Läs gratis den bruksanvisning för LevelOne FCS-3055 (41 sidor) i kategorin övervakningskamera. Guiden har ansetts hjälpsam av 3 personer och har ett genomsnittsbetyg på 4.8 stjärnor baserat på 2 recensioner. Har du en fråga om LevelOne FCS-3055 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga
Sida 1/41
Fixed Dome Network Camera
Hardware User Manual
FCS-3055, FCS-3082, FCS- 3083
Ver.2014/ / 01 15
Hardware Manual
2
Table of Contents
Precautions ....................................................................... 4
Safety Instructions ................................................................................................... 6
Introduction ..................................................................... 7
The List of Models ................................................................................................... 7
Ou Package Contents ............................................................................................... 8
Physical Description ................................................................................................ 9
Installing the Camera on a Surface .............................. 11
Step 1: Drill the Holes ............................................................................................ 11
Step 2: Open the Dome Cover .............................................................................. 12
Step 3: Prepare for Waterproof Installation........................................................ 14
Waterproof Solution with Naked Cable ................................................. 15
Waterproof Solution with Conduit .......................................................... 17
Step 4: Install the Camera to the Surface ............................................................ 21
Step 5: Connect the Cable(s) ................................................................................. 22
Step 6: Access the Camera Live View .................................................................. 23
Step 7: Adjust the Viewing Angle ......................................................................... 23
Step 8: Close the Dome Cover .............................................................................. 24
Other Connections ......................................................... 25
Connecting DI/DO and Audio Devices (Optional) .............................................. 25
How to Connect DI/DO Devices ............................................................ 25
How to Connect Audio Devices ............................................................. 29
Hardware Manual
3
Other Adjustments and Accessories ............................. 30
How to Adjust the Viewing Angle ........................................................................ 30
FCS-3055 / FCS-3082 / FCS-3083 ....................................................... 30
How to Install / Remove the Memory Card......................................................... 31
How to Insert the Memory Card ............................................................ 31
How to Remove the Memory Card ........................................................ 31
How to Replace the Dome Cover .......................................................................... 32
Accessing the Camera 35....................................................
Configure the IP Addresses ................................................................................... 35
Access the Camera ................................................................................................. 39
Produktspecifikationer
| Varumärke: | LevelOne |
| Kategori: | övervakningskamera |
| Modell: | FCS-3055 |
