Overview And Uses
HDDA-1
HDTV
Wideband Analog
Distribution
Amplifier
Phone: 503-575-1951
Email: s[email protected]
INDAY
1818 NE 140th
Portland, Oregon 97230
For Customer Service:
The HDDA-1 is a very wideband analog Distribu-
tion Amplifier (DA) capable of buffering and split-
ting any nominal 1 to 2 Volt (peak to peak) signal
that terminates into 75 ohms. This includes any of
the following.
-H
DTV Analog RGB/YPbPr signals
.
-Sta
ndard Def. Analog RGB/YPbPr/Betacam
-Co
mponent DVD, Progressive or Interlac
ed.
-C
omposite Video (NTSC)
-SPDIF
Digital Audio (PCM/AC3
/DTS)
Figure 1 - Connectors
Figure 2 - Component Video Distribution
The HDDA-1 can be configured in a number of
ways. Here are the most common.
♦A
1-In to 4-Out HDTV Receiver or Progress
ive
Scan
DVD Splitter. Figure
2
♦
A 1
-In to 10 out Composite Distribution Amp to
feed a stack of Dubbing VCR’s. Figure
3
♦
Three
separate 1-In to 4-Out DA’s. Figure
4.
♦
Hom
e Theater. One input distributes the Com-
posite (NTSC) video to the Displays and anot
her
in
put distributes the Digital Audio to the Audio
equipment. Figure
5
Th
e unit is supplied with the proper 12VDC Power
Supply (center pin positive +).
Configurations
Figure 3 - Composite Video Distribution 1X10
