Sida 1/12

Operating instructions

Upright refrigerator

090114

7082831 - 01

KP2620/ K(P)(sl)3120 ... 3

Contents

1 Appliance at a glance............................................ 2

1.1 Description of appliance and equipment.................. 2

1.2 Range of appliance use............................................ 2

1.3 Conformity................................................................ 3

1.4 External dimensions of the appliance....................... 3

1.5 Saving energy.......................................................... 3

2 General safety information................................... 3

3 Controls and displays........................................... 4

3.1 Operating controls.................................................... 4

3.2 Temperature display................................................. 4

4 Putting into operation............................................ 4

4.1 Changing over the door hinges................................ 4

4.2 Insertion into a row of kitchen units........................... 5

4.3 Transporting the appliance....................................... 6

4.4 Installing the appliance............................................. 6

4.5 Disposing of packaging............................................ 7

4.6 Connecting the appliance......................................... 7

4.7 Switching on the appliance....................................... 7

5 Control.................................................................... 7

5.1 Brightness of the temperature display...................... 7

5.2 Food refrigeration..................................................... 8

5.3 Setting the temperature............................................ 8

5.4 SuperCool................................................................ 8

5.5 Fan........................................................................... 8

5.6 Shelves.................................................................... 8

5.7 Using the sectioned shelf......................................... 9

5.8 Door racks................................................................ 9

5.9 Removing the bottle holder....................................... 9

6 Maintenance........................................................... 9

6.1 Defrosting................................................................. 9

6.2 Cleaning the appliance............................................. 9

6.3 Replacing the interior illumination with LED lamp..... 10

6.4 Customer service..................................................... 10

7 Malfunction............................................................. 10

8 Decommissioning.................................................. 11

8.1 Switching off the appliance....................................... 11

8.2 Taking the appliance out of service.......................... 11

9 Disposing of the appliance................................... 11

The manufacturer works constantly on the further development

of all the types and models. Therefore please understand that

we have to reserve the right to make design, equipment and

technical modifications.

To get to know all the benefits of your new appliance, please

read the information contained in these instructions carefully.

The instructions apply to several models. Differences may

occur. Text relating only to specific appliances is marked with

an asterisk (*).

Instructions for action are marked with a , the results of

action are marked with a

1 Appliance at a glance

1.1 Description of appliance and equip-

ment

Note

Place food inside the appliance as shown in the diagram.

This allows the appliance to save energy during operation.

Shelves, drawers and baskets are arranged for optimum

energy efficiency on delivery.

Fig. 1

(1) (8)Operating controls Defrost water drain

(2) (9)Shelf*, adjustable Coldest area

(3) (10)Butter shelf Bottle shelf

(4) (11)Egg tray Vegetable bins

(5) (12)Bottle rack Type plate

(6) (13)Interior light Adjustable feet at the

front, castors for transport

at the rear

(7) Door rack, adjustable

1.2 Range of appliance use

The appliance is suitable solely for cooling food

in a domestic environment or similar. This

includes use in, for example

in staff kitchenettes, bed and breakfast estab-

lishments,

by guests in country homes, hotels, motels

and other forms of accommodation,

in catering and similar services in the whole-

sale trade

Use the appliance solely as is customary within

a domestic environment. All other types of use

are inadmissible. The appliance is not suitable

for storing and cooling medicines, blood

plasma, laboratory preparations or similar

substances and products covered by the

2007/47/EC Medical Devices Directive. Misuse

of the appliance can result in the stored prod-

ucts suffering harm or perishing. Furthermore,

the appliance is not suitable for operation in

potentially explosive atmospheres.

The appliance is set to operate within specific

ambient temperature limits according to its

climate rating. The correct climate rating for

your appliance is indicated on the type plate.

Appliance at a glance

2 * Depending on model and options

Note

Compliance with the ambient temperatures

indicated is required, otherwise the cooling

performance is reduced.

Climate

rating

for ambient temperatures of

SN 10 °C to 32 °C

N 16 °C to 32 °C

ST 16 °C to 38 °C

T 16 °C to 43 °C

1.3 Conformity

The refrigerant circuit is tested for leakage. The appliance

complies with the relevant safety regulations and EC Directives

2006/95/EC, 2004/108/EC, 2009/125/EC and 2010/30/EU.

Note for test institutions:

Tests are to be carried out according to the applicable

standards and guidelines.

Preparation and testing of the appliances must be carried

out taking the and themanufacturer's loading plans

notes in the operating manual into account.

1.4 External dimensions of the appli-

ance

Fig. 2

KP 2620 1250

K(P)(sl) 3120 1447

For appliances supplied with wall spacers, the measurement

increases by 35 mm (see 4.4) .

1.5 Saving energy

Always ensure good ventilation. Do not cover ventilation

openings or grille.

Always keep fan louvres clear.

Do not place appliance in areas of direct sunlight or next to a

stove, heater or similar object.

The energy consumption depends on the installation condi-

tions, e.g. the ambient temperature (see 1.2) .

Keep the time the appliance is open to a minimum.

The lower the temperature setting, the higher the power

consumption.

Store food logically. (see Appliance at a glance).

Ensure that all food is well packed and covered for storage.

This will prevent frost from forming.

Remove food as needed in order that it does not warm too

much.

First cool warm food to room temperature before storing it .

Accumulated dust increases the energy

consumption:

Once a year, dust the refrigerating unit

together with the metal grille of the heat

exchanger at the back of the appliance.

2 General safety information

Danger for the user:

This appliance can be used by children of 8

years old and over, and also by persons with

restricted physical, sensory or mental

capacity or lack of experience and knowl-

edge, if they are supervised or have been

instructed on safe use of the appliance and

understand the resulting risks. Children must

not be allowed to play with the appliance.

Cleaning and user maintenance must not be

carried out by children without supervision.

When disconnecting the appliance from the

supply, always take hold of the plug. Do not

pull the cable.

In the event of a fault pull out the mains plug

or deactivate the fuse.

Do not damage the mains power cable. Do

not operate the appliance with a defective

mains power cable.

Have any repairs to or intervention in the

appliance, and any change of the mains

power cable, carried out by the customer

service only or by other specialised personnel

trained for the purpose.

Only assemble, connect and dispose of the

appliance according to the instructions.

Please keep these instructions in a safe place

and pass them on to any subsequent owners.

Special-purpose lamps (incandescent lamps,

LEDs, fluorescent tubes) in the appliance

serve to illuminate the appliance interior and

are not suited for room illumination.

Fire hazard:

The refrigerant R 600a is environmentally

friendly but flammable. Escaping refrigerant

may ignite.

•

Do not damage the refrigerant circuit pipes.

•

Do not allow naked flames or ignition

sources to enter the appliance.

General safety information

* Depending on model and options 3
