Sida 1/12
JT-UM25C
USB-Messgerät
1. GENERAL INFORMATION
Dear customer,
Thank you for purchasing our product. In the following are information
which you should note before commissioning. Whenever you have
unfore seeable problems do not hesitate to contact us.
Today, USB connections are not only found at PCs, but also at power
banks, in cars or in trains. But not all connections are of best quality and
deliver even currents and voltages.
With the JT-UM25C, you always have all values in view. The meter supports
additional functions such as Quickcharge 2.0 and 3.0, as well as Apple 2.4
A, 2.1 A, 1 A, 0.5 A and Android DCP, and also oers convenient evaluation
via a wireless interface. With a measuring range of up to 24 V and 5 A, the
JT-UM25C is suitable for practically all applications. The integrated 1.44”
LCD display can be regulated in ve brightness levels and provides always
an overview of all measured values.
2. DEVICE OVERVIEW
Voltage measuring range
Current measuring range
Update rate
Measurement accuracy
Temperature range
Display size
Supported
QuickCharge
modes
4 - 24 V
0 - 5 A
2 Hz
0,001 V / 0,0001 A
-10 - 100 °C
1,44“
QC2.0, QC3.0,
Apple 2.4 A / 2.1 A / 1 A / 0.5 A,
Android DCP, Samsung
USB-A Port
(female)
BT switch
4x multifunctional buttons
microUSB-Port
USB-C-Output
(only VBUS, GND, CC1,
CC2)
1,44“
Color Display
BT status (changes by
a connection from
ashing light to a
permanent light)
USB-C-Input
(only VBUS,
GND, CC1, CC2)
USB-A Port
(male)
3. FUNCTION MENU AND NAVIGATION
General use
Measurement result
main page
QuickCharge
detection
Recording of charging
process
Cable impedance Measurement graph System settings
Use and to switch between the separate
menu pages.
Hold to switch to the next data group. Hold
to reset the current data group.
