OWNER’S MANUAL
DVD Home
Theater System
1912_Rev02
www.lg.com
Copyright © 2019 LG Electronics Inc. All Rights Reserved.
Please read this manual carefully before operating your set and retain it for future
reference.
MODEL
LHD647 (LHD647, S67T2-S, S67S2-S, S67T2-C, S67T2-W)
MFL71261813

Getting Started2
Getting Started
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product’s
enclosure that may be of sufcient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature
accompanying the product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
CAUTION: The apparatus should not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, should be placed on the
apparatus.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: Do not use high voltage products around
this product. (ex. Electrical swatter) This product may
malfunction due to electrical shock.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided
for ventilation and to ensure reliable operation of
the product and to protect it from over heating.
The openings should never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION: This product employs a Laser System.
To ensure proper use of this product, please read
this owner’s manual carefully and retain it for future
reference. Shall the unit require maintenance, contact
an authorized service center.
Use of controls, adjustments or the performance of
procedures other than those specied herein may
result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try
to open the enclosure.
CAUTION concerning the Power Cord
The Power Plug is the disconnecting device. In case
of an emergency, the Power Plug must remain readily
accessible.
Check the specication page of this owner’s manual
to be certain of the current requirements.
Do not overload wall outlets. Overloaded wall outlets,
loose or damaged wall outlets, extension cords, frayed
power cords, or damaged or cracked wire insulation
are dangerous. Any of these conditions could result
in electric shock or re. Periodically examine the
cord of your device, and if its appearance indicates
damage or deterioration, unplug it, discontinue use of
the device, and have the cord replaced with an exact
replacement part by an authorized service center.
Protect the power cord from physical or mechanical
abuse, such as being twisted, kinked, pinched, closed
in a door, or walked upon. Pay particular attention to
plugs, wall outlets, and the point where the cord exits
the device.

Getting Started 3
Getting Started
1
NOTICE: For safety marking information including
product identication and supply ratings, please refer
to the main label on the bottom or the other surface
of the product.
CAUTION: No naked ame sources, such as lighted
candles, should be placed on the apparatus.
Symbols
~Refers to alternating current(AC).
0Refers to direct current(DC).
Refers to class II equipment.
1Refers to stand-by.
!Refers to “ON” (power).
Refers to dangerous voltage.

Table of Contents4
Table of Contents
1 Getting Started
2 Safety Information
6 Unique Features
6 – Portable In
6 – USB Direct Recording
6 – Full HD up-scaling
6 – Home Theater Speaker ez Setup
6 – Bluetooth®
7 Introduction
7 – Playable Discs
7 – About the “ ” Symbol Display7
7 – Symbols Used in this Manual
7 – Regional Codes
8 Playable file Requirement
9 Remote control
10 Front panel
11 Rear panel
2 Connecting
12 Speaker Installation
13 Assembling the speaker
15 Attaching the speakers to the unit
16 Positioning the system
17 Connections to Your TV
17 – HDMI Out Connection
18 – What is SIMPLINK?
19 – Video Connection
19 – Resolution Setting
20 Video Output Resolution
20 Optional Equipment Connection
20 – AUX (L/R) INPUT Connection
21 – PORT. IN (Portable Input) Connection
21 – Listening to music from your portable
player or external device
21 – USB Connection
22 – OPTICAL IN connection
22 – Home theater speaker ez setup
22 – Antenna Connection
3 System Setting
23 Adjust the setup settings
23 – OSD Initial language settings - Optional
23 – To display and exit the Setup menu
24 – Language
24 – Display
25 – Audio
26 – Lock (Parental Control)

Getting Started6
Getting Started
1
Unique Features
Portable In
Listen to music from your portable device. (MP3,
Notebook, etc.)
USB Direct Recording
Records music from CD to your USB device.
Full HD up-scaling
Views Full HD picture quality with simple setup.
Home Theater Speaker ez Setup
Listen to sounds from TV, DVD and Digital device with
vivid 5.1 (2.1 or 2.0) ch mode.
Bluetooth®
Listens to music stored on your Bluetooth device.

Getting Started 7
Getting Started
1
Introduction
Playable Discs
This unit plays DVD±R/RW and CD-R/RW that
contains audio titles, MP3, WMA and/or JPEG les.
Some DVD±RW/DVD±R or CD-RW/CD-R cannot
be played on this unit due to the recording quality or
physical condition of the disc, or the characteristics of
the recording device and authoring software.
DVD-VIDEO (8 cm/12 cm disc)
Discs such as movies that can be
purchased or rented.
DVD±R (8 cm/12 cm disc)
Video mode and nalized only.
DVD-RW (8 cm/12 cm disc)
Video mode and nalized only.
DVD+R: Video mode only
Supports the double layer disc also.
DVD+RW (8 cm/12 cm disc)
Video mode and nalized only.
Audio CD: Music CDs or CD-R/CD-
RW in music CD format that can be
purchased.
About the “7” Symbol Display
“7” may appear on your TV display during operation
and indicates that the function explained in this
owner’s manual is not available on that specic
media.
Symbols Used in this Manual
rDVD-Video, DVD±R/RW in Video
mode and nalized
tAudio CDs
yVideo les contained in the USB/
Disc
uAudio les contained in the USB/
Disc
iPhoto les contained in the USB/
Disc
, Note
Indicates special notes and operating features.
, Tip
Indicates tip and hints for making the task easier.
>Caution
Indicates cautions for preventing possible damages
from abuse.
Regional Codes
This unit has a regional code printed on the unit.
This unit can play only DVD discs labeled same as the
unit or “ALL”.
yMost DVD discs have a globe with one or more
numbers in it clearly visible on the cover. This
number must match your unit’s regional code or
the disc cannot play.
yIf you try to play a DVD with a different regional
code from your unit, the message “Check Regional
Code” appears on the TV screen.

Getting Started8
Getting Started
1
Playable file
Requirement
Music file requirement
MP3/ WMA le compatibility with this unit is limited
as follows :
ySampling frequency : within 32 to 48 kHz (MP3),
within 32 to 48 kHz (WMA)
yBit rate : within 32 to 320 kbps (MP3),
40 to 192 kbps (WMA)
ySupport Version : v2, v7, v8, v9
yMaximum les : Under 999
yFile extensions : “.mp3”/ “.wma”
yCD-ROM le format : ISO9660/ JOLIET
yWe recommend that you use Easy-CD Creator,
which creates an ISO9660 le system.
yYou have to set the disc format option to
[Mastered] in order to make the discs compatible
with the LG players when formatting rewritable
discs. When setting the option to Live File System,
you cannot use it on LG players.(Mastered/ Live
File System : Disc format system for Windows
Vista)
The DTS is not supported. In case of DTS audio
format, audio is not output.
Photo file requirement
Photo le compatibility with this unit is limited as
follows :
yMax pixel in width : 2760 x 2048 pixel
yMaximum les : Under 999
ySome discs may not operate due to a different
recording format or the condition of disc.
yFile extensions: “.jpg”
yCD-ROM le format : ISO9660/ JOLIET
Video file requirement
Video le compatibility with this unit is limited as
follows :
yAvailable resolution: within 720 x 576 (W x H)
pixels.
yThe le name of the Video subtitle should be
entered within 45 characters.
yIf there is impossible code to express in the Video
le, it may be displayed as “ _ “ mark on the display.
yFrame rate : less than 30 fps.
yIf the video and audio structure of recorded les is
not interleaved, either video or audio is outputted.
yPlayable Video le : “.avi”, “.mpg”, “.mpeg”
yPlayable Subtitle format : SubRip (*.srt/ *.txt),
SAMI (*.smi), SubStation Alpha (*.ssa/ *.txt),
MicroDVD (*.sub/ *.txt), SubViewer 2.0 (*.sub/
*.txt), Vobsub (*.sub)
yPlayable Codec format :
“Xvid”, “MPEG-1”, “MPEG-2”
yPlayable Audio format : “AC3”, “PCM”, “MP3”,
“WMA”,
ySampling frequency : within 32 to 48 kHz (MP3),
within 32 to 48 kHz (WMA)
yBit rate : within 32 to 320 kbps (MP3), 40 to 192
kbps (WMA)
yFor Discs formatted in Live le system, you can not
it on this unit.
yIf the name of movie le is different from that of
the subtitle le, during playback of a Video le,
subtitle may not be display.
yIf you play a Xvid le differ from Xvid spec, it may
not operate normally.
yIf you play GMC video le which is more than
1-warp point, video playback screen will not
smooth.

Getting Started10
Getting Started
1
Front panel
a Disc Tray
b Display window
Shows the current status of the unit.
c Microphone jacks 1/2
d PORT. IN
Connects to a portable player with audio
outputs.
e USB Port
Connects a USB device.
f R (Open/Close)
Opens or closes the disc tray.
g T (Play/Pause)
- Starts playback.
- Pauses playback temporarily, press again to exit
pause mode.
h I (Stop)
Stops playback.
i F (Function)
Changes the input source or function.
j -/+(Volume)
Adjusts speaker volume.
k 1/! (Standby/On)
Switches the unit ON or OFF.

Getting Started 11
Getting Started
1
a Power cord
b Speaker connectors
Connects the speaker cables.
c HDMI OUT TO TV
Connects to TV with HDMI inputs.
(Interface for digital audio and video)
d AUX (L/R) INPUT
Connects to an external source with 2 channel
audio outputs.
e VIDEO OUT
Connects to a TV with video inputs.
f ANTENNA FM
FM- Connects the FM wired antenna.
g OPTICAL IN
Connects to optical audio equipment.
Rear panel

Connecting14
Connecting
2
3. Attach the speakers to the speaker stands by
rotating the screws.
Do not catch the speaker cord between speaker
and the pole.
, Note
4. Connect the speaker wire to the terminal on the
speaker. Make sure the wire marked black goes in
to the terminal marked “-”(minus) and the other
wire goes in to the terminal marked “+”(plus).
Be careful that the speaker
does not fall down. Otherwise
it may result in the speaker
malfunction and cause
personal injury and/ or
property damage.
> Caution
Produktspecifikationer
Varumärke: | LG |
Kategori: | Blu ray-spelare |
Modell: | LHD647 |
Behöver du hjälp?
Om du behöver hjälp med LG LHD647 ställ en fråga nedan och andra användare kommer att svara dig
Blu ray-spelare LG Manualer
9 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
Blu ray-spelare Manualer
- Vizio
- Sharp
- Asus
- Philips
- Tascam
- Grundig
- Hitachi
- Denon
- Oppo
- Cambridge
- Peaq
- Toshiba
- Verbatim
- NAD
- Marantz
Nyaste Blu ray-spelare Manualer
19 Augusti 2025
13 Augusti 2025
13 Augusti 2025
13 Augusti 2025
1 Augusti 2025
31 Juli 2025
18 Juli 2025
18 Juli 2025
18 Juli 2025
18 Juli 2025
