WM-6D Quick Start
Manufacturer
: Kramer Israel
2
Negev St. Airport City 7019900
+972 (0)73
-265-0200
info_il@kramerav.com
EU Importer:
Kramer EMEA Netherlands
Stroombaan 16
, The Garden 1181VX
Amstelveen
info_EMEA@kramerav.com
P/N:
2 9 0 0 - 3 0 1 8
7 8 QS
Rev:
1
Scan to go to website
WM-6D Quick Start Guide
This guide helps you install and use your WM-6D for the first time.
Go to http://www.kramerav.com/downloads/WM-6D to download the latest user manual and check if
firmware upgrades are available.
Step 1: Check what’s in the box
1 WM-6D 6.5”, 2–way wall mounted PoE powered
Dante speaker
1 EasyMount mounting bracket
2 bracket screws
1 Silicon cap
1 L-Shaped Allen key (M6)
1 Quick start guide
Step 2: Get to know your WM-6D
# Feature Function
1
Speaker
Speaker body
2 EasyMount Bracket For mounting the bracket in horizontal or vertical position as well as in corners
3
Mounting bracket screws
For securing the EasyMount bracket to the speaker and adjusting the angle
4 Factory Reset button For resetting the DSP to default values
5
RJ45 connector
PoE Ethernet connector
6 75mm VESA mounting threads Standard 75mm VESA mounting threads for alternative mounting options
7
Speaker grill
Speaker’s grill
8 Safety anchor point Secondary safety anchor point for securing a seismic restraint cable
Step 3: Key Features
• Supports PoE++/PoE+/PoE (auto-negotiate)
• Built-in mixer, DSP, and amplifier for two-channel mixing, parametric EQ, High pass and low pass filters,
input compressor, output limiter and advanced power settings
• Features a built-in “Find Me” tone, making it easy to identify and locate individual speakers during installation
or maintenance.
• Power handling: 10W continuous / 30W peak
• Sound Pressure Level (SPL):
o Sensitivity (1W@1m, free field): 90dB SPL
1
2
3
4
5
6
7
8
o Maximum SPL: Continuous: 100dB SPL / Peak: 105dB SPL
• Regulatory compliance:
o UL1480A Certified
o IEC62368(CB) / CE LVD, UL62368-1
o FCC/IC, BIS, RCM
o RoHS, REACH, WEEE
Step 4: Achieving the Best Performance
To ensure optimal power delivery, audio performance, and long-term reliability of the Kramer WM-6D PoE-powered Dante
speaker, follow these cabling best practices:
Use high-quality Ethernet Cables
For all PoE+ and PoE++ installations, it is essential to use high-quality Ethernet cables that are designed to handle
higher power, minimize signal degradation and electro-magnetic interference.
Kramer recommends that CAT cables used for PoE Dante speakers should meet the following criteria:
• Use Category 6A cables or higher
• Use S/FTP or U/FTP shielded cables
• For long cable runs use 23 AWG conductors or thicker
• Use cables rated for 60°C or higher
• Use Low Smoke Halogen free rated (mainly for plenum and in-wall installations)
Kramer recommended cables:
• PC6A-LS508 - CAT6A S/FTP 500MHz 4x2x26AWG Patch Cord Low Smoke & Halogen Free available
from 0.15m to 30m
• BC-DGKat7a23 - Four–Pair CAT 7a S/FTP Data Bulk Cable (23AWG) – available in 100m and 305m bulks
• BC-UNIKAT CAT6A U/FTP Video & LAN Bulk Cable — Low Smoke & Halogen Free
Installation Best Practices
• Cable Length Limit: Keep total cable length between the PoE switch and the speaker under 100 meters
• Avoid Tight Bundling & Coiling
• Route Away from Electrical Noise: Do not run Ethernet cables parallel to power lines or close to lighting
dimmers and ballasts
• Ensure Proper Termination & Grounding: Especially for shielded cables (S/FTP or Cat7A), ensure grounding
is done correctly at one end
Step 5: Choosing the Best Location
• Plan the location of the speakers based on the designated listening area, the height of the ceiling and dispersion
angle of the speakers.
• Wall Type Suitability: Ensure the wall is appropriate for supporting the speaker’s weight.
• Obstruction Check: Verify the mounting location is free of obstructions like electrical piping, AC ducts, or water lines.
• Ceiling Clearance: Avoid placing speakers too close to the ceiling to prevent sound distortion.
• Avoid Reflective Surfaces: Minimize placement near glass, tiles, or other reflective materials to reduce unwanted
echo or reverb.
Step 6: Unpacking
1. Carefully remove the speaker and bracket from the packaging.
2. Inspect all components for damage before proceeding.
3. Dispose of the packaging materials according to regulations.
