Sida 1/2
PACKAGE CONTENTS
• 3.6A USB Charger Wall Outlet
• White decora-style wall plate
• Wall plate screws (2)
• Outlet mounting screws (2)
• Quick Setup Guide
FEATURES
• Replaces a standard duplex outlet
• Quickly charges USB devices
• Tamper-resistant outlets for added safety
• Provides two USB ports with 3.6A total output
• Provides two standard 110V power outlets
• Works in nearly all installations
• Compatible with your existing decora wall plate
We recommend that you use a professional
electrician to install the USB charger wall outlet.
SAFETY
Warnings:
• RISK OF ELECTRIC SHOCK — Use only in dry
locations and only indoors.
• All cables should be routed away from the charger
outlet openings.
• DO NOT use with any aquarium equipment.
• DO NOT install in an outlet that is not grounded.
Notes to the installer:
• This device must be installed in accordance with
National and Local electrical codes.
• To prevent severe shock or electrocution, always
turn power OFF at the service panel before
working with wiring.
• This device should be used with copper or
copper-clad wire. DO NOT use with aluminum
wire.
• DO NOT install this device into a shallow wall box.
The wall box must be deep enough to house the
charger outlet. If the box is too shallow, the
charger outlet will not t securely into the wall.
• Professional installation is not a requirement but is
highly recommended
• Installer should use the screws that were used to
install the existing outlet.
INSTALLING THE OUTLET
Warning: DISCONNECT POWER. Failure to
do so can result in severe injury or death.
1 Make sure that you disconnect power to the
circuit by removing the fuse from the circuit or
turning OFF the circuit breaker.
2 Remove the wall plate and mounting screws
that cover the old outlet.
3 Carefully remove the existing outlet from the
wall box.
4 Disconnect the wiring from the old outlet. Note
the wire positions.
5 Connect the wires to the outlet:
• Black lead attaches to the hot wire(s)
• White lead attaches to the neutral wire(s)
• Green lead attaches to the ground wire(s)
Note: Installers should use previous wire positions
as a guide.
Electrical outlets
USB ports
QUICK SETUP GUIDE
3.6A
USB Charger
Wall Outlet
NS-HW36A2P
Before using your new product, please read these instructions to prevent any damage.
Hot (black)
Neutral (white)
Ground (green)
NS-HW36A2P_22-0923_QSG_V2_EN_Final.ai 1 11/8/2022 8:55:04 AM
