, ICES, C-tick, BSMI, VCCI Class-B, SABs, GOST-R, UkrSEPRO
Operating system
compatibility
Windows® XP SP2 (32-bit edition only), Windows® XP SP3 (32-bit edition only), Windows Vista® SP1 (32-bit
and 64-bit editions), Windows Vista® SP2 (32-bit and 64-bit editions), Windows® 7 (32-bit and 64-bit
editions)
NOTE:
Please note this port replicator does not work with the HP ElitePad 900 Tablet PC.
Option kit contents
HP 3005pr USB 3.0 Port Replicator, AC power adapter, USB 3.0 cable, documentation
QuickSpecs
HP Universal Docking Solutions for HP Notebook PCs
HP 3005pr USB 3.0 Port Replicator
DA - 13223 North America — Version 16 — January 10, 2013
Page 3
