SANIX PRO 7.5 battery sprayer
Designed to carry out the protection treatment with water solutions of insecticides, fungicides,
herbicides and fertilizers. It is also dedicated to the application of ecological preparations based
on paran oil and plant solutions. It is recommended to use one sprayer for the selected group of
chemicals.
CAUTION !!! Do not use a chemically active agents, including acids and bases, disinfectants,
impregnation, containing solvents, cleaners and petroleum resources.
Failure to follow this instruction may result damage to the sprayer orpermanent harm to health.
The set contained in the package is presented in Container with belt, hose Fig. 3. a.
with springs and feeding valve integrated with handle, Battery pack 3,4Ah with control b.
package, Charger 12,6V; 3A for charging the package, Telescopic lance with adjustable c. d.
nozzle MR 1,5 mm, Funnel with strainer, Spare nozzles: round nozzle MR 1.0, MR 2.0, flat e. f.
stream nozzle MF 3.0 and additional gaskets: , and silicone grease, User’s Fig. 1c. Fig.1d. g.
manual with a warranty card, EU DECLARATION OF CONFORMITY
The manufacturer reserves the right to change the equipment of the sprayer.
1. Before you start working with the sprayer, read these operating instructions.
2. Before starting work, prepare sprayer and check the tightness and correct operation
of the sprayer using clean water. For this purpose, fix the lance with the feeding valve
integrated with the handle , remove the battery pack with the control panel , Fig. 1. Fig.4b.
remove the safety foil and insert the package so that the click sound is heard Fig.4b. Fig.
4a. Fig.6a., then check the battery charge level by pressing the TEST button The LED
indicators on the panel will light up, showing the level of charging. Before pouring water,
make sure that the pump filter Fig. 1f. Fig. 5a. isproperly inserted and locked Unscrew the
tank nut Fig. 7., pour clean water and screw the nut. Press the button ON/OFF on the control
panel , the diodes will start to flash , press the feeding valve button Fig. 6a. Fig.6a,b,c.
Fig.11a. from the nozzle, air should first come out, then water.
3. In order to start working with the sprayer: empty the tank from water, then pour in
solution prepared in advance according to the producer recommendation, don’t exceed the
level indicated on the scale Fig. 7. Fig. 7., tighten the tank nut Press the button ON/OFF on
the control panel , extend the telescopic lance and then direct the lance to the place Fig.6a.
where spray will be carried out and press the feeding valve button , start spraying. Fig. 11a.
Continuous sprayer operation is possible by pressing the feeding valve button and moving
it forward After finishing work, release the feeding valve lock by moving the button Fig. 11a.
backwards. and switch the control package o with the ON/OFF button Fig. 11a. Fig. 6a.
4. Nozzle replacement:
– replacement of a cone 1.5 mm (yellow) nozzle with 1.0 mm (green) nozzle. To do this,
unscrew the yellow nozzle cap and screw the green nozzle cap Fig. 10a.
– replacement of the cone nozzle with a flat-stream nozzle. To do this, unscrew the nozzle
cap , then unscrew the black nut, take out the core and O-ring , insert the Fig. 10a. Fig.10b.
flat-stream nozzle into the black nut , then insert the O-ring and tighten.Fig. 10c.
5. The battery pack 3.4Ah with the control panel is an exchangeable element available in
the sales oer.
1. The guarantee period is 24 months from the date of purchase. The warranty excludes:
pump with engine, control package with battery and charger, for which the warranty period
is 12 months. The tank is covered by a 60-month warranty.
2. Reclamation should be lodged to the seller of the sprayer.
3. CAUTION! Dirty and contaminated with chemicals sprayers, supplied as a complaint,
or sprayers with any content will not be repaired. Thoroughly empty, rinse and clean
them beforehand!
4. The claims will be accepted after showing the defected part or giving the full description
of the fault.
5. The guarantee repairs should be made using always the genuine parts.
6. Number of repairs after which the seller cannot refuse to exchange the sprayer for anew
one (in case there are still defects) is 3.
7. Operations connected with exploitation of the sprayer and described in the manual are
not treated as guarantee repairs.
8. The producer will not accept the claim if there were changes in pressure regulation or the
storing, operating, maintaining of the product were not according to the manual.
9. Mechanical damages caused by the user cannot be the subject to reclamation. The
damaged parts can be exchanged but the costs are charged.
10. The warranty does not cover damage resulting from the use of an unsuitable charger.
1. Do not store the sprayer in sunlight or in temperatures below +4°C.
2. After finishing work, thoroughly wash the sprayer using clean water and blow air
through it. Perform maintenance periodically.
After washing the sprayer and blowing the air through it, you should: unscrew the hose from
the handle, remove the filter and clean it under running water using a soft brush. Fig. 11b.
Unscrew the nut from the feeding valve in the handle, take out the valve piston with a spring
Fig. 11c. Fig. 2i., clean and lubricate it with silicone grease , put it back and tighten the nut.
Unscrew the nozzle nut remove the nozzle and rinse it thoroughly with water, then Fig. 10a.
lubricate with silicone grease O-ring Unlock and remove the pump filter Fig. 1d. Fig. 5a, b, c,
d. Fig. 5a. and clean it under running water using a soft brush, then insert and lock (a small
amount of liquid may flow out after removing the filter). Unscrew the tank nut Fig. 7., remove
the funnel with strainer and rinse with water, then put it back in the tank and screw Fig. 9.
the nut. shows the diagram of the elements to be maintained or which are wasted Fig.1.
and must be replaced by purchasing a repair kit Z08x Fig. 2.
3. Maintenance and repairs should only be carried out with silicone grease.
Using other lubricants will damage the sprayer.
CAUTION! All repair, replacement or maintenance operations concerning the pump
unit, battery and control package may only be carried out at authorized services. If you
attempt to repair, replace ormaintain above mentioned items, you lose your warranty.
GB
In order to charge the battery, stick the included charger into the charging socket in the
control package , and then connect it to the power supply 230V 50 Hz. It is possible Fig. 4c.
to charge the battery when the package is in the sprayer, as well as independently outside
the sprayer. After connecting the charger, the diodes will start to flash, the charging cycle
is in progress. The battery is fully charged when all the LED indicators are on. If the Fig. 6.
battery has a low level of charging and only the red indicator light is on, it means that the
sprayer battery needs to be charged before starting work. Charging should be stopped only
when the battery is fully charged. The sprayer should be stored with a charged battery, what
should be periodically checked by pressing the TEST button Prolonged storage of Fig. 6a.
the sprayer with adischarged battery may damage the battery.
WARNING! The control package can be charged only with the included charger or12.6V,
3A charger. If you try to use the charger with other parameters, the panel may be
permanently damaged or the battery will not get charged.
1. APPLICATION AND USE
OWNER MANUAL
2. EQUIPMENT OF THE SPRAYER
4. CHARGING THE BATTERY
3. PREPARATION AND OPERATION OF THE SPRAYER
5. WORK SAFETY REGULATIONS
6. SERVICE AND WARRANTY REPAIRS
7. STORAGE AND MAINTENANCE OF THE SPRAYER
e
f
b
d
c
a
BATTERY SPRAYER
IRRORATRICE A BATTERIA
PULVERIZADOR DE BATERÍA
AKKU-SPRÜHGERÄT
PULVÉRISATEUR À BATTERIE
g
h
i
d
SANIX
PRO 7.5
a
b
d
d
2
1
c
g
h
1. Children, pregnant women, people taking medicines or other drugs restricting the
concentration powers or drinking alcohol are forbidden to operate the sprayer.
2. Before first spraying check the tightness and correct operation of the sprayer using clean
water.
3. When working with chemicals (also during liquid preparation and destroying the
packages) itis necessary to wear protective clothing (rubber boots, gloves, a coat, acap
and a mask).
4. It’s forbidden to work with chemicals on an empty stomach and eat or drink during
working. It’s forbidden to drink alcohol one day before and one day after working with
chemicals.
5. It’s forbidden to pour the liquid remains to the open water reservoirs or biological sewage
treatment plants. These notes apply also to the water after cleansing the container and
other parts of the sprayer.
6. Expendable sprayer should be handed over for utilization.
6a. The used battery pack with the control panel should be given to a collection point for
used electrical and electronic equipment and batteries.
7. People working using the sprayer should strictly comply to all the recommendations on
the package of the spraying agents. In case of poisoning the doctor must be contacted.
8. It’s is forbidden to work using defective sprayer or with any leakage. Do not expose the
sprayer toimpact.
9. All the operations should be done after decompression of the sprayer.
10. Thoroughly cleanse the sprayer after each using and before servicing.
11. It’s is forbidden to use the sprayer for other purposes than stipulated in the owner
manual.
12. It’s forbidden to store the sprayer filled with a liquid and under pressure.
13. It’s forbidden tospray with liquids warmer than +40°C, and with easy inflammable
chemicals orsubstances which can cause an explosion e.g. petrol, solvents.
14. Changes in the sprayer or using it not according to its allocation can result in poisoning
people or animals, polluting the environment, damaging the sprayer orserious accidents.
15. After finishing work, you should change your clothes (the protective clothes must be
cleaned), wash your hands, face, mouth and throat, and clean your nose.
16. After finishing work, rinse the sprayer using clean water.
17. The user is fully responsible for the damages caused by not complying with these
recommendations.
18. Always check the battery level before starting work.
19. It’s forbidden to point the lance of the sprayer and spray the liquid in the direction of the
face.
20. The sprayer while working and storing should be secured from any unauthorized
people, especially children.
21. When using other agents, make sure that it can be used in the sprayer, and that they are
not harmful to the sprayer, people and the environment.
22. CAUTION! The sprayer’s control package is splash-proof and has a higher moisture
level, isnot resistant to flooding and frequent contact with water.
a
b
a
c
c
d
b
c
a
b
c
d
b
a
b
c
3 4
5
6
7 8
b
a
max
10
9
11
click
click
d
e
f
g
CAUTION! Removing the filter Fig. 1f. liquid will flow out of the tank.
It is recommended to use sprayer for one group of chemical substances. The
sprayer once used for chemicals, can not be used for other purposes !!!
In the lance handle integrated with the feeding valve is used filter R40 which has to
prevent clogging of the nozzles.
8. GENERAL REMARKS
