Sida 1/12
owner’s manual
Thank you for choosing a JL Audio Evolution™ C2 Component System
for your automotive sound system.
These Evolution™ Speakers have been designed and manufactured to
exacting standards in order to ensure years of musical enjoyment in your
vehicle. For maximum performance, we highly recommend that you have
your new speakers installed by an authorized JL Audio dealer. Your
authorized dealer has the training, expertise and installation equipment
to ensure optimum performance from this product. Should you
decide to install the speakers yourself, please take the time
to read this manual thoroughly so as to familiarize yourself
with its installation requirements and setup procedures.
If you have any questions regarding the instructions in this
manual or any aspect of your amplifier’s operation, please contact your
authorized JL Audio dealer for assistance. If you need further assistance,
please call the JL Audio Technical Support Department
at (954) 443-1165 during business hours.
6.50-inch (165 mm) 2-Way Component System
2 | JL Audio - C2-650 Owner’s Manual
AE
B
F
D
C
Due to ongoing product development, all specifications are subject to change without notice.
Woofer Physical Dimensions
Frame Outer Diameter (A) 6.50 in. / 165.0 mm
Grille Tray Outer Diameter (B) 6.84 in. / 173.7 mm
Magnet Outer Diameter (C) 3.15 in. / 80.0 mm w/o cover
Frontal Grille Protrusion (D) 0.85 in. / 21.6 mm
Mounting Hole Diameter (E) 5.56 in. / 141.3 mm
Mounting Depth (F) 2.44 in. / 61.9 mm w/o cover
A
D
C
A
D
B
C
B
A
Crossover Network Physical Dimensions
Height (A) 4.72 in. / 119.9 mm
Width (B) 3.36 in. / 85.3 mm
Depth (C) 1.44 in. / 36.6 mm
Tweeter Fixture Physical Dimensions Flush-Mount Surface-Mount
Fixture Outer Diameter (A) 1.87 in. / 47.5 mm 1.69 in. / 42.9 mm
Fixture Mounting Hole Diameter (B) 1.625 in. / 41.3 mm N/A
Fixture Mounting Depth (C) 0.76 in. / 19.3 mm N/A
Tweeter Frontal Protrusion (D) 0.29 in. / 7.4 mm 0.92 in. / 23.4 mm
3
Due to ongoing product development, all specifications are subject to change without notice.
C2-650 sPeCiFiCaTions:
Woofer: Injection-molded, Mica-filled, Polypropylene Cone,
Butyl Rubber Surround, 1 in. Voice Coil on Kapton® Former,
Flat, Symmetrical Roll Spider, Ferrite Magnet
Tweeter: 0.75 in. (19 mm) Silk Dome, Ferrofluid Cooling /
Damping, Neodymium Magnet
Crossover Networks: 1st Order Low-Pass Filter, 2nd Order
High-Pass Filter, 3-Position Adjustable Tweeter Level, Premium
Mylar® Capacitors Premium Air-Core Inductors
Continuous Power Handling: 60 Watts
Recommended Amp Power: 15-100 Watts per channel (RMS)
Efficiency: 91.0 dB @ 1W/1m | 97.0 dB @ 1W/0.5m
Sensitivity: 94.0 dB @ 2.83V/1m
Nominal Impedance: 4 ohm
Frequency Response: 59 Hz - 22 KHz ± 3 dB
Included Components and Parts:
• Two C2-650cw 6.50-inch (165 mm) Woofers
• Two C2-075ct 0.75-inch (19 mm) Tweeters
• Two C2-650-XO Crossover Networks
• Two Flush-Mount Tweeter Fixtures
• Two Surface-Mount Tweeter Fixtures
• Two Metal Spring Clips for Tweeter Fixtures
• Two Grille Assemblies
• Two Self-Adhesive JL Audio Nameplates for Grilles
• Twelve #8 x 1.2 inch (30 mm) Sheet Metal Screws
• Four #6 x 1-inch (25 mm) Sheet Metal Screws
• Two 1.18-inch (30 mm) Machine Screws
• Eight Mounting Clips for Woofer Mounting
• Two 4.7 mm Female Crimpable Connectors
• Two 2.8 mm Female Crimpable Connectors
• Two 4.7 Male Crimpable Connectors
• Two 2.8 mm Male Crimpable Connectors
• Twelve Crimpable Spade Connectors
GeTTinG sTarTeD
•Turnofftheaudiosystem.Itisalso
advisabletodisconnectthenegative(–)
terminalofyourvehicle’sbatterywhenever
performinginstallationwork.
•Beforecutting,drillingorinsertinganyscrew,
checkclearancesonbothsidesoftheplanned
mountingsurface.Alsocheckforanypotential
obstacles,suchaswindowtracksandmotors,
wiringharnesses,etc.Checkbothsidesofthe
vehicle,manyvehiclesarenotsymmetrical!
•Alwayswearprotectiveeyewear.
sPeaKer PlaCemenT ConsiDeraTions
Inmostcases,yourspeakerswillbeplacedinto
factoryspeakerlocations.Ifyouhavesomespeaker
mountingflexibility,keepthefollowinginmind:
Lowermountinglocations,suchasthelowerfront
cornerofadoororakick-panelprovidethegreatest
pathlengthdistancesforthesoundemittedbythe
speakers.Forthisreason,theyaregenerallymore
desirablethanhighermountinglocations.Higher
mountinglocationswillusuallyresultinextreme
near-sidesoundstagebiaswhichcompromisesthe
stereolisteningexperience.
