LevelOne FCS-5057 Bruksanvisning

LevelOne övervakningskamera FCS-5057

Läs nedan 📖 manual på svenska för LevelOne FCS-5057 (37 sidor) i kategorin övervakningskamera. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF

Sida 1/37

Fixed Network Camera

Hardware User Manual

FCS-5054, FCS-5057, FCS-5064

Ver. 2014 3/0 /27

Hardware Manual

Table of Contents

Precautions 4

Safety Instructions..................................................................................... 6

Introduction 7

List of Models .............................................................................................. 7

Package Contents ...................................................................................... 8

Physical Description ................................................................................. 9

Installation Procedures Using the Bundled

Bracket 11

Step 1: Install the Bundled Bracket...................................................... 11

Step 2: Attach the Sunshield ................................................................ 12

Step 3: Install the Camera ...................................................................... 13

Step 4: Waterproof and Connect the Cable ...................................... 14

How to Use the Cable Gland ........................................................ 15

How to Use the Conduit Gland ..................................................... 18

Step 5: Connect the Cable ..................................................................... 22

Step 6: Access the Camera Live View ................................................ 22

Other Connections 23

How to Connect DI/DO Devices (Optional) ........................................ 23

How to Connect Audio Input / Output Devices (Optional) ............ 26

Adjustments and Accessories 27

How to Install / Remove the Memory Card ........................................ 27

How to Insert the Memory Card ................................................... 27

How to Remove the Memory Card ............................................... 28

Adjust the Viewing Angle and Focus .................................................. 29

How to Reset the Camera ...................................................................... 30

Accessing the Camera 31

Hardware Manual

Configure the IP Addresses .................................................................. 31

Using DHCP Server to Assign IP Addresses ................................ 31

Using the Default Camera IP Address .......................................... 33

Access the Camera .................................................................................. 35
