Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help you obtain the best performance from your new product.
© 2023 JVCKENWOOD Corporation
CA-HRN98UT
REAR SPEAKER HARNESS DESIGNED AND ENGINEERED
FOR 98-13 HARLEY-DAVIDSON® ULTRA MOTORCYCLES
INSTRUCTION MANUAL
JVCKENWOOD Corporation
Important Notes
©2023 JVCKENWOOD Corporation. All Rights Reserved. KENWOOD® and eXcelon®
are registered trademarks of JVCKENWOOD Corporation. Harley-Davidson®, Electra
Glide®, Road Glide®, Street Glide®, Ultra Classic®, Tri Glide®, CVO™, Screamin Eagle®
and Tour-Pak® are trademarks or registered trademarks of Harley-Davidson, Inc. and/
or its affiliates and if used or implied are for reference only. There is no affiliation
between Harley-Davidson, Inc. and/or its aliates and JVCKENWOOD Corporation
and/or its aliates. All other trademarks are the property of their respective owners.
Specications subject to change without notice.
Rear Speaker Harness Installation Instructions
Installation procedure
1. You will see that one end of this harness has two 4-pin connectors. One of these white
4-pin plugs will plug into the “amplied out” on the amp that will power the rear speakers.
The amplifier comes with a short harness with a black 8-pin plug and two 4-pin blue
plugs. Plug the 8-pin black plug into the amplier’s input that will power the rear speakers.
The second 4-pin plug marked “rear in” on the rear speaker harness will plug into one of
the blue 4-pin connectors, noting they will only go in one way.
2. The harness that will run the rear speakers will pass under the inner fairing on the clutch
side of the bike. Loosen the tank’s “chrome console” and run the wires up and over the gas
tank, but under the tank’s chrome console. There is a provision on the front of the console
for wires to pass under it allowing the power harness to run on the brake side of the ller
spout and the rear speaker harness to run on the clutch side of the spout.
NOTE: Although not necessary, the power and rear harnesses can go under the gas tank if
you choose to remove and re-install the tank. With the tank removed you will see a factory
wire channel where wires pass along the bike’s frame. Removing the top of the channel
will allow for the power and rear speaker harness to be safely run under the tank to the
battery area. When reinstalling the top of the channel take care not to pinch any wires
along the edges of the channel.
3. When installed on the bike, you will see that this harness has a white 8-pin plug towards
the back of the bike. This is a “quick disconnect” for bikes that have the large “tour pak”
removeable, and allows the rear speakers to be plugged in or unplugged easily. The end
of the harness that will be at the rear end of the bike is split into 2 groups of 4 wires, one
marked “clutch side”, and one marked “brake side”. If you are sitting on the bike looking
forward, the brake side is on your right-hand side. Remove the factory rear speakers from
each rear “pod”. Each group of wires will enter the rear pod where the factory wires enter
the pod. The factory speaker wires will plug into the male spades on each side, and the
female spades on this harness will plug directly onto each rear speaker.
NOTE: Factory rear wires DO NOT have insulators. Once the factory rear wires are plugged
into this harness, please wrap each connection with electrical tape to prevent the wires
from shorting against each other.
For updated information (the latest Instruction Manual, etc.),
please visit the following website:
https://manual.kenwood.com/en_contents/search/
