Quick Installation Guide

( ) Managed Commercial Grade Switches

- 1 -

Content

English .........................................................................................................2

Deutsch...............................................................................................................

Français ..................................................................................................... 9 ..

Español ............ .....................1..................................................................... 2

Italiano .............................................................................................................

Português ........................................................................................................

This Quick Installation Guide only describes the most basic situations and

settings. All detailed information is described in the user manual.

- 2 -

English

Package Contents

This product is provided with the following accessories in the box; please check them carefully. If

any of the accessories is missing or damaged, please contact with your local dealer timely.

Serial number

Name

Quantity

Note

Master unit

Required

Power cord

Required

Quick Installation Guide

Required

Declaration of Conformity

Required

L-shaped bracket and other

Required

Preparing for installation

For smooth installation, please prepare the following items:

l Installation tools, including: Phillips screwdriver, static wrist anti strap,etc.

l Connecting cables, such as network cable, optical fiber, optical fiber module, etc.

l Related devices, such as electrical outlets, HUB, switch, router,etc.

The installation environment for the switch must meet the following requirements:

l The switch must avoid direct sunlight, away from heat and sources of strong electromagneticinterference.

l The switch must be placed in a cool, dry place, and there should be enough gap for heat dissipation all

around for the purpose of ventilation and heat dissipation.

l -1 0 1 0The switch must work in the indoor environment with a temperature of 0 °C~5 °C and humidityof 0%~9 %

without condensation.

Equipment Installation

1. I nstalled in the rack

Install the switch on a 19-inch standard rack, and the installation steps are as follows:

Check the grounding and stability of the rack;

Install the two L-shaped brackets accessories in the on both of sides the switch panel, and fix

them with the screws in the accessories;

Place the switch in of the appropriate location the rack, and support itusing a tray;

Secure the L-shaped brackets guide on the slots fixed the rack, at both ends of to thatensure the

switch can mounted be on the rack in astable, horizontal manner;

Use a power cord power connector with to connect the switch the powersocket.
