INSTRUCTIONS

LVT1704-001B

[J,C]

For Customer Use:

Enter below the Model No. and Serial

No. which are located either on the rear,

bottom or side of the cabinet. Retain this

information for future reference.

Model No.

Serial No.

TH-D60

Consists of XV-THD60, SP-THD6W,

SP-THD6F, SP-THD6C and SP-THD6S

TH-D50

Consists of XV-THD50, SP-THD5W,

SP-THD5F, SP-THD5C and SP-THD5S

TH-D5

Consists of XV-THD5, SP-THD5W,

SP-THD5F, SP-THD5C and SP-THD5S

TH-D4

Consists of XV-THD4, SP-THD5W,

SP-THD5F, SP-THD5C and SP-THD5S

DVD DIGITAL THEATER SYSTEM

(TH-D60 only)

G-1

CAUTION

To reduce the risk of electrical shocks, fire, etc.:

1. Do not remove screws, covers or cabinet.

2. Do not expose this appliance to rain or moisture.

ATTENTION

Afin d’éviter tout risque d’électrocution, d’incendie, etc.:

1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir le

coffret de l’appareil.

2. Ne pas exposer l’appareil à la pluie ni à l’humidité.

CAUTION — button!

Disconnect the mains plug to shut the power off

completely (the STANDBY lamp goes off). When

installing the apparatus, ensure that the plug is easily

accessible.

The button in any position does not disconnect the

mains line.

• When the system is on standby, the STANDBY lamp

lights red.

• When the system is turned on, the STANDBY lamp

goes off.

The power can be remote controlled.

ATTENTION — Touche

Déconnectez la fiche d’alimentation secteur pour couper

l’alimentation complètement (le témoin STANDBY

s’éteint). Lors de l’installation de l’appareil, assurez-vous

que la fiche soit facilement accessible.

La touche , dans n’importe quelle position, ne

déconnecte pas le système du secteur.

• Quand le système est en attente, le témoin STANDBY

est allumé en rouge.

• Quand le système est sous tension, le témoin

STANDBY s’éteint.

L’alimentation peut être télécommandée.

Note to CATV system installer:

This reminder is provided to call the CATV system

installer’s attention to section 820-40 of the NEC which

provides guidelines for proper grounding and, in

particular, specifies that the cable ground shall be

connected to the grounding system of the building, as

close to the point of cable entry as practical.

[European Union only]

[Union européenne seulement]

Warnings, Cautions and Others

Mises en garde, précautions et indications diverses

G-2

IMPORTANT FOR LASER PRODUCTS

1. CLASS 1 LASER PRODUCT

2. CAUTION: Do not open the top cover or cabinet. There are

no user serviceable parts inside the unit; leave all servicing

to qualified service personnel.

3. CAUTION:

(For U.S.A.) Visible and/or invisible class II laser

radiation when open. Do not stare into beam.

(For Canada) Visible and/or invisible class 1M laser

radiation when open. Do not view directly with optical

instruments.

4. REPRODUCTION OF LABEL: CAUTION LABEL,

PLACED INSIDE THE UNIT.

IMPORTANT POUR PRODUITS LASER

1. PRODUIT LASER CLASSE 1

2. ATTENTION: N’ouvrez pas le couvercle supérieur ni le

coffret de l’appareil. Il n’y a aucune pièce réparable par

l’utilisateur à l’intérieur de l’appareil; confiez toute

réparation à un personnel qualifié.

3. ATTENTION:

(Pour les Etats-Unis) Radiation laser de classe II visibles

et/ou invisible si l’appareil est ouvert. Ne regardez pas le

rayon.

(Pour le Canada) Rayonnement laser visible et/ou

invisible de classe 1M une fois ouvert. Ne pas regarder

directement avec des instruments optiques.

4. REPRODUCTION DE L’ÉTIQUETTE: ÉTIQUETTE

DE PRÉCAUTION PLACÉE À L’INTERIEUR DE

L’APPARE IL.

For U.S.A.

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation.

This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is

no guarantee that interference will not occur in a

particular installation. If this equipment does cause

harmful interference to radio or television reception,

which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and

receiver.

Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician

for help.

CAUTION

Changes or modifications not approved by JVC could

void the user’s authority to operate the equipment.

For Canada

THIS DIGITAL APPARATUS DOES NOT EXCEED

THE CLASS B LIMITS FOR RADIO NOISE

EMISSIONS FROM DIGITAL APPARATUS AS SET

OUT IN THE INTERFERENCE-CAUSING

EQUIPMENT STANDARD ENTITLED “DIGITAL

APPARATUS,” ICES-003 OF THE DEPARTMENT OF

COMMUNICATIONS.

Pour le Canada

CET APPAREIL NUMERIQUE RESPECTE LES

LIMITES DE BRUITS RADIOELECTRIQUES

APPLICABLES AUX APPAREILS NUMIRIQUES DE

CLASSE B PRESCRITES DANS LA NORME SUR LE

MATERIEL BROUILLEUR; “APPAREILS

NUMERIQUES”, NMB-003 EDICTEE PAR LE

MINISTRE DES COMMUNICATIONS.

CAUTION:

Excessive sound pressure from earphones or headphones

can cause hearing loss.

ATTENTION:

Une pression acoustique excessive des écouteurs ou du

casque d’écoute peut entraîner une perte auditive.

CAUTION!

To avoid personal injury or accidentally dropping the

unit, have two persons unpack, carry, and install the unit.

ATTENTION!

Pour éviter toute blessure personnelle ou toute chute

accidentelle de l’appareil, celui-ci doit être déballé,

transporté et installé par deux personnes.

TH-D60: 30.7 kg/68 lbs

TH-D50/TH-D5/TH-D4: 23.7 kg/53 lbs

Notes on installing the System

• Select a location which is level, dry and neither too hot nor

too cold between 5°C and 35°C (41°F and 95°F).

• Do not install the System in a location subject to

vibrations.

• Do not put heavy objects on the System.

Avoid moisture, water, dust, and high

temperatures

• Do not install the System in moist or dusty locations.

• If water gets inside the System, turn off the power and

remove the plug from the wall outlet, then consult your

dealer. Using the System in this state may cause a fire or

electrical shock.

• Do not expose the System to direct sunlight or place it near

a heating device.

To prevent malfunctions or damage to the System

• Do not insert any metallic objects, such as wires, hairpins,

coins, etc. into the System.

• Do not block the vents.

Notes on the power cord

• When you are away on travel or otherwise for an extended

period of time, remove the plug from the wall outlet. A

small amount of power is always consumed while the

power cord is connected to the wall outlet.

• When unplugging the System from the wall outlet, always

pull the plug, not the power cord.

• Disconnect the power cord before cleaning or moving the

System.

• Do not modify, twist or pull the power cord, or put

anything heavy on it. Doing so may cause fire, electric

shock, or other accidents.

About copyright laws

Observe the copyright laws in your country before recording

from original sources. Recording of copyrighted material

may infringe copyright laws.

About the copyguard system

The discs are protected by the copyguard system. When

connecting the System to a TV via a VCR, or to a TV with a

built-in VCR, the copyguard system activates and distortion

of the picture may occur.

Notes on installing and using the speakers

• Place the speakers and subwoofer on a flat and level

surface.

• The speakers are magnetically shielded to avoid color

distortions on TVs. If the color on a TV is distorted,

perform the following procedure:

– Turn off the TV’s main power switch or unplug it

before installing the speakers. Then wait at least

30 minutes before turning on the TV’s main power

switch again.

Some TVs may still be affected even though you have

followed the above procedure. If this happens, move the

speakers away from the TV.

• The subwoofer is not magnetically shielded. To avoid

color distortion, do not place it near the TV or monitor.

• When moving the speakers and subwoofer, do not pull the

speaker cords. Doing so may cause the speakers and/or

subwoofer to fall over, causing damage or injury.

• When installing the speakers on a wall, be sure to have

them installed by qualified personnel. DO NOT install the

speakers on a wall by yourself.

• Do not lean against the speakers, as they could fall down

or break, possibly causing an injury. Be especially careful

that children do not lean against them.

About the adjustment of volume

Always set the volume to the minimum level before starting

any source. If the volume is set at a high level, the sudden

blast of sound could permanently damage your hearing and/

or blow out the speakers.

To clean the System

• Use a soft cloth. Follow the relevant instructions on the

use of chemically-coated cloths.

• If the System is heavily stained, apply a small amount of

water or neutral detergent to the cloth and wipe clean, then

wipe with a dry cloth.

• Do not use benzene, thinner or other organic solvents and

disinfectants. These may cause deformation or

discoloring.

Precautions

There are no user-serviceable parts inside. If anything

goes wrong, unplug the power cord and consult your

dealer.

Before using this System

This System accommodates the NTSC system, and

also can play discs/files recorded with PAL system.

Note that an PAL video signal on a disc/file is

converted to the NTSC signal and output.

It is possible to play back finalized +R/+RW (DVD

Video format only) discs. “DVD” lights on the display

panel when a +R/+RW disc is loaded.

DVD-R/-RW: This System does not support “multi-

border” discs.

CD-R/-RW:

– This System supports “multi-session” discs (up to

20 sessions).

– This System cannot play “packet write” discs.

Unplayable discs—unwarranted

Playing back the following discs generates noise and

damages the speakers.

• DVD-ROM, DVD-RAM, DualDisc* (non-DVD side)

• CD-ROM, CD-I (CD-I Ready), Photo CD, SACD

• Unfinalized discs (except DVD VR)

• Discs with an irregular shape or discs with tape, stickers

or paste on either the label side or playback side

• Warped, dirty, or scratched discs

*The Non-DVD side of a “DualDisc” does not comply with

the “Compact Disc Digital Audio” standard. Therefore, the

use of Non-DVD side of a DualDisc on this product may

not be recommended.

iPod

*Only still pictures are available.

If the iPod does not play correctly, update your iPod

software to the latest version. For details about

updating your iPod, check on the Apple web site

<http://www.apple.com>.

USB mass storage class device

A USB flash memory device, hard disk drive, multimedia

card reader, digital camera, etc. can be used with this System

through a USB connection.

This System is compatible with USB 2.0 Full-Speed.

This System cannot recognize a USB mass storage

class device whose rating exceeds 5 V/500 mA.

Some discs/files may require operations that differ

from those explained in this manual.

Some discs/devices/files may not be recognized or

played back correctly due to their characteristics.

Playable disc types

Type of disc Types of media

DVD Video

• Discs on the market

• DVD-R/-R DL/-RW

• +R/+RW

• DualDisc* (DVD side only)

DVD Audio

• Discs on the market

• DVD-R/-R DL/-RW

• +R/+RW

Super Video CD

(SVCD)/Video CD

(VCD)

• Discs on the market

• CD-R/-RW

Audio CD

• Discs on the market

• CD Text (Audio part only)

• CD-R/-RW

A disc recorded in

the DVD VR format • DVD-R/-RW

Audio/video files on

a disc ( 4)

• DVD-R/-R DL/-RW in UDF

Bridge format

• CD-R/-RW in ISO 9660

format

Region code of DVD Video

DVD Video players and DVD Video discs have their own

Region Code numbers. This system can play back DVD

Video discs whose Region Code numbers include “1.”

Ex.:

Playable digital devices

JVC bears no responsibility for any loss of data in an

iPod and/or USB mass storage class device while using

this System.

iPod model AUDIO VIDEO

iPod nano 1GB/2GB/4GB √

iPod nano (2nd Generation)

2GB/4GB/8GB √

iPod mini 4GB/6GB √

iPod (4th Generation)

20GB/40GB √

iPod photo (4th Generation)

20GB/30GB/40GB/60GB √ √ *

iPod video (5th Generation)

30GB/60GB/80GB √ √

Playable discs/devices/files

The following files in a disc or a USB mass storage class

device can be played back.

If a file on a USB mass storage class device exceeds

the following conditions, it may not be played back

correctly:

– Maximum data transfer rate: 2 Mbps

– Maximum frame rate: 30 fps for progressive

– Maximum file size: 2 GB

The System recognizes up to 150 tracks (files) per

group, and 99 groups per disc/device. The total

number of tracks (files) that the System can detect is

4000.

Information about the recording

conditions for the files on a disc/

device

MP3/WMA files

• The System supports MP3/WMA files recorded at a bit

rate of 32 – 320 kbps and a sampling frequency of 16 kHz,

22.05 kHz, 24 kHz*, 32 kHz, 44.1 kHz, or 48 kHz.

• It is recommended to record each file at a sample rate of

44.1 kHz and at a data transfer rate of 128 (96*) kbps.

*For WMA only

WAV files

• The System supports WAV files recorded at a

quantization rate of 8 or 16 bit and a sampling frequency

of 8 kHz, 11.025 kHz, 12 kHz, 16 kHz, 22.05 kHz,

24 kHz, 32 kHz, 44.1 kHz, or 48 kHz.

• It is recommended to record each file at a sample rate of

44.1 kHz and at a quantization rate of 16 bit Linear PCM.

JPEG files

• It is recommended to record a file at 640 x 480 resolution.

(If a file has been recorded at a resolution of more than

640 x 480, it will take a longer time to be displayed.)

• This System can only play baseline JPEG files.

ASF files

• The System supports MPEG-4 files with the following

conditions:

File format: ASF

Visual profile: MPEG-4 SP (Simple Profile)

Audio CODEC: G.726

Max. picture size: 352 x 288 (CIF)

Max. bit rate: 384 kbps

MPEG1/MPEG2 files

• The stream format should conform to the MPEG system/

program stream.

• 720 x 576 pixels (25 fps)/720 x 480 pixels (30 fps) is

recommended for the highest resolution.

• This system also supports resolutions of 352 x 576/480 x

576/352 x 288 pixels (25 fps) and 352 x 480/480 x 480/

352 x 240 pixels (30 fps).

• The file format should be MP@ML (Main Profile at Main

Level)/SP@ML (Simple Profile at Main Level)/MP@LL

(Main Profile at Low Level).

• Audio streams should conform to MPEG1 Audio Layer-2

or MPEG2 Audio Layer-2.

DivX files

• The System supports DivX files whose resolution is

720 x 480 pixels or less (30 fps), and 720 x 576 pixels or

less (25 fps).

• Audio stream should conform to Dolby Digital (including

multi-channel) or MPEG1 Audio Layer-3 (MP3).

• The System does not support GMC (Global Motion

Compression).

• Files encoded in the interlaced scanning mode may not be

played back correctly.

Playable file types

Type of file Playable files Extensions

Audio

MP3 <.mp3>

WMA <.wma>

WAV <.wav>

Picture JPEG <.jpg>, <.jpeg>

Movie

ASF <.asf>

MPEG-1 <.mpg>, <.mpeg>

MPEG-2 <.mpg>, <.mpeg>,

<.mod>

DivX (6.x, 5.x,

4.x and 3.11)

<.divx>, <.div>,

<.avi>

If anything is missing, contact your dealer immediately.

• Remote control (x 1)

• Batteries (x 2)

• FM antenna (x 1)

• AM loop antenna (x 1)

• Composite video cord (x 1)

• Connector for iPod

– TH-D60/TH-D50: Docking station for iPod (x 1)

– TH-D5/TH-D4:

Connection cable for iPod (x 1)

Stand for iPod (x 1)

• Speaker cords: 3 m (10 ft) (x 4), 8 m (26.3 ft) (x 2)

• Feet

– TH-D60: For surround speakers (x 8)

– TH-D50/TH-D5/TH-D4: For front and surround

speakers (x 16)

• Screws (TH-D60 only): M5 x 85 mm (3-3/8 inches) (x 6)

Do not expose batteries to heat or flame.

If the range or effectiveness of the remote control

decreases, replace both batteries.

If you connect speakers other than those supplied for

the System, use speakers of the same speaker

impedance (SPEAKER IMPEDANCE) indicated on

the rear of the center unit.

DO NOT connect more than one speaker to one

speaker terminal.

Checking the supplied

accessories

Putting batteries into the remote

control

R03 (UM-4)/AAA (24F) type

dry-cell batteries (supplied)

Connecting the speakers and

subwoofer

Connecting the speaker cords

Connect the speaker cords both to the center unit and to

each speaker.

On the center unit:

On the speaker:

• Connect the black cords to the r terminals.

• Connect the white cords to the q terminals.

Speaker cords:

: 3 m (10 ft)

: 8 m (26.3 ft)

To front right speaker

(SP-THD6F/SP-THD5F)

To center speake

(SP-THD6C/SP-THD5C)

To front left speaker

(SP-THD6F/SP-THD5F)

To subwoofe

(SP-THD6W

SP-THD5W)

To surround left speaker

(SP-THD6S/SP-THD5S)

To surround right speaker

(SP-THD6S/SP-THD5S)

Center unit

Speaker cord

Getting started

You can enjoy surround sound by placing the speakers as

illustrated (Speaker layout A or B).

Speaker layout A

Select “S.SPK R” as the speaker position mode for

this layout. ( 12)

To obtain the best possible surround sound from this

System, place all the speakers except the subwoofer

at the same distance from the listening position. If it

is impossible, adjust the delay time from DELAY

menu. ( 24)

Speaker layout B

Select “S.SPK F” as the speaker position mode for

this layout. ( 12)

Place the surround speakers close to the center

speaker.

It is recommended to place the surround speakers

horizontally (see below).

When placing the speakers horizontally

Lay the speakers horizontally so that the JVC logos are

positioned as illustrated below.

TH-D50/TH-D5/TH-D4 only: you can also lay the front

speakers as illustrated below.

TH-D60: Do not lay down the front speakers

horizontally.

You can turn the JVC logos to make them

legible.

Attaching the base plates—required for the SP-

THD6F only

Speaker layout

Connect the

speaker cord.

Route the speaker

cord.

This side should

face the front.

Use the supplied screws (M5 x 85 mm/3-3/8 inches) to

attach the base plate to the speaker.

Front right (R)

Subwoofer

(SW)

Surround right

(SR)

Center (C)

Front left (L)

Surround left

(SL)

Attaching the feet

When placing the speakers horizontally, attach the feet to

the bottom of the speakers as illustrated.

Subwoofer (SW)

Surround right (SR)

Center (C)

Front left (L)

Surround left (SL)

Front right (R)

Ex.:

SL SR

L SL SR R

Peel off

Do not connect the power cord

until all other connections have

been made.

XM Mini-Tuner system—TH-D60 only

For better reception, install the XM Mini-Tuner Home

Dock antenna in the following location:

– Near a south-facing window with aiming the

antenna at the sky directly

– Where “Channel 1” can be heard clearly

– Where the Antenna Aiming display shows a value

higher than 0 for either satellite or terrestrial signal

strength ( 25)

AM and FM antennas

Make sure the antenna conductors do not touch any

other terminals, connecting cords or power cords.

Connect the TV to the appropriate video out jacks to view

the playback picture.

The picture quality order is as follows:

HDMI > Component video > S-video > Composite

video

Make the following settings after connecting the TV:

– Scanning mode ( 14)

– MONITOR TYPE ( 23)

Connection using the HDMI terminal

You can make the following settings for the TV when

the HDMI connection is used:

– HDMI DVI COLOR ( 23)

– HDMI OUT ( 23)

– HDMI AUDIO OUT ( 24)

– DOWN MIX ( 24)*

Use a certified HDMI cable, which has the HDMI

logo.

You can use a monitor with a DVI terminal by

connecting with a DVI-HDMI conversion cable.

When you play HDCP (High-Bandwidth Digital

Content Protection) source, allow a few seconds for

the sound and picture to be transmitted to the

speakers and TV while the confirmation process is

completed.

On some TV, no sound may come out during

playback of sources such as DVD Audio even when

the HDMI AUDIO OUT setting is “ON” ( 24).

*This setting is available only when the speaker position

mode is set to “S.SPK F” ( 12).

Connecting the antennas

For better FM reception

XM Mini-Tuner

(not supplied)

XM Mini-Tuner Home Dock

antenna (not supplied)

Extend it horizontally.

FM antenna

(supplied)

AM loop antenna

(supplied)

Turn it until the best

reception is obtained.

FM outdoor antenna

(not supplied)

Standard type (75 Ω

coaxial) connector FM outdoor antenna cord

(not supplied)

Connecting a TV

From HDMI input

terminal

HDMI cable (not supplied)

Getting started

Connection using the component

video jacks

For the BNC connection, use a plug adapter (not

supplied).

Connection using the S-video or

composite video jack

Connection for “VIDEO1”—TH-D60

Select “VIDEO1” as the source ( 11) for

playing a component connected as follows.

Video connection

No sound signal comes into HDMI VIDEO 1 IN

terminal. Make audio connection to listen to the

sound (see the right column).

Audio connection

Connecting a digital component

The initial setting for the audio input setting is

“COAX.” When using OPTICAL terminal, change the

setting to “OPT” before playing back. ( 14)

Connecting an analog component

To listen to the sound from AUDIO MULTI IN jacks,

perform the following procedure:

– Place the speakers by following “Speaker layout

A” ( 6).

– Select “S.SPK R” as the speaker position mode.

( 12)

Select “5.1CH” as the audio input setting before

playing back. ( 14)

Connecting external components

From component

video input

Component video

cord (not supplied)

Green

Blue

Red

Composite video cord

(supplied)

S-video cord (not supplied)

A From Composite video input

B From S-video input

Align the

5 marks.

DVD player,

etc.

HDMI cable

(not supplied)

From HDMI video output

DBS (Direct

Broadcasting

Satellite)

tuner, etc.

Digital coaxial cable

(not supplied)

A From digital coaxial output

B From digital optical output

Digital optical cable

(not supplied)

DVD player,

etc.

A From center channel audio output

B From front left/right channel audio outputs

C From subwoofer output

D From surround left/right channel audio outputs

RCA pin plug cord (not supplied)

Do not connect the power cord

until all other connections have

been made.

Connection for “VIDEO2”—TH-D60

Select “VIDEO2” as the source ( 11) for

playing a component connected as follows.

Video connection

*Connect an external component with the same kind of cable

as the one used to connect TV. ( 8)

Audio connection

Connecting a digital component

The initial setting for the audio input setting is “OPT.”

When using COAXIAL jack, change the setting to

“COAX” before playing back. ( 14)

Connecting an analog component

Select “2CH” as the audio input setting before

playing back. ( 14)

Connection for “VIDEO” —TH-D50/TH-

D5/TH-D4

Select “VIDEO” as the source ( 11) for playing

a component connected as follows.

Video connection

*Connect an external component with the same kind of cable

as the one used to connect TV. ( 8)

Audio connection

Connecting a digital component

Select “OPT” as the audio input setting before

playing back. ( 14)

Connecting an analog component

Select “2CH” as the audio input setting before

playing back. ( 14)

Plug in the System only after all the connections have

been completed.

Composite video cord*

(not supplied)

S-video cord*

(not supplied)

A From composite video output

B From S-video output

Align the

5 marks.

VCR, etc.

DBS (Direct

Broadcasting

Satellite)

tuner, etc.

Digital coaxial cable

(not supplied)

A From digital coaxial output

B From digital optical output

Digital optical cable

(not supplied)

From audio output

RCA pin plug cord

(not supplied)

VCR, etc.

Connecting the AC power cord

Composite video cord*

(not supplied)

S-video cord*

(not supplied)

A From composite video output

B From S-video output

Align the

5 marks.

VCR, etc.

DBS (Direct

Broadcasting

Satellite)

tuner, etc.

From digital optical output

Digital optical cable

(not supplied)

From audio output

RCA pin plug cord

(not supplied)

VCR, etc.

Available video output terminals for each source

Source DVD USB iPod VIDEO2/

VIDEO VIDEO1

Terminal

HDMI √ √ √

COMPONENT √ √

S-VIDEO √ √ √ √

VIDEO (Composite video) √ √ √ √

Do not connect the power cord

until all other connections have

been made.

Turning the power on or off

To turn off the System by using the sleep timer

To check the remaining time, press the button once.

Selecting the source

To select the source from the center unit

*1TH-D60 only

*2TH-D50/TH-D5/TH-D4: The FM/AM button is used instead

of FM/AM/XM.

*3Make sure that the appropriate audio input setting have been

made for the source (VIDEO1/VIDEO2 or VIDEO).

( 14)

Adjusting the volume

To turn off the volume instantly

To restore the volume, press the button again, or adjust the

volume level.

Prohibiting disc ejection

1Turn off the System.

2Lock the disc tray.

To unlock the disc tray, perform the above procedure

again. “UNLOCKED” appears on the display.

To do Indication

Play back a disc DVD 15

Play back a file on a

USB mass storage

class device

USB 15

Play back an iPod IPod 28

Listen to an XM

Satellite Radio*1,

FM, or AM station

XM*1, FM,

or AM

25*1,

Play back an

external component

• TH-D60: VIDEO1/

VIDEO2

• TH-D50/TH-D5/

TH-D4: VIDEO

VIDEO1*329

VIDEO2*329

VIDEO*329

– – (off) = 10 = 20 = 30 = 60 = 90 = 120

= = = 150 180 (back to the beginning)

(unit: minutes)

“MUTING” appears on the display.

“LOCKED” appears on the

display.

(On the center unit)

«Hold

See page 10 for button

locations.

Selecting the speaker position

mode

Select the speaker position mode according to your speaker

layout ( 6).

1Turn off the System. ( 11)

3Select the appropriate speaker position mode

according to your speaker layout ( 6).

As the speaker position mode is changed, the

following settings are also changed automatically:

– The output level settings of the speakers and

subwoofer (see below) are initialized.

– The surround mode ( 13) is set to “AUTO

SUR.”

Adjusting the output level of the

speakers and subwoofer

2Adjust the output level.

Different output level settings can be stored for the

following two groups of sources:

– TH-D60: DVD, USB, IPod, VIDEO1*1, VIDEO2

TH-D50/TH-D5/TH-D4: DVD, USB, IPod, VIDEO

– TH-D60: FM, AM and VIDEO1*2

TH-D50/TH-D5/TH-D4: FM and AM

TH-D60 only: When the source is “XM,” this

adjustment is not available.

You can also make adjustments from the LEVEL

menu ( 24) when the speaker position mode is

“S.SPK R.”

*1With “COAX” or “OPT” selected as the audio input setting

( 14)

*2With “5.1CH” selected as the audio input setting

( 14)

Sound settings and adjustments

Set the remote

control mode

before operation.

«Hold

S.SPK R

For speaker layout A

• The R indicator lights

on the display.

S.SPK F

For speaker layout B

• The F indicator lights

on the display.

• When the speaker position mode is “S.SPK R”:

• When the speaker position mode is “S.SPK F”:

The items you can adjust differ depending on

the selected speaker position mode (see the

left column).

FRNT L =FRNT R = CENTER =SURR L

= = = SURR R SUBWFR (back to the

beginning)

CENTER =SURR =SUBWFR = (back to

the beginning)

Sound and monitor settings

Adjusting the bass and treble

sounds

2Adjust the level.

Using the surround mode

Select one of the available surround

modes.

•During 2-channel playback with “S.SPK R” speaker

position mode:

•During multi-channel playback with “S.SPK R”

speaker position mode:

•During playback with “S.SPK F” speaker position

mode:

To check the surround mode currently selected, press

SURROUND once.

TH-D60 only:

– When the source is “VIDEO 1” with “5.1CH”

selected as the audio input setting ( 14), the

surround mode setting is ineffective. All incoming

signals are emitted through the corresponding

speakers. “MULTI CH” appears on the display.

– When the source is “XM,” the surround mode

cannot be changed.

During playback of ASF, MPEG-2, or MPEG-1 files,

the surround mode setting is ineffective.

For DVD Audio, when “LR ONLY” appears on the

display, activate the surround mode for the multi-

channel reproduction.

Available surround modes

The surround modes you can select depend on the

playback source and the selected speaker position

mode ( 12). For details on each surround

mode, see “Available surround modes” on the

right column.

AUTO SUR =MOVIE =MUSIC =STADIUM

= = ALL ST OFF = (back to the beginning)

When the source is “FM” or “AM,” you can only

select “ALL ST.”

AUTO SUR = currently selected mode* =OFF =

(back to the beginning)

*When “AUTO SUR” is selected, the System

automatically selects a proper multi-channel surround

mode, such as “DOLBY D (Dolby Digital)” or “DTS

(DTS Digital Surround).”

AUTO SUR =MOVIE =WIDE/2CH =

SUPER W =OFF = (back to the beginning)

When the source is “FM” or “AM,” the surround

mode cannot be activated.

TRE Adjusts the treble sound

BASS Adjusts the bass sound

Surround mode for “S.SPK R”

AUTO SUR

(Auto Surround)

Selects an appropriate

surround mode according to

the incoming signals

MOVIE (Dolby Pro

Logic II Movie) For movie sources

MUSIC (Dolby Pro

Logic II Music) For music sources

STADIUM

Adds clarity and spreads the

sound, as if in an outdoor

stadium

ALL ST

(All Channel

Stereo)

Reproduces a larger stereo

sound field using all the

activated speakers

OFF (Off) Deactivates surround mode

Surround mode for “S.SPK F”

AUTO SUR

(Auto Surround)

Selects an appropriate

surround mode according to

the incoming signals

MOVIE For movie or multi-channel

music sources

WIDE/2CH For 2-channel music sources

SUPER W

(Super Wide)

Reproduces broader sound

field

OFF (Off) Deactivates surround mode

Sound and monitor settings

Setting the audio input for

external components

Set the audio input of the external component for “VIDEO1/

VIDEO2” (TH-D60) or “VIDEO” (TH-D50/TH-D5/TH-

D4).

2TH-D60 only: Select a source you want to set the

audio input for.

3Select an appropriate audio input according to

the audio connection. ( 8, 9)

You can select the following settings for each source

(underlined items are the initial settings for each

source):

– “VIDEO1”: 5.1CH*2, COAX*3, and OPT*3

– “VIDEO2”: 2CH, COAX*3, and OPT*3

– “VIDEO”: 2CH and OPT

If your System is the TH-D60, make the audio input

setting for both “VIDEO1” and “VIDEO2.”

*1“AIN.1” or “AIN.2” appears on TH-D60, and “AIN.” on

TH-D50/TH-D5/TH-D4.

*2TH-D60 only: When the speaker position mode is set to

“S.SPK F,” “5.1CH” is not selectable.

*3TH-D60 only: It is not possible to select the same audio

input setting for “VIDEO 1” and “VIDEO 2.” For example,

when “COAX” is assigned to “VIDEO 1,” it is not

selectable for “VIDEO 2.”

Select the scanning mode according to the type

of TV and connection method.

To use the progressive mode, connect the TV to the

HDMI MONITOR OUT terminal or COMPONENT

jacks*1. ( 7)

1Select “DVD” or “USB” as the source.

( 11)

3Select an appropriate scanning mode, then

confirm the selection.

You can get better picture quality in the following

orders:

– 1080I > 720P

– 480P > 480I

When the picture is not shown correctly, change

the scanning mode to the interlaced mode.

When the TV is connected through S-VIDEO or

VIDEO jack, the scanning mode setting has no

effect.

*1Activate progressive mode only when your TV supports

progressive video signals.

*2Selectable only when the TV is connected via COMPONENT

jacks. ( 8)

*3Selectable only when the TV is connected via HDMI

MONITOR OUT terminal. ( 7)

Item*1Current setting

AIN.1 For “VIDEO 1”

AIN.2 For “VIDEO 2”

2CH For connection via the

AUDIO IN jacks

5.1CH For connection via the

AUDIO MULTI IN jacks

COAX For connection via the

COAXIAL jack

OPT For connection via the

OPTICAL terminal

Scanning mode setting

480I*2

To see the picture in interlaced mode.

1080I*3

480P To see the picture in progressive

mode.

720P*3

AUTO*3

The System automatically emits the

video signal to get the best picture

quality on your TV.

«Hold

Select Confirm

See page 12 for button

locations.

Playing back a disc

1Select “DVD” as the source. ( 11)

3Place a disc on the tray.

4Start playback.

• JPEG: Slide-show playback starts.

• MP3/WMA/WAV: The file control display appears

on the TV. ( 22)

Playing back a file on a USB mass

storage class device

1Connect a USB mass storage class device while

the System is turned off.

2Turn on the System, then select “USB” as the

source. ( 11)

Playback starts automatically.

Press 3 (play button) to start playback if the file is not

played back automatically.

• JPEG: Slide-show playback starts.

• MP3/WMA/WAV: The file control display appears

on the TV. ( 22)

The following icons show the available disc/file types for

the target function:

Initial settings

Make the following settings before playing back discs/

files.

• Scanning mode ( 14)

• MONITOR TYPE ( 23)

• ON SCREEN LANGUAGE ( 23)

If a still picture is displayed for about 5 minutes, the

System automatically dims the screen (screen

saver function). You can deactivate the screen

saver function. ( 23)

When several types of files (music, picture or

movie) are recorded on a disc or device, select

the file type you want to play. ( 23)

For messages and icons appearing on the display,

see “Messages and icons shown on the TV during

disc/file playback” ( 31).

Set the remote control mode

before operation.

For disc playback

For playback of a file on a USB

mass storage class device

Operating the touch sensor

panel

You can operate the playback control

buttons on the center unit simply by

touching them.

When you touch any one of these

buttons, it lights briefly in blue.

Basic playback

(On the center unit)

Label side up When placing an 8 cm

(3-3/16 inches) disc

USB mass storage

class device

Disc/file playback

For DVD Video/DVD Audio

2Select the desired item, then confirm the

selection.

For some discs, you can also select items by using

the number buttons.

*TH-D50/TH-D5/TH-D4: The TOP MENU/PG button is used

instead of TOP MENU/PG/DIRECT.

For VCD/SVCD with PBC

The Play Back Control function (PBC) allows you

to operate the VCD/SVCD using menus.

Select the number of the desired

item while the menu is displayed on

the TV.*

• To move to the next or previous page

of the current menu

• To return to the previous menu

To perform playback without PBC

• While playback is stopped, select the desired track by

using the number buttons.*

• Select the desired track by pressing x repeatedly, then

press 3 (play button).

To activate the PBC function, press TOP MENU(/PG/

DIRECT) MENU(/PL). or

While playing back a VCD or SVCD with PBC

(“PBC” appears on the display), some functions

such as time search, do not work.

*For details on using the number buttons, see “How to use the

number buttons” ( 10).

Selecting the beginning of a desired

scene or song

*1For DVD Video, DVD VR, VCD, and SVCD discs, this

function is not available while playback is stopped.

*2For DVD Video and DVD VR discs, you can select a title/

program while playback is stopped.

*3For details on using the number buttons, see “How to use the

number buttons” ( 10).

*4When selecting the chapter/track/file number from the on-

screen bar, see “Using the on-screen bar” ( 21).

Selecting the desired position of a

scene or song

*1This function works only within the same title/program/file.

*2This function is not available during repeat play.

Using the disc menu

For a DVD Video disc For a DVD Audio disc

* *

Select Confirm

Locating a desired scene or song

To do Disc/file

Skip chapter/track/file

Select the chapter/

track/file number*3 *4

Select the title/

program or playlist/

group number*3

• Enter the number

while “– –” is flashing

on the display

To do Disc/file

Move the playback

position back by

10 seconds (one-touch

replay)*1 *2

Skip at approximately

5-minute intervals*1

Disc/file playback

Programing the playing

order—program play

2Select the desired chapters/

tracks.

•For DVD Video, DVD Audio,

MP3 and WMA: Enter a title/group

number, then a chapter/track

number.*

•For VCD, SVCD and CD: Enter a track number.*

To clear the programs

To check the program contents

To return to normal playback

To program the tracks in the bonus group on a DVD

Audio disc, perform the “Playing back a bonus group”

procedure ( 20) before operation.

You can program up to 99 steps.

*For details on using the number buttons, see “How to use the

number buttons” ( 10).

Playing at random—random

play

To return to normal playback

To play the tracks in the bonus group on a DVD

Audio disc during random play, perform the “Playing

back a bonus group” procedure ( 20) before

operation.

Playing repeatedly—

repeat play

You can repeat the desired part from the on-screen

bar (A-B repeat). ( 21)

This function is not available when playing back a

VCD/SVCD disc with PBC ( 17).

*For DVD Video and DVD VR discs, this function is not

available while playback is stopped.

Changing the playback mode

Program play and random play cannot be used for a USB

mass storage class device.

Press the button repeatedly until both the

program window and

disappear from the TV.

Program window

One by one All programs at once

«Hold

Press the button repeatedly until both the

program window and

disappear from the TV.

The repeat modes you can

select depend on the

playback discs/files.

On the

display On the TV Meaning

REPEAT GROUP Repeat current group

Repeat current title

Repeat current

program

Repeat current

playlist

ALL REPEAT ALL

Repeat all titles/

programs/tracks/files

REPEAT TRACK,

REPEAT STEP

Repeat current track

, Repeat current

chapter

indication

Repeat mode is

deactivated

See page 15 for button

locations.

Changing the language/sound/scene

angle

For DVD Audio, the functions take effect for the

moving picture part only.

*1For DVD VR and SVCD discs, the subtitle indication

appears and can be changed by performing the above

procedure even if no subtitles are recorded.

*2Some subtitle or audio languages are abbreviated in the

pop-up window. See “Language code list” ( 30).

Special picture playback

To return to normal playback

• While playing back frame by frame or in slow-motion,

press 3 (play button).

• While zooming in the picture, select “OFF” by pressing

ZOOM repeatedly while holding SHIFT.

For DVD Audio, the functions take effect for the

moving picture part only.

*1For DVD Video and DVD Audio, reverse slow-motion is also

available by pressing (SLOW repeatedly.

*2To zoom in JPEG files, pause the playback first.

*3On some files, using cursor (3 2 K 5/ / / ) cannot move the

zoomed-in area during playback.

Advanced operations

To do Disc/file

Select the subtitle

language*1 *2

• To show/hide the

subtitle, press

SUBTITLE.

Select the audio

language/audio

channel*2

Select the view angle «Hold

To do Disc/file

Play back frame by

frame

Play back in slow-

motion*1

Enlarge the picture*2

• Change the scene

magnification, then

move the zoomed-in

area.

«Hold

Disc/file playback

Adjusting the picture

quality (VFP)

You can adjust the picture mode.

2Select the desired preset, then finish the setting.

To adjust the picture tone

1Select “USER1” or “USER2” (see above).

2Select a parameter, then confirm the selection.

3Adjust the parameter, then confirm the

selection.

4Repeat steps 2 and 3 to adjust others.

When connecting the TV to the HDMI MONITOR

OUT terminal ( 7), the VFP setting has no

effect.

Playing back a bonus group

Some DVD Audio discs have a “bonus group.”

To play back a bonus group, you have to enter the specific

“key number” (a password).

1Select a bonus group.

The key number entry screen appears.

2Enter the key number, then confirm the entry.

To clear the key number entry

Selecting browsable still

pictures

While playing back a track linked to browsable still pictures

(B.S.P), you can select the still pictures (turn the page).

• If a track is linked to browsable still pictures, they are

usually shown automatically during playback.

Select the desired still picture.

NORMAL Normally select this.

CINEMA Suitable for movies

USER1/

USER2

You can adjust parameters that affect

picture appearance. (See below.)

GAMMA Controls the brightness of the

neutral color

BRIGHTNESS Controls the brightness of the

entire picture

CONTRAST Controls the contrast

SATURATION Controls the color depth

TINT Controls the tint

SHARPNESS Controls the sharpness

Select Finish

Select Confirm

Special playback for DVD Audio

On the TV On the display

Enter the number

Confirm

See page 15 for button

locations.

Using the on-screen bar

You can use various functions from the on-

screen bar.

Basic operation procedure

2Select the desired item (see the right column),

then confirm the selection.

After confirming the selection...

•When the pull-down menu appears, select the desired

item by pressing cursor 5 Y/ repeatedly, then confirm the

selection by pressing ENTER.

•When a number-entry box appears, enter the number

by using the number buttons (0-9), then confirm the entry

by pressing ENTER.

To correct a misentry:

– setting: press cursor 2 repeatedly to clear the

misentry, then re-enter the number.

– setting: re-enter the number.

• When changing the time information mode ( ),

select the desired item by pressing ENTER repeatedly.

To clear the on-screen bar

The contents of the on-screen bar differ according to

the type of discs/files.

*1TH-D50/TH-D5/TH-D4: The ON SCREEN button is used

instead of CAT/ON SCREEN.

*2During playback of ASF, MPEG-1, MPEG-2, or DivX files,

the function bar does not appear.

On-screen bar functions

*3Not available for DVD VR discs

*4During playback of DVD Video or DVD VR discs, A-B

repeat play is available only within the same title/program.

*5A-B repeat play is not available during program and random

playback.

Operation from the TV screen

Status bar

Function bar*2

Ex.:

Select Confirm

Ex.:

Selects the time information mode shown

on the display and the status bar.

TIME*3: Elapsed time of chapter/track

REM*3: Remaining time of chapter/track

TOTAL: Elapsed time of title (DVD Video)/

group (DVD Audio)/program (DVD

VR)/disc (VCD/CD/SVCD)

T.REM: Remaining time of title (DVD

Video)/group (DVD Audio)/

program (DVD VR)/disc (VCD/

CD/SVCD)

Selects repeat mode.

/////

///:

category

1Enter the category search mode.

2Select the desired category name, then select the

channel.

3Exit from the category search mode.

To select a channel number

directly

2Select the desired channel

number. *

*For details on using the number buttons,

see “How to use the number buttons”

( 10).

You can preset 30 XM Satellite Radio channels.

Storing the preset channels

1Tune in to the channel you want to preset.

3Select a preset number, then store the channel

to that number.

• “STORED” appears on the display.

Tuning in to a preset channel

Select a preset number.*

You can also select a preset number

by pressing PRESET(/CAT) UP or PRESET(/CAT)

DOWN when the System is not in the category

search mode (the CAT indicator is turned off). To exit

from the category search mode, see the left column.

*For details on using the number buttons, see “How to use the

number buttons” ( 10).

You can change the type of channel information which

appears on the display.

If you turn off the power or select another source, the

display is changed back to the channel name

information.

When tuning in to another channel, the channel

name appears on the display temporarily.

Some characters cannot be displayed correctly.

Manual tuning

Select category Select channel

Preset tuning

Changing the channel

information

“_ _” flashes on the display. Perform the next

step while “_ _” is flashing.

Enter a preset number*

Store

CH (channel number) = CHAN (channel name)

= NAME (artist name/feature) = TITLE

(song/program title) = CAT (category name)

= (back to the beginning)

Tuning in to a station

You can also tune in to a station automatically. Press

and hold TUNING 9 (/TUNING until the station

search starts. The system tunes in the first station of

sufficient signal strength found automatically.

You can also tune in to the station by pressing cursor

5 Y/ .

You can preset 30 FM stations and 15 AM stations.

Storing the preset stations

1Tune in to the station you want to preset.

3Select a preset number, then store the station to

that number.

• “STORED” appears on the display.

Tuning in to a preset station

Select a preset number.*

You can also select a preset number

by pressing PRESET(/CAT) UP or PRESET(/CAT)

DOWN.

*For details on using the number buttons, see “How to use the

number buttons” ( 10).

When the stereo FM program currently tuned in is noisy, you

can change the FM reception mode to improve the reception.

Manual tuning

Set the remote control mode

before operation.

• Select the desired source (“FM”

or “AM”) you want to listen to.

( 11)

*TH-D50/TH-D5/TH-D4: The FM/

AM button is used instead of FM/

AM/XM.

Preset tuning

Selecting the FM reception mode

“_ _” flashes on the display. Perform the next

step while “_ _” is flashing.

Enter a preset number*

Store

AUTO Normally select this.

MONO Select to improve reception. (You

will lose the stereo effect.)

FM/AM tuner operations

Starting playback

Be sure to reduce the volume on the System to the

minimum level before connecting an iPod. Adjust the

volume after playback has started.

1Connect an iPod while the System is turned off.

• Face the arrow-mark side up when connecting the

plug.

2Turn on the System, then select “IPod” as the

source. ( 11)

“CONNECT” appears on the display. If an iPod is not

connected firmly, “NO CONNE” appears.

3Start playing the iPod.

• Press 3 (play button) again if iPod does not start

playback.

Play/pause/search/skip

*Operate on your iPod to skip to the next/previous item while

playing back a video.

• The iPod enters sleep mode when you turn off the System

or select another source.

• To show still pictures in the iPod, play back in slide-show

mode on the iPod.

DO NOT connect or disconnect the iPod when the

System is turned on.

DO NOT touch the iPod terminal pins or the

connector pins.

When the iPod is not charged through the System,

the iPod may not be turned on from the System.

If the sound is distorted when audio sources with

high recording levels are played, you are

recommended to deactivate the equalizer on your

iPod.

To view a video/picture from the iPod on the TV,

connect the System to the TV via the composite or S-

video jacks. (8)

You cannot send any data to your iPod from the

System.

TH-D5/TH-D4 only: To disconnect the

iPod cable from the iPod, press the

buttons on the sides, then pull it out.

The iPod battery is charged only when

“IPod” is selected as the source.

If the iPod which is not listed in “Playable digital devices”

( 3) is connected, the iPod may not be operated from

the System. In this case, deactivate the iPod battery charge

function so that the iPod may be operated, but the iPod

cannot be charged through the System.

To use the battery charge function, perform the above

procedure again. “P.ON” appears on the display.

Set the remote control mode before

operation.

Before selecting the video

source to play

Make the appropriate setting for

video output on the iPod.

Stand for iPod

(supplied)

Connection cable for

iPod (supplied)

TH-D5/TH-D4:

Docking station for iPod

(supplied)

TH-D60/TH-D50:

* Attach the dock adapter (supplied for the iPod or

separately purchased) before placing the iPod.

( 32)

To do

Start playback

Pause playback

Fast-forward/fast-reverse

Skip to the next/previous

item*

To deactivate the battery charge function

«Hold «Hold

“P.OFF” appears on the display.

«Hold

iPod playback

Before operating external components from the remote

control, set the manufacturer’s code.

1Set the remote control mode (see above).

2Press and hold for the target component

until the setting is finished.

4Enter the manufacturer’s code.

See “Manufacturer’s code list” for the

manufacturer’s code. ( 30)

5Release .

If there is more than one code listed

for the corresponding brand, try each one until you

enter the correct one.

Set the codes after replacing batteries of the remote

control.

Set the remote control mode before operating each

external component (see the left column).

Operating the TV

Operating the DBS tuner or CATV

converter

Operating the VCR

Setting the manufacturer’s code

For TV For DBS tuner or

CATV converter

For VCR

Set the remote control mode before

operation.

For TV

For DBS tuner or CATV converter

For VCR

Preparation

Make the audio input setting before

operation. ( 14)

«Hold «Hold

Operating external components

TV Turns the power on and off

TV VOL +/– Adjusts the volume

TV/VIDEO Selects the input mode (either

TV or VIDEO)

CH +/– Changes the channels

1-10, 0, h10 (100+) Selects the channels

TV RETURN Alternates between the

previously selected channel

and the current channel

VCR/DBS Turns the power on and off

CH +/– Changes the channels

1-10, 0, h10 (100+) Selects the channels

VCR/DBS Turns the power on and off

3 (play button) Starts playback

7 Stops playback

8 Pauses playback

y Fast-forwards the tape

1 Rewinds the tape

REC Press this button together with 3

(play button) to start recording or

together with 8 to enter recording-

pause.

CH +/– Changes the TV channels

0 - 9 Selects the TV channels

Operating external components

DBS tuner or CATV converter

VCR

* Initial setting

Manufacturers’ codes are subject to change without

notice.

Manufacturer’s code list

JVC 01*Samsung 12

Hitachi 10 Sanyo 13, 14

Magnavox 0602 Sharp

Mitsubishi 03 Sony 07

Panasonic 04, 11 Toshiba 08

Philips 15 Zenith 09

RCA 05

Echostar 21

G.I. 01*, 02, 03, 04, 05, 06, 07, 08

Hamlin 15, 16, 17, 18

Jerrold 01, 02, 03, 04, 05, 06, 07, 08

Pioneer 13, 14

RCA 19

Scientific Atlanta 09, 10

Sony 20

Zenith 11, 12

JVC 01*, 02, 03 Philips 09

Emerson 11, 26 RCA 05, 06

Fisher 29 Samsung 24

Funai 10, 14, 15, 16 Sanyo 21, 22, 23

Gold Star 12 Sharp 27, 28

Hitachi 04 Shintom 30

Mitsubishi 13 Sony 18, 19, 20

NEC 25 Zenith 08

Panasonic 07, 17

Language code list

AA Afar IW Hebrew RO Rumanian

AB Abkhazian JI Yiddish RW Kinyarwanda

AF Afrikaans JW Javanese SA Sanskrit

AM Ameharic KA Georgian SD Sindhi

AR Arabic KK Kazakh SG Sangho

AS Assamese KL Greenlandic SH Serbo-

Croatian

AY Aymara KM Cambodian

AZ Azerbaijani KN Kannada SI Singhalese

BA Bashkir KO Korean

(KOR)

SL Slovenian

BE Byelorussian SM Samoan

BG Bulgarian KS Kashmiri SN Shona

BH Bihari KU Kurdish SO Somali

BI Bislama KY Kirghiz SQ Albanian

BN Bengali,

Bangla

LA Latin SR Serbian

LN Lingala SS Siswati

BO Tibetan LO Laothian ST Sesotho

BR Breton SU SundaneseLT Lithuanian

CA Catalan LV Latvian,

Lettish

SV Swedish

CO Corsican SW Swahili

CY Welsh MG Malagasy TA Tamil

DA Danish MI Maori TE Telugu

DZ Bhutani MK Macedonian TG Tajik

EL Greek TH ThaiML Malayalam

EO Esperanto MN Mongolian TI Tigrinya

ET Estonian MO Moldavian TK Turkmen

EU Basque MR Marathi TL Tagalog

FA Persian MS Malay (MAY) TN Setswana

FI Finnish MT Maltese TO Tonga

FJ Fiji MY Burmese TR Turkish

FO Faroese NA Nauru TS Tsonga

FY Frisian NE Nepali TT Tatar

GA Irish NL Dutch TW Twi

GD Scots Gaelic NO Norwegian UK Ukrainian

GL Galician OC Occitan UR Urdu

GN Guarani OM (Afan) Oromo UZ Uzbek

GU Gujarati VI Vietnamese

HA Hausa OR Oriya VO Volapuk

HI Hindi PA Panjabi WO Wolof

HR Croatian PS Pashto,

Pushto

XH Xhosa

HY Armenian YO Yoruba

IA Interlingua PT Portuguese ZU Zulu

IE Interlingue QU Quechua

IK Inupiak RM Rhaeto-

Romance

IN Indonesian

IS Icelandic RN Kirundi

References

Messages and icons shown on the TV

during disc/file playback

You can change the setting so that the on-screen

guide icons do not appear on the TV. ( 24)

Messages shown on the display while

listening to the XM Satellite Radio

Power does not come on.

ZThe power plug is not inserted securely. Plug it in

securely.

Unable to operate the System from the remote

control.

ZThe path between the remote control and the remote

sensor on the center unit is blocked.

ZThe batteries are exhausted.

No sound is heard.

ZThe speaker connections and/or audio cord connections

are incorrect or loose. ( 5, 8, 9)

ZHeadphones are connected.

The sound is distorted

ZThe speaker layout ( 6) does not match the speaker

position mode ( 12).

No picture appears on the TV.

ZThe video cord connections are incorrect or loose.

( 7 – 9)

The picture does not fit the TV.

ZThe monitor type is not set correctly. ( 23)

No picture is displayed on the TV, the picture is

blurred, or the picture is divided into two parts.

ZThe scanning mode is set to the progressive mode even

though the TV connected to the System does not support

progressive video input. ( 14)

Messages and icons shown on

the TV and display

OPEN/CLOSE Opening or closing the disc tray

NOW READING Reading the disc/file information

READING

INDEX... Reading the DivX file

REGION CODE

ERROR!

The Region Code of the DVD

Video disc does not match the

code the System supports.

( 3)

NO DISC No disc or an unfinalized disc is

loaded.

NO USB

DEVICE

No USB mass storage class

device is loaded.

CANNOT PLAY

THIS DISC An unplayable disc is loaded.

CANNOT PLAY

THIS DEVICE

An unplayable USB mass storage

class device is connected.

RESTRICTED

DEVICE

iPod is connected to the USB

MEMORY terminal.

NOT SUPPORT The file cannot be played back.

The operation is unacceptable.

Playback

Pause

Fast-forward/fast-reverse

Forward/reverse slow-motion playback

The scene contains multi-audio languages.

The scene contains multi-subtitle

languages.

The scene contains multi-angle views.

NO SIGNL No signal is received.

CHECK

XM TUNER

The XM Mini-Tuner is not properly

installed or the XM Mini-Tuner

Home Dock is not properly

connected.

CHECK

ANTENNA

XM antenna is not properly

connected.

LOADING Loading the channel information

and audio data.

OFF AIR The selected channel is not

currently broadcasting any signal.

UPDATING Updating the latest encryption.

- - - - - No text information for the selected

channel is available.

Preset number

and “- - - - -”

CH- - - The selected channel does not

exist or is not subscribed yet.

Preset number

and “CH- - -”

Troubleshooting

References

No picture is displayed on the TV or no sound

comes out through the HDMI connection.

ZThe connected TV is not HDCP-compatible. (“HDCP

ERR” appears on the display.)

ZDisconnect the HDMI cable and connect it again, or use

a shorter cable.

Video and audio are distorted.

ZThe disc is scratched or dirty.

ZAudio/video files have not been properly copied on to the

USB mass storage class device.

ZA VCR is connected between the center unit and the TV.

Connect the center unit and TV directly. ( 7)

VCD/SVCD operation cannot be performed.

ZSome functions do not work for VCDs/SVCDs when the

PBC function is used.

No sound is heard from the external components,

or the video and audio do not match.

ZThe selected audio input is not appropriate. Select the

audio input to match the component connected.

( 14)

The iPod does not play even though “CONNECT”

appears on the display.

ZThe battery of the iPod is exhausted. Leave the iPod

connected for at least 10 minutes.

The iPod cannot be operated from the System.

ZThe iPod battery charge function is deactivated.

( 28)

ZThe iPod is not compatible with the System. Check the

compatibility. ( 3)

iPod is not charged.

ZThe source is not “IPod.”

ZThe iPod battery charge function is deactivated.

( 28)

The broadcast is hard to hear because of noise.

ZAntenna connections are incorrect or loose. ( 7)

ZThe AM loop antenna is too close to the System.

ZThe FM Antenna is not properly extended and positioned.

( 7)

• This product incorporates copyright protection

technology that is protected by U.S. patents and other

intellectual property rights. Use of this copyright

protection technology must be authorized by

Macrovision, and is intended for home and other limited

viewing uses only unless otherwise authorized by

Macrovision. Reverse engineering or disassembly is

prohibited.

• USE OF THIS PRODUCT IN ANY MANNER THAT

COMPLIES WITH THE MPEG-4 VISUAL

STANDARD IS PROHIBITED, EXCEPT FOR USE

BY A CONSUMER ENGAGING IN PERSONAL

AND NON-COMMERCIAL ACTIVITIES.

• DivX, DivX Ultra Certified, and associated logos are

trademarks of DivX, Inc. and are used under license.

• Official DivX® Ultra Certified product

• Plays all versions of DivX® video (including DivX® 6)

with enhanced playback of DivX® media files and the

DivX® Media Format

• Microsoft and Windows Media are either registered

trademarks or trademarks of Microsoft Corporation in

the United States and/or other countries.

• DVD Logo is a trademark of DVD Format/Logo

Licensing Corporation.

• iPod is a trademark of Apple Inc., registered in the U.S.

and other countries.

• Manufactured under license from Dolby Laboratories.

“Dolby”, “Pro Logic”, “MLP Lossless”, and the double-

D symbol are trademarks of Dolby Laboratories.

• “DTS” and “DTS Digital Surround” are registered

trademarks of DTS, Inc.

• HDMI, the HDMI logo and High-Definition Multimedia

Interface are trademarks or registered trademarks of

HDMI Licensing LLC.

• HDCP is the abbreviation of “High-bandwidth Digital

Content Protection,” and is the high-reliable copy

control technology licensed by Digital Content

Protection, LLC.

• XM Ready® is a registered trademark of XM Satellite

Attaching the dock adapter to the docking station

Dock adapter (supplied

for iPod or separately

purchased)

Docking station

To detach the dock adapter

from the docking station:

Push the slot then pull up to

remove the dock adapter.

Disconnect the docking station from the

center unit when attaching/detaching the

dock adapter.

Take care not to damage the terminal on

the docking station when attaching/

detaching the dock adapter.

Center unit (XV-THD60/XV-THD50/XV-

THD5/XV-THD4)

Output power

Front/Surround:

For XV-THD60/XV-THD50: 200 W per channel, RMS at

3 Ω at 1 kHz, with 10 % total harmonic distortion.

For XV-THD5: 180 W per channel, RMS at 3 Ω at 1 kHz,

with 10 % total harmonic distortion.

For XV-THD4: 167 W per channel, RMS at 3 Ω at 1 kHz,

with 10 % total harmonic distortion.

Center:

For XV-THD60/XV-THD50: 200 W, RMS at 3 Ω at

1 kHz, with 10 % total harmonic distortion.

For XV-THD5: 180 W, RMS at 3 Ω at 1 kHz, with 10 %

total harmonic distortion.

For XV-THD4: 167 W, RMS at 3 Ω at 1 kHz, with 10 %

total harmonic distortion.

Subwoofer:

For XV-THD60/XV-THD50: 200 W, RMS at 3 Ω at

100 Hz, with 10 % total harmonic distortion.

For XV-THD5: 200 W, RMS at 3 Ω at 100 Hz, with 10 %

total harmonic distortion.

For XV-THD4: 167 W, RMS at 3 Ω at 100 Hz, with 10 %

total harmonic distortion.

Audio section

Digital Input*1

DIGITAL IN

OPTICAL: –21 dBm to –15 dBm (660 nm

±30 nm)

COAXIAL*2: 0.5 V(p-p)/75 Ω

Video section

Video System: NTSC

Horizontal Resolution: 500 lines

Signal-to-Noise Ratio: 64 dB

Video Output Level (VIDEO OUT)

Composite video: 1.0 V(p-p)/75 Ω

S-video (Y): 1.0 V(p-p)/75 Ω

(C): 0.286 V(p-p)/75 Ω

Component (Y): 1.0 V(p-p)/75 Ω

(PB/PR): 0.7 V(p-p)/75 Ω

Video Input Sensitivity/Impedance

(VIDEO IN)

Composite: 1.0 V(p-p)/75 Ω

S-video (Y): 1.0 V(p-p)/75 Ω

(C): 0.286 V(p-p)/75 Ω

HDMI

HDMI Input (VIDEO 1 IN)*2:

PASS THROUGH (up to

225 MHz)

HDMI Output (MONITOR OUT):

480p/720p/1080i

USB storage

USB Specification: Compatible with USB 2.0 Full-

Speed

Compatible Device: Mass Storage Class

Compatible File System: FAT16, FAT32

Bus Power Supply: Max. 500 mA

Tuner section

Tuner Range

FM: 87.5 MHz to 108.0 MHz

AM: 530 kHz to 1 710 kHz

General

Power Requirements: AC 120 V , 60 Hz

Power Consumption: 160 W (during operation)

1.3 W (in standby mode)

Dimensions (W × × H D):

435 mm × 115 mm × 270 mm

(17-3/16 inches × 4-3/8 inches × 10-11/16 inches)

Mass: 6.8 kg (15.0 lbs)

*1Corresponding to Linear PCM, Dolby Digital, and DTS

Digital Surround (with sampling frequency — 32 kHz,

44.1 kHz, 48 kHz)

*2Only for XV-THD60

Subwoofer

For SP-THD6W (TH-D60)

Type: Bass-Reflex Type

Speaker: 20 cm (7-7/8 inches) cone × 1

Power Handling Capacity: 200 W

Impedance: 3 Ω

Frequency Range: 28 Hz to 200 Hz

Sound Pressure Level: 74 dB/W

•

Dimensions (W × × H D):

353.5 mm × × 351 mm 248 mm

(13-15/16 inches × × 13-7/8 inches 9-13/16 inches)

Mass: 8.5 kg (18.8 lbs)

For SP-THD5W (TH-D50/TH-D5/TH-D4)

Type: Bass-Reflex Type

Speaker: 16 cm (6-5/16 inches) cone × 1

Power Handling Capacity: 200 W

Impedance: 3 Ω

Frequency Range: 30 Hz to 200 Hz

Sound Pressure Level: 74 dB/W

•

Dimensions (W × H × D):

353.5 mm × × 351 mm 174 mm

(13-15/16 inches × × 13-7/8 inches 6-7/8 inches)

Mass: 6.3 kg (13.9 lbs)

Specifications

References

Satellite speakers (For TH-D60)

Front speakers (SP-THD6F)

Type:

2-Way Bass-Reflex Type (Magnetically Shielded Type)

Speaker: 8 cm (3-3/16 inches) cone × 1

3 cm (1-3/16 inches) dome × 1

Power Handling Capacity: 200 W

Impedance: 3 Ω

Frequency Range: 90 Hz to 20 000 Hz

Sound Pressure Level: 78 dB/W

•

Dimensions (W × × H D):

200 mm x 574 mm x 200 mm

(7-7/8 inches × 22-5/8 inches × 7-7/8 inches)

Mass: 2.4 kg (5.3 lbs) each

Center speaker (SP-THD6C)

Type:

1-Way 2-Speaker Bass-Reflex Type (Magnetically

Shielded Type)

Speaker: 8 cm (3-3/16 inches) cone × 2

Power Handling Capacity: 200 W

Impedance: 3 Ω

Frequency Range: 90 Hz to 20 000 Hz

Sound Pressure Level: 83 dB/W

•

Dimensions (W × × H D):

435 mm × × 99 mm 93.5 mm

(17-3/16 inches × 3-15/16 inches × 3-11/16 inches)

Mass: 2.0 kg (4.5 lbs)

Surround speakers (SP-THD6S)

Type:

1-Way Bass-Reflex Type (Magnetically Shielded Type)

Speaker: 8 cm (3-3/16 inches) cone × 1

Power Handling Capacity: 200 W

Impedance: 3 Ω

Frequency Range: 90 Hz to 20 000 Hz

Sound Pressure Level: 75 dB/W

•

Dimensions (W × × H D):

98.5 mm × 214.5 mm × 93.5 mm

(3-15/16 inches × × 8-1/2 inches 3-11/16 inches)

Mass: 0.85 kg (1.9 lbs) each

Satellite speakers (For TH-D50/TH-D5/

TH-D4)

Front speakers (SP-THD5F)

Type:

1-Way Bass-Reflex Type (Magnetically Shielded Type)

Speaker: 8 cm (3-3/16 inches) cone × 1

Power Handling Capacity: 200 W

Impedance: 3 Ω

Frequency Range: 90 Hz to 20 000 Hz

Sound Pressure Level: 79 dB/W

•

Dimensions (W × × H D):

98.5 mm × 214.5 mm × 93.5 mm

(3-15/16 inches × 8-1/2 inches × 3-11/16 inches)

Mass: 1.0 kg (2.2 lbs) each

Center speaker (SP-THD5C)

Type:

1-Way 2-Speaker Bass-Reflex Type (Magnetically

Shielded Type)

Speaker: 8 cm (3-3/16 inches) cone × 2

Power Handling Capacity: 200 W

Impedance: 3 Ω

Frequency Range: 90 Hz to 20 000 Hz

Sound Pressure Level: 83 dB/W

•

Dimensions (W × × H D):

435 mm × × 99 mm 93.5 mm

(17-3/16 inches × 3-15/16 inches × 3-11/16 inches)

Mass: 2.0 kg (4.5 lbs)

Surround speakers (SP-THD5S)

Type:

1-Way Bass-Reflex Type (Magnetically Shielded Type)

Speaker: 8 cm (3-3/16 inches) cone × 1

Power Handling Capacity: 200 W

Impedance: 3 Ω

Frequency Range: 90 Hz to 20 000 Hz

Sound Pressure Level: 75 dB/W

•

Dimensions (W × × H D):

98.5 mm × 214.5 mm × 93.5 mm

(3-15/16 inches × 8-1/2 inches × 3-11/16 inches)

Mass: 0.85 kg (1.9 lbs) each

Designs & specifications are subject to change without notice.

Dimensions of the wall-mount attachment on the center and surround speakers:

SP-THD6C/SP-THD5C SP-THD6S/SP-THD5S

Unit: mm (inch)

DVD DIGITAL THEATER SYSTEM

0107RYMMDWJEM

TH-D60/TH-D50/

TH-D5/TH-D4

INSTRUCTIONS

LVT1704-018A

[J]

For Customer Use:

Enter below the Model No. and Serial

No. which are located either on the rear,

bottom or side of the cabinet. Retain this

information for future reference.

Model No.

Serial No.

TH-D60WM

Consists of XV-THD60WM, SP-THD60WMW,

SP-THD6F, SP-THD6C and SP-THD6S

DVD DIGITAL THEATER SYSTEM

G-1

CAUTION

To reduce the risk of electrical shocks, fire, etc.:

1. Do not remove screws, covers or cabinet.

2. Do not expose this appliance to rain or moisture.

ATTENTION

Afin d’éviter tout risque d’électrocution, d’incendie, etc.:

1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir le

coffret de l’appareil.

2. Ne pas exposer l’appareil à la pluie ni à l’humidité.

CAUTION — button!

Disconnect the mains plug to shut the power off

completely (the STANDBY lamp goes off). When

installing the apparatus, ensure that the plug is easily

accessible.

The button in any position does not disconnect the

mains line.

• When the system is on standby, the STANDBY lamp

lights red.

• When the system is turned on, the STANDBY lamp

goes off.

The power can be remote controlled.

ATTENTION — Touche

Déconnectez la fiche d’alimentation secteur pour couper

l’alimentation complètement (le témoin STANDBY

s’éteint). Lors de l’installation de l’appareil, assurez-vous

que la fiche soit facilement accessible.

La touche , dans n’importe quelle position, ne

déconnecte pas le système du secteur.

• Quand le système est en attente, le témoin STANDBY

est allumé en rouge.

• Quand le système est sous tension, le témoin

STANDBY s’éteint.

L’alimentation peut être télécommandée.

Note to CATV system installer:

This reminder is provided to call the CATV system

installer’s attention to section 820-40 of the NEC which

provides guidelines for proper grounding and, in

particular, specifies that the cable ground shall be

connected to the grounding system of the building, as

close to the point of cable entry as practical.

[European Union only]

[Union européenne seulement]

Warnings, Cautions and Others

Mises en garde, précautions et indications diverses

G-2

IMPORTANT FOR LASER PRODUCTS

1. CLASS 1 LASER PRODUCT

2. CAUTION: Do not open the top cover or cabinet. There are

no user serviceable parts inside the unit; leave all servicing

to qualified service personnel.

3. CAUTION:

(For U.S.A.) Visible and/or invisible class II laser

radiation when open. Do not stare into beam.

(For Canada) Visible and/or invisible class 1M laser

radiation when open. Do not view directly with optical

instruments.

4. REPRODUCTION OF LABEL: CAUTION LABEL,

PLACED INSIDE THE UNIT.

IMPORTANT POUR PRODUITS LASER

1. PRODUIT LASER CLASSE 1

2. ATTENTION: N’ouvrez pas le couvercle supérieur ni le

coffret de l’appareil. Il n’y a aucune pièce réparable par

l’utilisateur à l’intérieur de l’appareil; confiez toute

réparation à un personnel qualifié.

3. ATTENTION:

(Pour les Etats-Unis) Radiation laser de classe II visibles

et/ou invisible si l’appareil est ouvert. Ne regardez pas le

rayon.

(Pour le Canada) Rayonnement laser visible et/ou

invisible de classe 1M une fois ouvert. Ne pas regarder

directement avec des instruments optiques.

4. REPRODUCTION DE L’ÉTIQUETTE: ÉTIQUETTE

DE PRÉCAUTION PLACÉE À L’INTERIEUR DE

L’APPARE IL.

For U.S.A.

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation.

This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is

no guarantee that interference will not occur in a

particular installation. If this equipment does cause

harmful interference to radio or television reception,

which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and

receiver.

Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician

for help.

CAUTION

Changes or modifications not approved by JVC could

void the user’s authority to operate the equipment.

For Canada

THIS DIGITAL APPARATUS DOES NOT EXCEED

THE CLASS B LIMITS FOR RADIO NOISE

EMISSIONS FROM DIGITAL APPARATUS AS SET

OUT IN THE INTERFERENCE-CAUSING

EQUIPMENT STANDARD ENTITLED “DIGITAL

APPARATUS,” ICES-003 OF THE DEPARTMENT OF

COMMUNICATIONS.

Pour le Canada

CET APPAREIL NUMERIQUE RESPECTE LES

LIMITES DE BRUITS RADIOELECTRIQUES

APPLICABLES AUX APPAREILS NUMIRIQUES DE

CLASSE B PRESCRITES DANS LA NORME SUR LE

MATERIEL BROUILLEUR; “APPAREILS

NUMERIQUES”, NMB-003 EDICTEE PAR LE

MINISTRE DES COMMUNICATIONS.

CAUTION:

Excessive sound pressure from earphones or headphones

can cause hearing loss.

ATTENTION:

Une pression acoustique excessive des écouteurs ou du

casque d’écoute peut entraîner une perte auditive.

CAUTION!

To avoid personal injury or accidentally dropping the

unit, have two persons unpack, carry, and install the unit.

ATTENTION!

Pour éviter toute blessure personnelle ou toute chute

accidentelle de l’appareil, celui-ci doit être déballé,

transporté et installé par deux personnes.

31.2 kg/69 lbs

Notes on installing the System

• Select a location which is level, dry and neither too hot nor

too cold between 5°C and 35°C (41°F and 95°F).

• Do not install the System in a location subject to

vibrations.

• Do not put heavy objects on the System.

Avoid moisture, water, dust, and high

temperatures

• Do not install the System in moist or dusty locations.

• If water gets inside the System, turn off the power and

remove the plug from the wall outlet, then consult your

dealer. Using the System in this state may cause a fire or

electrical shock.

• Do not expose the System to direct sunlight or place it near

a heating device.

To prevent malfunctions or damage to the System

• Do not insert any metallic objects, such as wires, hairpins,

coins, etc. into the System.

• Do not block the vents.

Notes on the power cord

• When you are away on travel or otherwise for an extended

period of time, remove the plug from the wall outlet. A

small amount of power is always consumed while the

power cord is connected to the wall outlet.

• When unplugging the System from the wall outlet, always

pull the plug, not the power cord.

• Disconnect the power cord before cleaning or moving the

System.

• Do not modify, twist or pull the power cord, or put

anything heavy on it. Doing so may cause fire, electric

shock, or other accidents.

About copyright laws

Observe the copyright laws in your country before recording

from original sources. Recording of copyrighted material

may infringe copyright laws.

About the copyguard system

The discs are protected by the copyguard system. When

connecting the System to a TV via a VCR, or to a TV with a

built-in VCR, the copyguard system activates and distortion

of the picture may occur.

Notes on installing and using the speakers

• Place the speakers and subwoofer on a flat and level

surface.

• The speakers are magnetically shielded to avoid color

distortions on TVs. If the color on a TV is distorted,

perform the following procedure:

– Turn off the TV’s main power switch or unplug it

before installing the speakers. Then wait at least

30 minutes before turning on the TV’s main power

switch again.

Some TVs may still be affected even though you have

followed the above procedure. If this happens, move the

speakers away from the TV.

• The subwoofer is not magnetically shielded. To avoid

color distortion, do not place it near the TV or monitor.

• When moving the speakers and subwoofer, do not pull the

speaker cords. Doing so may cause the speakers and/or

subwoofer to fall over, causing damage or injury.

• When installing the speakers on a wall, be sure to have

them installed by qualified personnel. DO NOT install the

speakers on a wall by yourself.

• Do not lean against the speakers, as they could fall down

or break, possibly causing an injury. Be especially careful

that children do not lean against them.

About the adjustment of volume

Always set the volume to the minimum level before starting

any source. If the volume is set at a high level, the sudden

blast of sound could permanently damage your hearing and/

or blow out the speakers.

To clean the System

• Use a soft cloth. Follow the relevant instructions on the

use of chemically-coated cloths.

• If the System is heavily stained, apply a small amount of

water or neutral detergent to the cloth and wipe clean, then

wipe with a dry cloth.

• Do not use benzene, thinner or other organic solvents and

disinfectants. These may cause deformation or

discoloring.

Precautions

There are no user-serviceable parts inside. If anything

goes wrong, unplug the power cord and consult your

dealer.

Before using this System

This System accommodates the NTSC system, and

also can play discs/files recorded with PAL system.

Note that an PAL video signal on a disc/file is

converted to the NTSC signal and output.

It is possible to play back finalized +R/+RW (DVD

Video format only) discs. “DVD” lights on the display

panel when a +R/+RW disc is loaded.

DVD-R/-RW: This System does not support “multi-

border” discs.

CD-R/-RW:

– This System supports “multi-session” discs (up to

20 sessions).

– This System cannot play “packet write” discs.

Unplayable discs—unwarranted

Playing back the following discs generates noise and

damages the speakers.

• DVD-ROM, DVD-RAM, DualDisc* (non-DVD side)

• CD-ROM, CD-I (CD-I Ready), Photo CD, SACD

• Unfinalized discs (except DVD VR)

• Discs with an irregular shape or discs with tape, stickers

or paste on either the label side or playback side

• Warped, dirty, or scratched discs

*The Non-DVD side of a “DualDisc” does not comply with

the “Compact Disc Digital Audio” standard. Therefore, the

use of Non-DVD side of a DualDisc on this product may

not be recommended.

iPod

*Only still pictures are available.

If the iPod does not play correctly, update your iPod

software to the latest version. For details about

updating your iPod, check on the Apple web site

<http://www.apple.com>.

USB mass storage class device

A USB flash memory device, hard disk drive, multimedia

card reader, digital camera, etc. can be used with this System

through a USB connection.

This System is compatible with USB 2.0 Full-Speed.

This System cannot recognize a USB mass storage

class device whose rating exceeds 5 V/500 mA.

Some discs/files may require operations that differ

from those explained in this manual.

Some discs/devices/files may not be recognized or

played back correctly due to their characteristics.

Playable disc types

Type of disc Types of media

DVD Video

• Discs on the market

• DVD-R/-R DL/-RW

• +R/+RW

• DualDisc* (DVD side only)

DVD Audio

• Discs on the market

• DVD-R/-R DL/-RW

• +R/+RW

Super Video CD

(SVCD)/Video CD

(VCD)

• Discs on the market

• CD-R/-RW

Audio CD

• Discs on the market

• CD Text (Audio part only)

• CD-R/-RW

A disc recorded in

the DVD VR format • DVD-R/-RW

Audio/video files on

a disc ( 4)

• DVD-R/-R DL/-RW in UDF

Bridge format

• CD-R/-RW in ISO 9660

format

Region code of DVD Video

DVD Video players and DVD Video discs have their own

Region Code numbers. This system can play back DVD

Video discs whose Region Code numbers include “1.”

Ex.:

Playable digital devices

JVC bears no responsibility for any loss of data in an

iPod and/or USB mass storage class device while using

this System.

iPod model AUDIO VIDEO

iPod nano 1GB/2GB/4GB √

iPod nano (2nd Generation)

2GB/4GB/8GB √

iPod mini 4GB/6GB √

iPod (4th Generation)

20GB/40GB √

iPod photo (4th Generation)

20GB/30GB/40GB/60GB √ √ *

iPod video (5th Generation)

30GB/60GB/80GB √ √

Playable discs/devices/files

The following files in a disc or a USB mass storage class

device can be played back.

If a file on a USB mass storage class device exceeds

the following conditions, it may not be played back

correctly:

– Maximum data transfer rate: 2 Mbps

– Maximum frame rate: 30 fps for progressive

– Maximum file size: 2 GB

The System recognizes up to 150 tracks (files) per

group, and 99 groups per disc/device. The total

number of tracks (files) that the System can detect is

4000.

Information about the recording

conditions for the files on a disc/

device

MP3/WMA files

• The System supports MP3/WMA files recorded at a bit

rate of 32 – 320 kbps and a sampling frequency of 16 kHz,

22.05 kHz, 24 kHz*, 32 kHz, 44.1 kHz, or 48 kHz.

• It is recommended to record each file at a sample rate of

44.1 kHz and at a data transfer rate of 128 (96*) kbps.

*For WMA only

WAV files

• The System supports WAV files recorded at a

quantization rate of 8 or 16 bit and a sampling frequency

of 8 kHz, 11.025 kHz, 12 kHz, 16 kHz, 22.05 kHz,

24 kHz, 32 kHz, 44.1 kHz, or 48 kHz.

• It is recommended to record each file at a sample rate of

44.1 kHz and at a quantization rate of 16 bit Linear PCM.

JPEG files

• It is recommended to record a file at 640 x 480 resolution.

(If a file has been recorded at a resolution of more than

640 x 480, it will take a longer time to be displayed.)

• This System can only play baseline JPEG files.

ASF files

• The System supports MPEG-4 files with the following

conditions:

File format: ASF

Visual profile: MPEG-4 SP (Simple Profile)

Audio CODEC: G.726

Max. picture size: 352 x 288 (CIF)

Max. bit rate: 384 kbps

MPEG1/MPEG2 files

• The stream format should conform to the MPEG system/

program stream.

• 720 x 576 pixels (25 fps)/720 x 480 pixels (30 fps) is

recommended for the highest resolution.

• This system also supports resolutions of 352 x 576/480 x

576/352 x 288 pixels (25 fps) and 352 x 480/480 x 480/

352 x 240 pixels (30 fps).

• The file format should be MP@ML (Main Profile at Main

Level)/SP@ML (Simple Profile at Main Level)/MP@LL

(Main Profile at Low Level).

• Audio streams should conform to MPEG1 Audio Layer-2

or MPEG2 Audio Layer-2.

DivX files

• The System supports DivX files whose resolution is

720 x 480 pixels or less (30 fps), and 720 x 576 pixels or

less (25 fps).

• Audio stream should conform to Dolby Digital (including

multi-channel) or MPEG1 Audio Layer-3 (MP3).

• The System does not support GMC (Global Motion

Compression).

• Files encoded in the interlaced scanning mode may not be

played back correctly.

Playable file types

Type of file Playable files Extensions

Audio

MP3 <.mp3>

WMA <.wma>

WAV <.wav>

Picture JPEG <.jpg>, <.jpeg>

Movie

ASF <.asf>

MPEG-1 <.mpg>, <.mpeg>

MPEG-2 <.mpg>, <.mpeg>,

<.mod>

DivX (6.x, 5.x,

4.x and 3.11)

<.divx>, <.div>,

<.avi>

If anything is missing, contact your dealer immediately.

• Remote control (x 1)

• Batteries (x 2)

• FM antenna (x 1)

• AM loop antenna (x 1)

• Composite video cord (x 1)

• Docking station for iPod (x 1)

• Speaker cords: 3 m (10 ft) (x 4), 8 m (26.3 ft) (x 2)

• Feet for surround speakers (x 8)

• Screws: M5 x 85 mm (3-3/8 inches) (x 6)

Do not expose batteries to heat or flame.

If the range or effectiveness of the remote control

decreases, replace both batteries.

If you connect speakers other than those supplied for

the System, use speakers of the same speaker

impedance (SPEAKER IMPEDANCE) indicated on

the rear of the center unit.

DO NOT connect more than one speaker to one

speaker terminal.

Checking the supplied

accessories

Putting batteries into the remote

control

R03 (UM-4)/AAA (24F) type

dry-cell batteries (supplied)

Connecting the speakers and

subwoofer

Connecting the speaker cords

Connect the speaker cords both to the center unit and to

each speaker.

On the center unit:

On the speaker:

• Connect the black cords to the r terminals.

• Connect the white cords to the q terminals.

Speaker cords:

: 3 m (10 ft)

: 8 m (26.3 ft)

To front right speaker

(SP-THD6F)

To center speake

(SP-THD6C)

To front left speaker

(SP-THD6F)

To subwoofe

(SP-THD60WMW)

To surround left speaker

(SP-THD6S)

To surround right speaker

(SP-THD6S)

Center unit

Speaker cord

Getting started

Produktspecifikationer

Varumärke:	JVC
Kategori:	Hemmabioset
Modell:	TH-D50

Behöver du hjälp?

Om du behöver hjälp med JVC TH-D50 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Hemmabioset JVC Manualer

JVC TH-A30 Bruksanvisning

3 September 2024

JVC TH-C60 Bruksanvisning

31 Augusti 2024

JVC TH-A75 Bruksanvisning

29 Augusti 2024

JVC TH-D60 Bruksanvisning

25 Augusti 2024

JVC TH-C7 Bruksanvisning

23 Augusti 2024

JVC TH-S11E Bruksanvisning

23 Augusti 2024

JVC TH-M606 Bruksanvisning

21 Augusti 2024

JVC TH-S33 Bruksanvisning

20 Augusti 2024

JVC TH-D50 Bruksanvisning

19 Augusti 2024

JVC TH-C4 Bruksanvisning

16 Augusti 2024

Hemmabioset Manualer

Nyaste Hemmabioset Manualer

Panasonic SC-PT750 Bruksanvisning

5 April 2025

Pioneer XV-DV313 Bruksanvisning

31 Mars 2025

LG DKS-6000Q Bruksanvisning

28 Mars 2025

Phase Technology PC-Surround-II Bruksanvisning

5 Mars 2025

Phase Technology PremierPC9.5 Bruksanvisning

5 Mars 2025

Phase Technology Premier PC1.5 Bruksanvisning

5 Mars 2025

Phase Technology Premier PC3.5 Bruksanvisning

5 Mars 2025

Phase Technology Premier PC33.5 Bruksanvisning

5 Mars 2025

Phase Technology Velocity V-Surround-II Bruksanvisning

5 Mars 2025

Samsung HT-F455K Bruksanvisning

24 Februari 2025
