GEP-2421 Series
24-Port Gigabit PoE Switch,
802.3af/at PoE
User’s Manual
FCC Warning
This device has been tested and found to
comply with limits for a Class A digital device,
pursuant to Part 15 of FCC Rules. These
limits are designed to provide reasonable
protection against harmful interference when
the equipment is operated in a commercial
environment. This equipment generates
and radiates radio frequency energy and, if
not installed and used in accordance with the
user’s manual, it may cause interference in
which case users will be required to correct
interference at their own expenses.
CE Warning
This is a Class A product. In a domestic
environment, this product may cause radio
interference in which case the user may be
required to take adequate measures.
Introduction
This switch provides / /1000M ports. 24 10 100
It was designed for easy installation and high
performance in an environment where trac
is on the network and the number of users
increases continuously.
It consists of PSE/PoE ports. That can 24
solve the limitation of the power outlet
location and oer the system designer a
exible solution to locate the network device
everywhere .
The rack-mount size was specically
designed for medium to large workgroups.
The Switch can be installed where space is
limited; moreover it provides smooth network
migration and easy upgrade to network
capacity. The 19” size can be rack-mount on
19” cabinet.
Package Contents
Before you start to install th switch, please is
verify your package that contains the following
items:
One PoE Giga Ethernet Switch
One Power Cord
One User’s Manual
Note: If any of these items is found missing or
damaged, please contact your local supplier
for replacement.
Key Features
Port 10/100/1000M Nway 24
(Auto-negotiation) Switch
PSE/PoE function ports 24
Supporting the power Max. W for each 30
PSE/PoE port
-mount size 19” rack
Auto-learning of networking congurations
Auto-detect full/half-duplex modes for any
port
Dedicated full-duplex 2Gbps bandwidth
Store- -Forward switching methods and
IEEE 802.3x ow control for full-duplex and
back-pressure ow control for half-duplex
Non-blocking & Non-head- -line blocking of
full wire speed forwarding
Auto-MDI/MDI-X function for any port
Smart plug & play
Front Panel (LEDs)
LED Indicators of Port PoE 24
10/100/1000M Switch
LED
Status
Description
Power
On
Power is on.
O
Power is off.
L AN
Green On
Connect in 1000Mbps.
Yellow On
Connect in 10/100Mbps
O
No connection.
Flashing
Data is transmitting or
receiving
PoE
Yellow On
Port is linked to Power
Device
O
No Power Device is
connected
Connections
Switch/Hub to this Port PoE Giga 24
Ethernet Switch
This switch provides automatic crossover
detection functionality for any port. It is
simple and friendly to up-link to another
switch without crossover cable.
PC/Other devices to this Ports Giga 24
Ethernet Switch
Via a twisted pair cable straight through, this
switch can be connected to PCs, servers and
other network devices.
Power Device to this Port PoE Giga 24
Ethernet Switch and getting V power 56
source through Cat 5 cables .
Using Cat. twisted-pair cable to connect Power5
Device to the port of this switch and then1~24 ,
this switch will supply 56V power to Power
Device over Cat twisted-pair cable. Please be. 5
noted Power Device should also comply with
IEEE 802.3at(30w per PoE port) and 802.3a f.
Rear Panel (Power)
AC input
AC input ( 0~240V/AC, 50~60Hz) 10
Technical Specications
Standards
IEEE 802.3at/802.3af
IEEE 802.3 10BaseT
IEEE 802.3u 100Base-TX
IEEE 802.3ab 1000Base- TX
IEEE 802.3x Flow control
Features
Number of Ports: 24
PSE/PoE Ports
MAC Address: 8K
Buer Memory: 256KB
Method: Store and
Forward
Filtering/
Forwarding
Rates
1000Mbps port –
1,480,000pps
100Mbps port 148,800pps –
10Mbps 14,880pps –
Transmission
Media
10BaseT Cat. 3, 4, 5
UTP/STP
100/1000BaseTX Cat. 5
UTP/STP
LED
Indicators
Per Port: LINK/ACT, PoE
ACT/Status
Per Unit: Power
Power Input
100~240V/AC, 50~60Hz
Power
Output
56V/DC Per Port Output –
30 W Max Per Port
Output Supported
Power
Consumption
150/250/380/500/630
Watts (Max)
Dimensions
480 × 200 × 44 mm
(L x W x H)
Weight
2.85 kg
Operating
Temperature
0 to 40℃
Storage
Temperature
-20 to 70 ℃
Humidity
10 to 90% RH
( -condensing) non
Certications
FCC Class A, CE
