Sida 1/2

TX + 1

Quick

IES-0600

Switch SFP + 1Combo

40 to 75

Installation Guid

v1.00 - 1401

IES-0600 Page 1

Overview

LevelOne IES-0600 Industry Ethernet Switch provides 4 ports

of 10/100/1000Base-T Ethernet plus 2 ports of Gigabit SFP to

enable high speed network at mission-critical environment. The

compact metal housing is designed for desktop space saving,

plus the clearly visible status LEDs provide simple monitoring of

port link activity. Moreover, the SFP slots support pluggable

modules that enabling you to choose from a variety of

transceivers.

High Reliability

All components are built to withstand harsh environment

applications without compromise where humidity, temperature

variation and even shock vibration are concerns, including

Electric & Utility, Critical Infrastructure, Transportation and

Surveillance Security. This device operates under -40 to 75

Celsius (-40 to 167 Fahrenheit) temperature.

Plug & Play

This unmanaged Industrial Ethernet Switch is designed for the

demanding industrial environments at businesses in need of

instant connectivity with no setup or configure required, truly

plug and play.

IES-0600 Page 2

Features

• Meets NEMA TS1/TS2 Environmental requirements such as temperature,

shock, and vibration for traffic control equipment

• Meets EN61000-6-2 & EN61000-6-4 EMC Generic Standard Immunity for

industrial environment

• Supports 1024 MAC addresses. Provides 1M bits memory buffer

• Provides one combo Gigabit ports. SFP socket for Gigabit fibre optic

expansion.

• Store-and-forward mechanism. Full wire-speed forwarding rate.

• Power Supply: 12~55VDC Terminal Block power input.

• 5.52W power consumption 48VDC @ 0.12A (unit only)

• -40 to 75 (-40 to 167 ) operating temperature range. ℃ ℃ ℉ ℉

• Tested for functional operation @ -40 to 85 (-40 to 185 ). ℃ ℃ ℉ ℉

• Hardened metal case

Package Contents

 IES-0600

 Quick Installation Guide

IES-0600

LED Stat

LED

Sta

PWR 1, 2

Steady

Off

P1 ~ P4

Steady

Off

10/100/1000Base-TX

(

LNK

Steady

Flashin

SPD

Steady

Off

1000Base-SFP

Steady

Flashin

Steady

Off

tus

atus

Descriptio

Power On

Power Off

PD is connected

No PD is connected

T1 ~ T5)

Network connection esta

Transmitting or Receivin

1000M speed is establis

10M or 100M speed is e

Network connection esta

Transmitting or Receivin

A valid

connection estab

No connection is being e

Page 3

ablished

ng data

shed

established

ablished

ng data

blished

established

IES-0600

Power In

Terminal Block

PW1

PW2

Rela

nput

–

VDC

–

Power Ground

12 – 55VDC

–

Power Ground

ay Output

1A @ 24VDC

Page 4

IES-0600

DIP Swit

OFF

T5 (

F5 (

Note:

Port5 (T5 & F5

RJ45 or SFP via DIP

tch

DIP1

RJ45) enabled

1000M

(SFP) enabled

100M

5) is shared combo port

, enabl

P1 switch

Page 5

e either

IES-0600

DIN Rail

•

Assembly: Place t

the slot. Push the

surface until it aud

•

Start-

up: Connect

via the terminal bl

•

Dismantling: Pull o

switch from the DI

Mount

the switch on the DIN rail from

front of the switch toward the m

dibly snaps into place

t the supply voltage to start up t

ock (or DC JACK)

out the lower edge and then re

IN rail.

Page 6

above using

mounting

the switch

emove the

IES-0600

10/100/10

The following lists th

10/100 DC

Rx +

Rx -

x +

unused

Tx -

unused

000Base

TX P

pin-out of 10/100/1000Base

C & Data

1000

DC & B

DC +

TxRx A +

DC + TxRx A -

TxRx B +

TxRx C +

TxRx C -

DC - TxRx B -

TxRx D +

TxRx D -

Page 7

TX ports

Data

DC +

DC -

Produktspecifikationer

Varumärke:	LevelOne
Kategori:	brytare
Modell:	IES-0600
Vikt:	720 g
Bredd:	40 mm
Djup:	105 mm
Höjd:	38 mm
Förpackningens bredd:	215 mm
LED-indikatorer:	Activity, Link, Power
Snabbstartsguide:	Ja
Ursprungsland:	Taiwan
Spänning:	5 - 56 V
Paketbuffertminne:	1 MB
Full duplex:	Ja
Produktens färg:	Svart
Monteringsbar på väggen:	Ja
Förpackningstyp:	Låda
Låddjup:	165 mm
Vikt inkl. förpackning:	120 g
Strömförsörjning via Ethernet (PoE) stöd:	Nej
Effekt skyddsfunktioner:	Overload, Reverse polarity
Temperatur vid drift:	-40 - 75 ° C
Temperaturintervall (förvaring):	-40 - 85 ° C
Intervall för relativ operativ luftfuktighet:	5 - 95 %
Fuktighet (förvaring):	5 - 95 %
Internationellt skydd (IP) kod:	IP30
Material, hölje:	Metall
Kommunikationsstandarder:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Harmonized System (HS)-kod:	85176990
Adresstabellstorlek:	1024 poster
Jumboramar:	10000
Switch kapacitet:	12 Gbit/s
10G stöd:	Nej
Flödeskontroll:	Ja
Antal grundläggande RJ-45 Ethernet-portar:	4
Typ av grundläggande RJ-45 Ethernet-portar:	Gigabit Ethernet (10/100/1000)
Lagra-och-vidarebefordra:	Ja
Antal SFP-modulplatser:	1
Autonegotiation:	Ja
Auto MDI / MDI-X:	Ja
DIN-skena:	Ja
Plintport:	Ja
Paketförmedlingshastighet (1 Gbps):	1488000 pps
Paketförmedlingshastighet (10 Mbps):	14880 pps
Paketförmedlingshastighet (100 Mbps):	148000 pps
