MP 55
Atmospheric pressure
DATA SHEET
MaterialABS
ProtectionIP54
Display
2 lines, LCD technology, 50 x 36 mm.
1 line of 5 digits with 7 segments (value)
1 line of 5 digits with 16 segments (unit)
Height of digitsValues: 9.2 mm. Units: 4.7 mm
Weight200 g (with batteries)
Features of housing
Easy to useHold function
14.1mm
6.2mm
71.5mm
147.9mm
34.2mm
Auto shut-off: 20 minutes
HOLD
OFF
Technical specications
(1)
All the accuracies indicated in this technical datasheet were stated in laboratory conditions, and can be
guaranteed for measurements carried out in the same conditions, or carried out with calibration compensation.
IP54
Measuring unitsmbar, mmHg, hPa
Measuring rangeFrom 700 to 1100 mbar
Accuracy
(1)
±2 mbar
Resolution0.1 mbar / 0.1 mmHg / 0.1 hPa
Response timeT
63
< 10 s
Measuring elementPiezoresistive sensor
ConnectionsBarbed connectors, Ø 6.2 mm made of nickelled brass
Conditions of use
(°C/%RH/m)
From 0 to +50 °C. In non-condensing conditions.
From 0 to 2000 m.
Storage temperatureFrom -20 to +80 °C
Power supply4 batteries AAA LR03 1.5 V
Battery life180 hours
European directives
2014/30/EU EMC; 2014/35/EU Low Voltage;
2011/65/EU RoHS II; 2012/19/EU WEEE
Pressure
Voltage
Vacuum
Silicon layer
+
+
+
+
+
+
+
-
-
-
-
-
-
-
V
Operating principles
Piezoresistive sensor
The pressure deforms the silicon layer.
This layer deformation generates a voltage at its
terminates. This voltage is proportional to the
pressure which is applied.
Supplied with
ADJUSTMENT
certificate
