LaCie 2big USB 3.0 • DESIGN BY NEIL POULTON Table of Contents

User Manual page 1

Table of Contents

1. Introduction .............................................................................................................. 4

1.1. Minimum System Requirements ..................................................................................................... 5

1.2. Box Content ................................................................................................................................ 6

1.3. Views of the Drive ........................................................................................................................ 7

1.4. Cables and Connectors ................................................................................................................ 9

2. Setting Up Your LaCie 2big USB 3.0 ....................................................................... 10

2.1. Connect the Interface Cable ....................................................................................................... 11

2.2. Turn the Drive On ...................................................................................................................... 12

2.3. Disconnecting Your Hard Drive ................................................................................................... 13

3. RAID ....................................................................................................................... 14

3.1. About RAID Modes ..................................................................................................................... 14

3.1.1. RAID 0 (FAST - High performance) .................................................................................... 14

3.1.2. JBOD (Just a bunch of disks) ............................................................................................ 15

3.1.3. RAID 1 (SAFE - Data protection) ........................................................................................ 16

3.2. Changing the RAID Mode ........................................................................................................... 17

3.3. Removing and Installing Drives .................................................................................................... 19

3.4. Formatting and Partitioning ......................................................................................................... 20

3.4.1. File System Formats ......................................................................................................... 20

3.4.2. Formatting for Window XP Users ....................................................................................... 22

3.4.3. Formatting for Windows Vista and Windows 7 Users ........................................................... 25

3.4.4. Formatting for Mac Users ................................................................................................. 29

4. Troubleshooting ..................................................................................................... 31

4.1. LED Status Indicators .................................................................................................................. 32

4.2. Basic Troubleshooting Topics ...................................................................................................... 33

5. Contacting Customer Support ................................................................................. 34

5.1. LaCie Technical Support Contacts ............................................................................................... 35

6. Warranty Information ............................................................................................. 36

LaCie 2big USB 3.0 • DESIGN BY NEIL POULTON Foreword

User Manual page 2

Copyrights

served. No part of this publication may

be reproduced, stored in a retrieval sys-

tem, or transmitted in any form or by any

means, electronic, mechanical, photo-

copying, recording or otherwise, without

the prior written consent of LaCie.

Trademarks

Apple, Mac, and Macintosh are regis-

tered trademarks of Apple Inc. Microsoft,

Windows 95, Windows 98, Windows Me,

Windows NT, Windows 2000, Windows

XP, Windows Vista, and Windows 7 are

registered trademarks of Microsoft Cor-

poration. Other trademarks mentioned in

this manual are the property of their re-

spective owners.

Changes

The material in this document is for in-

formation only and subject to change

without notice. While reasonable efforts

have been made in the preparation of this

document to assure its accuracy, LaCie

assumes no liability resulting from errors

or omissions in this document, or from the

use of the information contained herein.

LaCie reserves the right to make changes

or revisions in the product design or the

product manual without reservation and

without obligation to notify any person of

such revisions and changes.

Canada Compliance Statement

This Class B digital apparatus meets all

requirements of the Canadian Interfer-

ence-Causing Equipment Regulations.

Japan Compliance Statement

This is a Class B product based on the

standard of the Voluntary Control Coun-

cil for Interference from Information Tech-

nology Equipment (VCCI). If this is used

near a radio or television receiver in a

domestic environment, it may cause radio

interference. Install and use the equip-

ment according to the instruction manual.

FCC Statement

This device complies with Part 15 of the

FCC Rules. Operation is subject to the

following conditions:

1. The devices may not cause harmful

interference

2. The devices must accept any inter-

ference received, including inter-

ference that may cause undesired

operation.

NOTE: This equipment has been tested

and found to comply with the limits for

a Class B digital device, pursuant to Part

15 of the FCC Rules. These limits are

designed to provide reasonable protec-

tion against harmful interference in a

residential installation. This equipment

generates, uses and can radiate radio

frequency energy and, if not installed and

used in accordance with the instructions,

may cause harmful interference to radio

communications. However, there is no

guarantee that interference will not occur

in a particular installation. If this equip-

ment does cause harmful interference to

radio or television reception, which can

be determined by turning the equipment

off and on, the user is encouraged to try

and correct the interference by one or

more of the following measures:

✦ Reorient or relocate the receiving

antenna.

✦ Increase the separation between

the equipment and receiver.

✦ Connect the equipment into an out-

let on a circuit different from that to

which the receiver is connected.

✦ Consult the dealer or an experi-

enced radio/TV technician for help.

Manufacturer’s Declaration

for CE Certiﬁcation

We, LaCie, solemnly declare that this

product conforms to the following Eu-

ropean standards: Class B EN60950,

EN55022, EN55024, EN61000-3-2:

2000, EN61000-3-3: 2001

With reference to the following condi-

tions: 73/23/EEC Low Voltage Directive;

89/336/EEC EMC Directive

This symbol on the product

or on its packaging indi-

cates that this product must

not be disposed of with your

other household waste. In-

stead, it is your responsibility to dispose of

your waste equipment by handing it over

to a designed collection point for the re-

cycling of waste electrical and electronic

equipment. The separate collection and

recycling of your waste equipment at the

time of disposal will help to conserve nat-

ural resources and ensure that it is recy-

cled in a manner that protects human

health and the environment. For more in-

formation about where you can drop off

your waste equipment for recycling,

please contact your local city ofﬁce, your

household waste disposal service, or the

shop where you purchased the product.

CAUTION: Modiﬁcations not authorized

by the manufacturer may void the user’s

authority to operate this device.

CAUTION: A shielded-type power cord

is required in order to meet FCC emission

limits and also to prevent interference to

the nearby radio and television reception.

It is essential that only the supplied power

cord be used.

Tested to comply with FCC

standards for home or ofﬁce

use

LaCie 2big USB 3.0

100716v1.1

LaCie 2big USB 3.0 • DESIGN BY NEIL POULTON Foreword

User Manual page 3

Health and Safety

Precautions

✦ Only qualiﬁed persons are autho-

rized to carry out maintenance on

this device.

✦ Read this User Manual carefully

and follow the correct procedure

when setting up the device.

✦ Do not open a disk drive or attempt

to disassemble or modify it. Never

insert any metallic object into the

drive to avoid any risk of electrical

shock, ﬁre, short-circuiting or dan-

gerous emissions. The disk drives

shipped with your LaCie 2big USB

3.0 contain no user-serviceable

parts. If it appears to be malfunction-

ing, have it inspected by a qualiﬁed

LaCie Technical Support represen-

tative.

✦ Never expose your device to rain,

or use it near water, or in damp or

wet conditions. Never place objects

containing liquids on the LaCie

2big USB 3.0, as they may spill into

its openings. Doing so increases the

risk of electrical shock, short-circuit-

ing, ﬁre or personal injury.

✦ Make sure that the computer and

LaCie 2big USB 3.0 are electrically

grounded. If the devices are not

grounded, there is an increased risk

of electrical shock.

General Use

Precautions

✦ Power requirements 100-240 V~,

1.44 A, 50-60 Hz, (supply voltage

ﬂuctuations not exceeding ± 10%

of the nominal and transient over-

voltages according to over-voltage

category II).

✦ Do not expose the LaCie 2big USB

3.0 to temperatures outside the

range of 5° C to 35° C (41° F to

95° F); or to operational humidity

beyond 5-80%, non-condensing,

or non-operating humidity beyond

10-90%, non-condensing. Doing

so may damage the LaCie 2big

USB 3.0 or disﬁgure its casing.

Avoid placing your LaCie 2big USB

3.0 near a source of heat or ex-

posing it to sunlight (even through

a window). Inversely, placing your

LaCie 2big USB 3.0 in an environ-

ment that is too cold may damage

the unit.

✦ Rated cooling for altitudes up to

2000 meters.

✦ Always unplug the LaCie 2big USB

3.0 from the electrical outlet if there

is a risk of lightning or if it will be

unused for an extended period of

time. Otherwise, there is an in-

creased risk of electrical shock,

short-circuiting or ﬁre.

✦ Use only the power supply shipped

with the device.

✦ Do not use the LaCie 2big USB 3.0

near other electrical appliances

such as televisions, radios or speak-

ers. Doing so may cause interfer-

ence which will adversely affect the

operation of the other products.

✦ Do not place the LaCie 2big USB

3.0 near sources of magnetic inter-

ference, such as computer displays,

televisions or speakers.

✦ Magnetic interference can affect the

operation and stability of your La-

Cie 2big USB 3.0.

✦ Never use excessive force on your

LaCie 2big USB 3.0. If you detect a

problem, consult the Troubleshoot-

ing section in this manual.

✦ Protect your LaCie 2big USB 3.0

from excessive exposure to dust

during use or storage. Dust can

build up inside the device, increas-

ing the risk of damage or malfunc-

tion.

✦ Never use benzene, paint thinners,

detergent or other chemical prod-

ucts to clean the outside of the La-

Cie 2big USB 3.0. Such products

will disﬁgure and discolor the cas-

ing. Instead, use a soft, dry cloth to

wipe the device.

✦ Please replace defective hard drives

only with a new drive provided by

LaCie. For drive removal process,

see section 3.3. Removing and In-

stalling Drives.

IMPORTANT INFO: Any loss, corrup-

tion or destruction of data while using

a LaCie drive or drive system is the sole

responsibility of the user, and under no

circumstances will LaCie be held liable for

the recovery or restoration of this data. To

help prevent the loss of your data, LaCie

highly recommends that you keep TWO

copies of your data; one copy on your

external hard disk, for instance, and a

second copy either on your internal hard

disk, another external hard disk or some

other form of removable storage media.

If you would like more information on

backup, please refer to our web site.

IMPORTANT INFO: 1TB (Terabyte)

= 1,000GB. 1GB = 1000MB. 1MB =

1,000,000 Bytes. Total accessible ca-

pacity varies depending upon operating

environment (typically up to 10% less per

TB). Capacity and cache memory vary de-

pending upon RAID mode.

Produktspecifikationer

Varumärke:	LaCie
Kategori:	Extern hårddisk
Modell:	2big USB 3.0
Vikt:	3600 g
Bredd:	93 mm
Djup:	200 mm
Höjd:	183 mm
Snabbstartsguide:	Ja
USB-version:	3.2 Gen 1 (3.1 Gen 1)
Material:	Gjuten aluminium
Modell:	HDD
Total lagringskapacitet:	4000 GB
Kompatibla operativsystem:	Windows XP, Windows Vista, Windows 7 /Mac OS X 10.5, 10.6 (USB 2.0
USB-kontakt:	USB Type-A
Läshastighet:	190 MB/s
Skrivhastighet:	160 MB/s
Antal USB 3.2 Gen 1 (3.1 Gen 1)-portar:	1
Bussdriven:	Nej
FireWire 400:	Nej
FireWire 800:	Nej
Integrerad USB-kabel:	Ja
Produktens färg:	Silver
Hårddiskkapacitet:	2000 GB
Nätverksansluten (Ethernet):	Nej
Hårddiskens rotationshastighet:	7200 RPM
RAID-nivåer:	JBOD
Manual:	Ja
Intern:	Nej
Mac-kompatibel:	Ja
Datalagringsenhetens buffertstorlek:	16 MB
Hårddiskens storlek:	- "
Minimum hårddisk utrymme:	600 MB
Byte under drift (hotswap):	Ja
Tillgängliga dataöverföringshastigheter:	USB 3.0 5Gbits/s, USB 2.0 480Mbits/s
Antalet inkluderade diskar:	2 styck
USB kabel:	USB
