ITEM#: JYL9801A

Product Dimension

●Thank you for purchasing our UFO Highbay. Please read the below articles carefully to see how to use this product safely.

●Warning contents and attention contents related to product safety use, please be sure to follow it.

UFO High Bay

The Installation must be carried out by

a qualified

electrician.

AC100-277V, 50/60Hz.V & AC277-480

40

o

F(40

o

C)113

o

F(45

o

C)

Installation Instruction

Dimmer connection (

With dimmable driver.)

Wiring Connection

Turn off the power, connect AC wire. black wire to L, white wire to N, and green wire to E.

this step can be omitted

if with non-dim driver

driver

Power

Input Current

Input Voltage

Frequency

150W

1.65A2.2A2.64A

100W200W

1.1A

240W

AC100-277V

50/60Hz

Model

Power

Input Current

Input Voltage

Frequency

100W

0.4A

0.6A

150W

AC277-480V

50/60Hz

Model

UHB0710-100W-XXX-X-XXK

UHB07B10-100W-XXX-X-XXK

UHB07B10-100W-XXX-X-XXK(MS)

UHB0710-100W-XXX-X-XXK-Z

UHB0715-150W-XXX-X-XXK

UHB07B15-150W-XXX-X-XXK

UHB07B15-150W-XXX-X-XXK(MS)

UHB0715-150W-XXX-X-XXK-Z

UHB0720-200W-XXX-X-XXK

UHB07B20-200W-XXX-X-XXK

UHB07B20-200W-XXX-X-XXK(MS)

UHB0720-200W-XXX-X-XXK-Z

UHB0724-240W-XXX-X-XXK

UHB07B24-240W-XXX-X-XXK

UHB07B24-240W-XXX-X-XXK(MS)

UHB0724-240W-XXX-X-XXK-Z

UHB071100W-X0-XX-X-HV-XKX(XX)

UHB071150W-X5-XX-X-HV-XKX(XX)

0.8A

200W

UHB0720-200W-XXX-HV-X-XXK(XX)

0.95A

240W

UHB0724-240W-XXX-HV-X-XXK(XX)

“XXX” can be any letter or number to represent the Light-emitting angle;

“X” can be H, L or HY(Y=number) to represent the lighting effect (no effect to power);

“XXK” can be 40K,50K,57K to indicate color temperature;

“(XX)” can be “(MS)” for with Motion Sensor or blank for without Motion Sensor.

2.Tighten the screw.

(This step can be omitted if there is

no screw hole.)

3.Hang up the light.

screw hole

screw

1.Lock the hook.

4.Lock the screw.

screw

Hook type:

AC277-480V

Hook:

AC100-277V

Hook:

239(9.4")

239(9.4")

271(10.7")

271(10.7")

306(12.0")

306(12.0")

220(8.7")

205(8.1")

188(7.4")

100W150W

200/240W

124(4.9")

140(5.5")

156(6.1")

239(9.4")

239(9.4")

271(10.7")

271(10.7")

306(12.0")

306(12.0")

100W150W

200W/240W

217(8.5")

191(7.5")

127(5")

152(6")

223(8.8")

159(6.3")
