Operating instructions

Ultrasonic diffuse-reflection sensor

with IO-Link

UIT500

UIT503

UIT506

80278204 / 00 08 / 2018

1 Safety instructions

• Read this document before setting up the product and keep it during the entire

service life.

• The product must be suitable for the corresponding applications and

environmental conditions without any restrictions.

• Only use the product for its intended purpose .(→ 2 Functions and features)

• If the operating instructions or the technical data are not adhered to, personal

injury and/or damage to property may occur.

• The manufacturer assumes no liability or warranty for any consequences

caused by tampering with the product or incorrect use by the operator.

• Installation, electrical connection, set-up, operation and maintenance of the

product must be carried out by qualified personnel authorised by the machine

operator.

• Protect units and cables against damage.

2 Functions and features

Ultrasonic sensor for monitoring levels and detecting objects.

3 Installation

►Secure the unit to a bracket.

1/2: status LEDs 1/2 (yellow),

setting aid and output indication

3: echo LED (green), is on when object or

background is detected

4: teach button

Sound-absorbing surfaces have a negative effect on a reliable function.

► Technical data sheet): Consider the dead zone (→

No object detection in the dead zone.

For units with metal housing (according to UL 508):

►Observe a minimum distance of 12.7 mm between the sensor and non-

insulated live parts.

For further information please refer to www.ifm.com

→ General information about installation and operation.

4 Electrical connection

►

Disconnect power.

► Connect unit (depending on the type selected):

BK: black

BN: brown

BU: blue

WH: white

2OUT2

L+

OUT1

• OUT1: switching output / IO-Link

• OUT2: switching output

colours to DIN EN 60947-5-2

5 Settings

The unit and the parameters are set via the IO-Link interface (→ 5.1) or the

teach button (→ 5.2).

5.1 IO-Link

This unit has an IO-Link communication interface which enables direct access to

process and diagnostic data. In addition it is possible to set the parameters of the

unit while it is in operation. Operation of the unit via an IO-Link interface requires

an IO-Link master.

With a PC, suitable IO-Link software and an IO-Link adapter cable communication

is possible when the system is not in operation.

The IODDs necessary for the configuration of the unit, detailed information about

process data structure, diagnostic information, parameter addresses and the

necessary information about the required IO-Link hardware and software can be

found at www.ifm.com.
