Sida 1/10

LevelOne

User Manual

KVM- 60 02

Cable KVM Switch, 2 Ports, DVI, USB, Audio

Version 1.0

TABLE OF CONTENTS

1. INTRODUCTION ........................................................................................................................................ 3

1.1. FEATURES............................................................................................................................................ 3

1.2. PHYSICAL IAGRAMD ............................................................................................................................ 4

1.3. PACKAGE ONTENTSC .......................................................................................................................... 4

2. SPECIFICATIONS 5.....................................................................................................................................

3. INSTALLING THE USB/DVI CABLE KVM SWITCH ........................................................................... 6

3.1. S RYSTEM EQUIREMENTS .................................................................................................................... 6

3.2. HARDWARE NSTALLATIONI .................................................................................................................. 6

3.3. H SOT WAPPABLE ................................................................................................................................ 6

3.4. D IRIVER NSTALLATION INDOWS ONLY(W 98/SE ) ............................................................................... 6

4. OPERATION ............................................................................................................................................... 9

4.1. P BUSH UTTON PERATIONO ................................................................................................................. 9

4.1.1. S PC ELECTION ............................................................................................................................... 9

4.1.2. A UTO CAN-S .................................................................................................................................... 9

4.2. H K OOT EY PERATION .......................................................................................................................... 9

4.2.1. S PC ELECTION ............................................................................................................................. 10

4.2.2. A S UDIO ELECTION ........................................................................................................................ 10

1. Introduction

Thank you for purchasing 2-port USB/DVI Cable KVM Switch with Audio!

You now have a high quality, durable system that enables you to control two

computers from one console (USB Mouse, Keyboard, and Monitor). In

addition, this device allows you to independently control and switch audio

between two computers.

1.1. Features

1. Controls 2 computers from a single console (Keyboard/Mouse) over USB

connection.

2. Support Window 98SE/ME/2000/XP/Vista/2003 server, Mac , Linux

3. Compliant with DVI 1.1 standards,

4. Supports speaker and Microphone.

5. Emulates a keyboard on each PC allow your computers to boot normally to

without a keyboard error.

6. Supports hot-swap. All devices connected to the KVM can be added or

removed at any time, without shutting the unit down.

7. Supports USB keyboard Hot-Key Switch (for Microsoft Windows series) and

push buttons for easy operation.

8. Supports Auto-Scan function to alternate video between both computers.

9. Supports LED display for PC and audio status monitoring.

10. Supports max resolution: 1920x1080@60Hz

11. Supports Plug and Play.

12. Self powered through USB connection.

13. Supports independent audio switching.

Produktspecifikationer

Varumärke:	LevelOne
Kategori:	ej kategoriserat
Modell:	KVM-0260
Inbyggd display:	Nej
Vikt:	457 g
Bredd:	87 mm
Djup:	62 mm
Höjd:	24 mm
Förpackningens bredd:	160 mm
LED-indikatorer:	Ja
Maximal upplösning:	1920 x 1200 pixlar
Ursprungsland:	Kina
Hörlursutgångar:	1
Certifiering:	CE, FCC
HDCP:	Ja
USB-anslutning:	USB Type-A
Antal mikrofoningångar:	1
Antal datorer:	2
Konsolportar:	3.5mm headphone, 3.5mm mic, DVI-I, USB A
Ljudanslutningar:	Ja
Kabellängd:	1.2 m
Produktens färg:	Black, Grey
bruksanvisning:	Ja
Låddjup:	50 mm
Vikt inkl. förpackning:	600 g
Mac-operativsystem som stöds:	Ja
Temperatur vid drift:	0 - 50 ° C
Temperaturintervall (förvaring):	-20 - 60 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
Fuktighet (förvaring):	10 - 90 %
Hållbarhetscertifiering:	RoHS
Video porttyp:	DVI-I
Kabel inkluderad:	KVM
USB-ström:	Ja
Antal USB 2.0 anslutningar:	2
Plug & Play-kompatibel:	Ja
Linux operativsystem som stöds:	Ja
Harmonized System (HS)-kod:	85176200
Tangentbord anslutningstyp:	USB
Mus porttyp:	USB
Stöd för DDC2B:	Ja
Antal DVI-I anslutningar:	1
Skärmbytesknapp:	Ja
