Manometer
USER MANUAL
Description of the device
1. OK key
2. Backlight key
3. Select key
4. On/Off/Esc key
5. Hold/min/max key
MP 110 – MP111
MP112 – MP 115
Technical specications
General features
Measuring elementPiezoresistive sensor
Tolerated overpressureMP 110: 250 mbar / MP 111: 700 mbar / MP 115: 1.4 bar / MP 112: 3 bar
Connector
MP 110 / 111: Ø 6.2 mm barbed connectors made of nickelled brass / MP 115 / 112: Ø 4.6 mm barbed connectors made of
nickelled brass
Display
4 lines, LCD technology. Dimensions 50 x 36 mm.
2 lines of 5 digits with 7 segments (value)
2 lines of 5 digits with 16 segments (unit)
HousingABS, protection IP54
Keypad5 keys
European directives2014/30/EU EMC; 2014/35/EU Low Voltage; 2011/65/EU RoHS II; 2012/19/EU WEEE
Power supply4 batteries AAA LR03 1.5 V
Battery life180 hours
AmbienceNeutral gas
Conditions of use (°C, %RH, m)From 0 to +50 °C. In non condensing conditions. From 0 to 2000 m.
Storage temperatureFrom -20 to +80 °C
Auto shut-offAdjustable from 0 to 120 min
Weight220 g
ParameterModelsMeasuring unitsAccuracy*Measuring rangeResolution
Pressure
MP 110Pa, mmH
2
O, inWg, daPa±0.5% of reading ±2 PaFrom -1000 to +1000 Pa1 Pa
MP 111
kPa, mmH
2
O, inWg, mbar,
mmHg, daPa
±0.5% of reading ±2 mmH
2
OFrom -1000 to +1000 mmH
2
O
From 0 to ±200OmmH
2
O:
0.1 mmH
2
O
Beyond: 1 mmH
2
O
MP 115
kPa, inWg, mbar, mmHg,
PSI
±0.5% of reading ±0.5 mbarFrom -500 to +500 mbar0.1 mbar
MP 112
kPa, inWg, mbar, mmHg,
PSI, bar
±0.5% of reading ±2 mbarFrom -2000 to +2000 mbar1 mbar
*All the accuracies indicated in this technical datasheet were stated in laboratory conditions, and can be guaranteed for measurements carried out in the same conditions, or carried out with calibration compensation.
